Page 1: User Manual
LED LCD TV RECEIVER USER MANUAL MODEL: LET26C430 Please read this manual carefully before using your television and keep this manual in a good LET32C430 place for future reference. - Page 2 Rear AV connections...
- Page 3 Thanks for buying this 26"/ 32" LED LCD TV. This guide will help you set up and begin using your TV. 26" Full HD 1080P Digital LED LCD TV 32" HD Ready LED LCD TV Remote control Remote control AAA ba ttery AAA ba ttery...
-
Page 4: Safety Notice
SAF ETY NOTICE " For your protection,please read these instruction completely and keep this manual for future reference. " Please ensure that the set has adequate ventilation. " Do not place the set near a heat source or in direct sunlight. Do not put the unit near water or oil as it may cause a fire. -
Page 5: Warnings And Cautions
WARNINGS AND CAUTIONS Warning Caution High voltages are used in the operation Do not trap the power supply cord under of this television receiver. Do not remove the television receiver. the cabinet back from your set. Refer servicing to qualified service personnel. Caution Never stand on, lean on, or suddenly push Warning... -
Page 6: Installation
Introduction INSTALLATION CAUTION *Locate the TV in the room where light Never tamper with any components inside does not strike the screen directly. the TV, or any other adjustment controls not mentioned in this manual. All -TVs *Total darkness or a reflection on the are high voltage instruments. -
Page 7: Preset Mode
PRESET MODE V.Freq.(Hz) H.Freq.(KHz) RESOLUTION 800*600 37.88 640*480 31.47 1024*768 48.36 1360x768 47.7 1280x1024 63.98 1920x1080 66.64 (Only for 26") P.06... - Page 8 STAND INSTALLATION GUIDE This STAND INSTALLATION GUIDE is provided to help you easily install the stand. Please carefully follow step 1 through Step 2. Open the box and find the parts Open the box and find the following parts. Screws - Stand x1 pc Packing - Screws x 4 pcs...
-
Page 9: Wall Mounting Installation Guidelines
WALL MOUNTING INSTALLATION GUIDELINES Wall Mounting Holes Spacing and Location 200.00 4 Wall mount M4 Screws 1.Use the screwdriver to remove screws from the screw location. 2.Remove the base stand from the Main body. P.08... -
Page 10: Front Control Panel
Front control panel SOURCE MENU VOL+ VOL- STANDBY SOURCE Display the input source menu. Remote control sensor. Display main MENU. MENU Indicator LED: In TV mode,press CH+ or CH- to change CH+/CH- the channel up and down. Blue:POWER ON. RED STAND BY. In MENU, press CH+ or CH- to select items . - Page 11 P.10...
-
Page 12: Common Interface
COMMON INTERFACE The common interface (CI) slot is designed to accept the conditional Access (CA) Module and Smart card in order to view the pay TV programmes and additional services. Contact your Common Interface service provider to get more information about the modules and subscription. -
Page 13: Remote Control
Remote control 1:POWER:To set the TV to standby or power on. 2:NUMERIC KEY: For direct access to channels. POWER MUTE 3:TV MENU:To display TV menu. 4:CURSOR:To move within the menu. AUDIO 5:CH.LIST:To display the channels list. RECALL 6:VOL+/- :To adjust sound level. 7:PIC:To switch picture mode. - Page 14 REMOTE CONTROL TELETEXT Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language(cable networks, satellite channels, etc.) Press: You will obtain :...
-
Page 15: Operation
OPERATION Installation Guide Tune Type DTV+ATV Please select an OSD Language Germany Italy Norway Luxembourg Greece Poland Cesky English Magyar Polski Fran ais Hungary Portugal Netherlands Espanol Dansk Hrvatski Nederlands Portugues MENU Deutsch Italiano Norsk Pycck Pls press to select country at first , then press OK button to start auto tuning . -
Page 16: Picture Menu
Once your favorite group is created, you can ATV Manual Tuning press the FAV key to quickly access your favorite channel. Storage To 1 5). CI information: (optional) System BG This menu can display the CI card' s information. Current CH 1 2. -
Page 17: Option Menu
NOTE: The default pass word is 0000, If you forget the Clock -- password, you can use the super password:9443. Off Time Block program: Press to choose the On Time program ,press teletext green button to block Sleep Timer < >... -
Page 18: Pvr Function
8.PVR function 1.Prepare to record the program From OPTION MENU enter into PVR File Select Disk System in “OPTION MENU”, please choose “check PVR File System”. Click Check PVR File System Start “OK”, until “checking”change into USB Disk “Success”. Format Note: please check the term “speed”. - Page 19 2.Record the program (Suggest to format the device by “High Speed Fs...”, which can speed up As playing the DTV source, choose the channel and click “record”, the record the record.) frame will pop up. Click “record” again, Format disk the record frame will disappear and the “REC”...
-
Page 20: Timeshift Function
9.Timeshift function 1.Prepare to record the program 00:00:33/00:04:22 This TV allows you to pause and record the currently watched digital program to a USB Play Prev. Next Stop storage device, and to resume to the point Pause where it was paused. NOTE: NOTE: Formatting a USB 2.0 storage device will... - Page 21 Time Shift limitations: 1. When the Time Shift feature is activated, only the PLAY/PAUSE/STOP/FWD/REV/ VOL+/VOL-/MUTE keys and some basic operation keys (ENTER/EXIT/navigation keys) are available. 2. Video playback may not be smooth and skip if USB recording speed does not meet the minimum requirements .
-
Page 22: Usb Player
10.USB Player 00:00:33/00:04:22 Press source key, and selsct USB in soure list, press OK button to enter the USB menu. Info. Pause Prev. Next Stop Repeat ALL Press to select the function icon, press OK USB 2.0 button to confirm the function. Press or EXIT button to exit the control bar. -
Page 23: Troubleshooting
Trouble shooting Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction Ghost Normal audio or connection electronic equipment,car/ Interference Noise motorcycle,fluorescent light Volume(check if mute is activated or if the audio system Normal Picture connections are not correct) Mute... -
Page 24: Specification
Specification Colour system PAL-B/G, I, D/K SECAM-B/G, D/K, L, L Sound system BG, DK, I, L,L' SCART, YP , AV, Video input VGA, HDMI, USB. 480i/p, 576i/p, 720p, 1080i, 1080p HDMI 480i/p, 576i/p, 720p, 1080i, 1080p Power AC 100-240V 50/60Hz requirements Power 55W(26")
