R
LWSS STAINLESS STEEL
UNVENTED WATER STORAGE HEATER
INSTALLATION
COMMISSIONING
MAINTENANCE
THIS UNIT IS SUPPLIED BY
APPLIED ENERGY PRODUCTS LTD
TEL: 08709 000430

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LWSS STAINLESS STEEL and is the answer not in the manual?

Questions and answers

Summary of Contents for Redring LWSS STAINLESS STEEL

  • Page 1 LWSS STAINLESS STEEL UNVENTED WATER STORAGE HEATER INSTALLATION COMMISSIONING MAINTENANCE THIS UNIT IS SUPPLIED BY APPLIED ENERGY PRODUCTS LTD TEL: 08709 000430...
  • Page 2 APPLIED ENERGY PRODUCTS LTD STAINLESS STEEL UNVENTED HOT WATER STORAGE UNITS Please read the following carefully before installation of the product. You should be competent to install the unvented system as defined by the regulations. Special attention must be paid to maintenance and service.
  • Page 3 Please also take into account any fitting that could restrict flow such as water meters, softeners etc. Connection to the unit – Use 22mm compression for all connections. Use gunmetal, DZR or brass fittings, noting local water conditions. COLD MAINS COMPONENT LAYOUT EXPANSION VESSEL COLD TAPS (OPTIONAL)
  • Page 4: Guidance Notes

    GUIDANCE NOTES TUNDISH DISCHARGE The unit is supplied with two mechanical safety devices. An expansion relief valve, supplied loose, and a temperature/pressure relief valve fitted to the unit, both discharging into a tundish (supplied loose). Discharge pipes must be left open to atmosphere, not blocking the tundish. The responsibility for supplying and fitting the discharge pipe from the tundish is that of the certified installer.
  • Page 5 GUIDANCE NOTES d.3 Discharges at high level; e.g. in to metal hopper and metal down pipe with the end of the discharge pipe clearly visible (tundish visible or not) or onto a roof capable of withstanding high temperature discharges of water and 3m from any plastic guttering systems that would collect such discharges (tundish visible).
  • Page 6 GUIDANCE NOTES - TYPICAL DISCHARGE PIPE ARRANGEMENT SAFETY DEVICE (e.g. TEMPERATURE RELIEF VALVE) METAL DISCHARGE PIPE (D1) FROM TEMPERATURE RELIEF TO TUNDISH 500mm MAXIMUM TUNDISH 300mm MINIMUM DISCHARGE BELOW FIXED GRATING (3.9d GIVES ALTERNATIVE POINTS METAL DISCHARGE PIPE (D2) OF DISCHARGE) FROM TUNDISH, WITH CONTINUOUS FALL FIXED GRATING...
  • Page 7: Installation

    WORKED EXAMPLE: The example below is for a G 1 /2 temperature relief valve with a discharge pipe (D2) having 4 No. elbows and length of 7m from the tundish to the point of discharge. From Table 1 • Maximum resistance allowed for a straight length of 22mm copper discharge pipe (D2) from a G 1 /2 temperature relief valve is 9.0m.
  • Page 8: Electrical Connections

    ELECTRICAL CONNECTIONS Immersion heaters are rated 3kw at 240v (2.76kw at 230v), incolloy elements, with a thermal energy cut- out, and must be connected via double pole switches with a 3mm contact gap separation. Appropriate wiring for the electrical load must be used. The twin immersion heaters supplied with direct units can be switched to utilise low tariff electricity supply.
  • Page 9: Wiring Installation

    WIRING INSTALLATION The wiring diagram for Danfoss systems is given as guidance. For modified Danfoss Randall Y, S and W plan systems when used in conjunction with unvented water storage systems. Programmers recommended are: FP715 (7,5 and 2 day programming and the CP15 5, 2 and 24 hour programming.
  • Page 10 WIRING INSTALLATION The wiring diagram for Danfoss systems is given as guidance. For modified Danfoss Randall Y, S and W plan systems when used in conjunction with unvented water storage systems. Programmers recommended are: FP715 (7,5 and 2 day programming and the CP15 5, 2 and 24 hour programming.
  • Page 11 WIRING INSTALLATION The wiring diagram for Danfoss systems is given as guidance. For modified Danfoss Randall Y, S and W plan systems when used in conjunction with unvented water storage systems. Programmers recommended are: FP715 (7,5 and 2 day programming and the CP15 5, 2 and 24 hour programming.
  • Page 12: Commissioning Instructions

    COMMISSIONING INSTRUCTIONS BEFORE FILLING, CHECK EXPANSION VESSEL CHARGE IS AT 3.0 BAR. 1. Open all terminal fittings on the domestic hot water circuit. Open the main supply to the unit. 2. Flush through until all air is expelled. 3. Close hot outlets and open all cold outlets connected to the tee after the pressure control valve. 4.
  • Page 13 STAINLESS INDIRECT UNIT WITH COMPONENT I.D. " Female boss for expansion vessel COLD MAIN IN THROUGH E, THEN G. D IS TEED OFF BETWEEN G AND THE UNIT. HOT DRAW-OFF TO TAPS. 3 KW IMMERSION HEATER WITH MANUAL RE-SET TEMPERATURE HIGH LIMIT CUT-OUT. TEMPERATURE AND PRESSURE RELIEF VALVE.
  • Page 14 STAINLESS DIRECT UNIT WITH COMPONENT I.D. COLD MAIN IN THROUGH E, THEN G. D IS TEED OFF BETWEEN G AND THE UNIT. HOT DRAW-OFF TO TAPS. 3 KW IMMERSION HEATER WITH MANUAL RE-SET TEMPERATURE HIGH LIMIT CUT-OUT. TEMPERATURE AND PRESSURE RELIEF VALVE. EXPANSION RELIEF VALVE.
  • Page 15: Sizing Guide

    SIZING GUIDE & SPECIFICATIONS SIZING GUIDE NOM WEIGHT NOM WEIGHT INDIRECT APPLICATION DIRECT APPLICATION CAPACITY NOM SIZES INDIRECT DIRECT (FULL) (FULL) (LITRES) HEAT-UP TIME/RE-HEAT TIME HEAT-UP TIME/RE-HEAT TIME SINGLE BATH - 3 BED TWIN BATH 1120 x 560 230kg 201kg 30mins / 21mins 88mins / 50mins 2 BATH &...
  • Page 16 GUARANTEE Applied Energy Products Ltd guarantees the shell of the unit for 25 years. The component parts, including the expansion vessel, are guaranteed for 2 years from date of purchase. THE FOLLOWING INFORMATION IS IMPORTANT – WITHOUT IT YOUR GUARANTEE MAY BE INVALID 1.
  • Page 17 TROUBLESHOOTING - NO HOT WATER - INDIRECT START IS BOILER ON? SWITCH ON PROGRAMMER SET PROGRAMME SWITCHED TO HOT WATER? RE-SET, CHECK MID POSITION WIRING & PLUMBING VALVE IN CORRECT IS CORRECT POSITION CONTROL TEMPERATURE SET RE-SET AT 55 C-60 IS ALL WIRING TO THE HIGH LIMIT...
  • Page 18 TROUBLESHOOTING - NO HOT WATER - DIRECT START POWER SWITCH ON ON TO ELEMENTS? CONTROL TEMPERATURE SET RE-SET AT 55 C-60 HIGH LIMIT REPLACE ELEMENT TRIPPED? CHECK WIRING LINKS CONTINUITY AND RE-SET...
  • Page 19 TROUBLESHOOTING - POOR WATER FLOW AT HOT TAPS START WATER SERVICE INCOMING MAINS CHECK BY SUPPLY FLOW/PRESSURE SUPPLY COMPANY ADEQUATE REQUIRED CLEAN OR REPLACE IN-LINE STRAINERS STRAINER (IN PRV) AS APPROPRIATE DIRTY SERVICE/ IS PRV REPLACE PRV FAULTY AS APPROPRIATE SYSTEM CLEAR FREE FROM...
  • Page 20 TROUBLESHOOTING - WATER DISCHARGING INTO TUNDISH START PRESSURE DOWNSTREAM OF TPRV CORRECT CLEAN OR VALVE SEAL REPLACE AND SEAT CLEAN & UNDAMAGED? REQUIRED HEATER EXPANSION RECOMMISSION OPERATING AT VESSEL CHARGE EXPANSION LESS THAN CORRECT? LEVEL IS ERV/TPRV REPLACE DISCHARGING ERV/TPRV RESET TEMPERATURE RE-CALIBRATE...
  • Page 21: Service Provider

    SERVICE INTERVAL RECORD It is recommended that your heating system is serviced regularly and that your service engineer completes the appropriate Service Interval Record below. SERVICE PROVIDER Before completing the appropriate Service Interval Record below, please ensure you have carried out the service as described in the manufacturer’s instructions and in compliance with all the relevant codes of practice.
  • Page 22 COMMISSIONING PROCEDURE INFORMATION BOILER PRIMARY SETTINGS IS THE PRIMARY SEALED OR OPEN VENTED SYSTEM? Sealed Open IF SEALED THEN WHAT IS THE SYSTEM PRESSURE? Hot Cold IF SEALED THEN WHAT IS THE CHARGE PRESSURE OF EXPANSION VESSEL? WHAT IS THE AVAILABLE BOILER FLOW TEMPERATURE? WHAT IS THE BOILER RETURN TEMPERATURE WHEN CYLINDER/STORE IS SATISFIED? BOILER PRIMARY SETTINGS IS THE VENT PIPE CORRECTLY INSTALLED?
  • Page 23: Appliance Details

    CUSTOMER DETAILS NAME ADDRESS TEL No. INSTALLER DETAILS NAME DATE ADDRESS TEL NO. REGISTRATION DETAILS (Where applicable for unvented systems etc) REG No. ID SERIAL No. etc. COMMISSIONING ENGINEER DETAILS NAME DATE ADDRESS TEL NO. REGISTRATION DETAILS (Where applicable for unvented systems etc) REG No.
  • Page 24: Service Record

    is supported by W AT E R H E AT E R MANUFACTURERS A S S O C I A T I O N Storage Waterheater Installation, Commissioning and Service Record Log Book (To be retained by customer). INSTALLER DETAILS APPLIANCE DETAILS COMMISSIONING RECORDS SERVICE INTERVAL RECORD...
