iMcV-Modules
Operation Manual
19772 Pauling • Foothill Ranch, CA 92610-2611 USA
TEL: (949) 465-3000 • FAX: (949) 465-3020
www.imcnetworks.com
© 2007 IMC Networks. All rights reserved.
The information in this document is subject to change without notice. IMC Networks assumes no responsibility for any
errors that may appear in this document. iMcV-Modules are a trademark of IMC Networks. Other brands or product
names may be trademarks and are the property of their respective companies.
Document Number 50-80920-01 A4
March 2007
If the product's part number begins with an "8", it is compliant with the Restriction of Hazardous Substances (RoHS)
directive.
Advertisement
Table of Contents
Related Manuals for IMC Networks iMcV-Modules
Summary of Contents for IMC Networks iMcV-Modules
- Page 1 The information in this document is subject to change without notice. IMC Networks assumes no responsibility for any errors that may appear in this document. iMcV-Modules are a trademark of IMC Networks. Other brands or product names may be trademarks and are the property of their respective companies.
-
Page 2: Fcc Radio Frequency Interference Statement
Laser Klasse 1, Appareil A’Laser de Classe 1 limitations set forth below. At its option, IMC Networks will repair or replace at no charge the product which proves to be defective within such warranty period. This limited warranty shall not apply if the IMC Networks product has been damaged by unreasonable use, accident, negligence, service or modification by anyone other than an authorized IMC Networks Service Technician or by any other causes unrelated to defective materials or workmanship. - Page 3 Table of Contents IMC Networks Technical Support FCC Radio Frequency Interference Statement ............ii Warranty......................ii Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada); About the iMcV-Modules .................. 1 Configuration Instructions.................. 2 +32-16-550880 (Europe) Installation ......................7 Fax: (949) 465-3020 LED Operation....................
- Page 4 Installation Troubleshooting Notes • During installation, first test the fiber and twisted pair connections with all troubleshooting features disabled, then enable these features, if desired, just before final installation. This will reduce the features’ interference with testing. • When working with units where the features cannot be disabled, you must establish BOTH your twisted pair and fiber connections before the link LEDs will light! •...
- Page 5 Single-strand fiber versions also available. LEDs on iMcV-S2MM/S2SM/M2MM For information about other iMcV Modules refer to their respective manuals, and datasheets on the IMC Networks Web site at: The LED functions on iMcV-S2MM/S2SM/M2MM are as follows: http://www.imcnetworks.com/tech/techsup.asp • ENA Glows green when port is enabled.
- Page 6 Installation Unmanaged Modules iMcV Modules install in any IMC Networks SNMP-manageable media converter Before beginning installation of the iMcV Modules, configure them for the desired chassis or in any MediaChassis. To install an iMcV Module, remove the blank features.
- Page 7 Configuring LinkLoss and FiberAlert iMcV-PIM and iMcV-LIM Modules ship from the factory with troubleshooting iMcV Module Jumper/Switch Configuration Chart features disabled. See the configuration instructions in this manual for Module Feature Jumper/Switch Default instructions on enabling FiberAlert and LinkLoss. iMcV-PIM FiberAlert TP/FO FO LinkLoss...
- Page 8 FiberAlert minimizes the problems associated with the loss of one strand of fiber. enclosed module(s). If a strand is unavailable, the IMC Networks device at the receiver end notes the loss of link. The device will then stop transmitting data and the link signal until a ** WARNING ** signal or link pulse is received.
