RCA MS60BKR Instruction Manual

fl at panel solutions
Fixed Wall Mount for LCD, Plasma,
and LED Displays
Instruction Manual
Specifi cations
Display Size:
Maximum Load:
Mounting Pattern:
Profi le:
Box contents
Wall Plate (x1)
Mount Arm (x2)
Safety Rod (x1)
Warnings
1.
Read these instructions before you begin. If
you are unsure of any part of the process, contact
a professional contractor or installer for assistance.
Improper installation can result in injury or damage.
2.
The wall or mounting surface must be capable of
supporting the combined weight of the mount and
the display; if not, the structure must be reinforced.
3.
Locate pipes, wires, or any other hazards in the wall
where you wish to install the mount before drilling.
4.
Safety gear and proper tools must be used. Failure
to do so can result in injury or damage.
5.
Two people are recommended for installation.
Do not attempt to lift a heavy display without
assistance.
6.
Follow all instructions and recommendations
regarding adequate ventilation and suitable
locations for mounting your display. Consult the
owner's manual for your particular display for more
information.
32" to 60"
130 lb (60kg)
600 mm x 400 mm (23.6" x 15.7") max
1.2" (3.0 cm)
Instruction Manual (x1)
Hardware Kit (x1)
Template (x1)
CAUTION:
This wall mount is intended for use only with the
maximum weight of 60 kg (130 lbs). Use with heavier
than the maximum weights indicated may result in
instability causing possible injury.
MS60BKR
Fits TVs 32"- 60"
Maximum Load
Capacity – 130 lb (60kg)
Pour des instructions
en français, se
reporter à la page 5.
Para obtener
instrucciones en
español, consulte la
página 9.
Continues on next page...
