Operating Manual
iMcV Modules (-LIM, -PIM and
-S2MM/ M2MM/ S2SM)
Operation Manual
19772 Pauling • Foothill Ranch, CA 92610-2611 USA
TEL: (949) 465-3000 • FAX: (949) 465-3020
www.imcnetworks.com
© 2007 IMC Networks. All rights reserved.
The information in this document is subject to change without notice. IMC Networks assumes no responsibility for any
errors that may appear in this document. iMcV-Modules are a trademark of IMC Networks. Other brands or product
names may be trademarks and are the property of their respective companies.
Document Number 50-80920-01 A4
July 2007
If the product's part number begins with an "8", it is compliant with the Restriction of Hazardous Substances (RoHS)
directive.
Advertisement
Related Manuals for IMC Networks iMcV-LIM
Summary of Contents for IMC Networks iMcV-LIM
- Page 1 © 2007 IMC Networks. All rights reserved. The information in this document is subject to change without notice. IMC Networks assumes no responsibility for any errors that may appear in this document. iMcV-Modules are a trademark of IMC Networks. Other brands or product names may be trademarks and are the property of their respective companies.
-
Page 2: Fcc Radio Frequency Interference Statement
Laser Klasse 1, Appareil A’Laser de Classe 1 limitations set forth below. At its option, IMC Networks will repair or replace at no charge the product which proves to be defective within such warranty period. This limited warranty shall not apply if the IMC Networks product has been damaged by unreasonable use, accident, negligence, service or modification by anyone other than an authorized IMC Networks Service Technician or by any other causes unrelated to defective materials or workmanship. - Page 3 Fax: (949) 465-3020 Configuration Instructions.................. 2 Installation ......................7 E-Mail: techsupport@imcnetworks.com LED Operation....................8 Web: www.imcnetworks.com Installation Troubleshooting................9 IMC Networks Technical Support..............10 Specifications Specifications ....................10 Safety Certifications..................11 Power Consumption (Typical): iMcV-PIM: 0.30 Amp. iMcV-LIM: 0.80 Amp.
- Page 4 Installation Troubleshooting Notes • During installation, first test the fiber and twisted pair connections with all troubleshooting features disabled, then enable these features, if desired, just before final installation. This will reduce the features’ interference with testing. • When working with units where the features cannot be disabled, you must establish BOTH your twisted pair and fiber connections before the link LEDs will light! •...
- Page 5 Glows green when a link is connectors (or one small form factor connector). established on the port. Also available in a single-strand fiber version, iMcV-LIM TX/SSFX allows two • wavelengths to share one fiber strand — Full-Duplex data travels on different Blinks green when port is wavelengths (1310 nm and 1550 nm) —...
- Page 6 100 Mbps Half-Duplex connection is desired, auto-negotiation Many iMcV Modules have user-configurable features (e.g., FiberAlert, LinkLoss, on iMcV-LIM must be disabled. Half- and Full-Duplex settings must be manually Auto-Negotiation, etc.). Refer to the chart for information on available features set, and match, on both devices connected to the iMcV-LIM.
- Page 7 Auto-Negotiation on iMcV-LIM iMcV-LIM Modules include the feature Auto-Negotiation. When Auto- Negotiation is enabled, the module negotiates as a 100 Mbps Full-Duplex device; if the device the iMcV-LIM is connected to can operate at 100 Mbps Full-Duplex, a link will be established.
- Page 8 FiberAlert minimizes the problems associated with the loss of one strand of fiber. they will react in your network configuration, before attempting to install the If a strand is unavailable, the IMC Networks device at the receiver end notes the enclosed module(s).
