Haier LET22T1000F User Manual

Led lcd tv receiver
Hide thumbs

Advertisement

Quick Links

LED LCD TV RECEIVER
Please read this manual carefully before using
your television and keep this manual in a good
place for future reference.

USER MANUAL

MODEL:
LET22T1000F
LET24T1000F
LET26T1000F

Advertisement

loading

  Related Manuals for Haier LET22T1000F

  Summary of Contents for Haier LET22T1000F

  • Page 1: User Manual

    LED LCD TV RECEIVER USER MANUAL MODEL: LET22T1000F Please read this manual carefully before using LET24T1000F your television and keep this manual in a good LET26T1000F place for future reference.
  • Page 2: Table Of Contents

    Safety and warnings Welcome ………………………………………………………………………… P.02 Important information …………………………………………………………… P.02 Safety notice …………………………………………………………………… P.03 Warnings and cautions ………………………………………………………… P.05 Introduction Main Parameter ………………………………………………………………… P.05 Base Stand Assembly Instruction …………………………………………… P.08 Wall Mounting Installation Guidelines ……………………………………… P.09 Control Panel …………………………………………………………………… P.10 Rear/Side Sockets ………………………………………………………………...
  • Page 3: Important Information

    Thanks for buying this 22"/24"/26" LED LCD TV. This guide will help you set up and begin using your TV. 26" HD Ready Digital LED LCD TV 22" Full HD 1080P Digital LED LCD TV 24" Full HD 1080P Digital LED LCD TV Remote control Remote control Remote control...
  • Page 4 P.03...
  • Page 5 UK Only 13A Plug Connection. If your TV is connected to the mains supply using a 3 pin 13 amp plug, the voltage rating is 220- 240 volts and should be protected by a 3 amp fuse in the plug. Should the fuse require replacement for any reason, the fuse must be replaced with a fuse rated at 3 amps and manufactured and approved to Bs1362.
  • Page 6: Warnings And Cautions

    WARNINGS AND CAUTIONS Warning Caution High voltages are used in the operation Do not trap the power supply cord under of this television receiver. Do not remove the television receiver. the cabinet back from your set. Refer servicing to qualified service personnel. Caution Never stand on, lean on, or suddenly push Warning...
  • Page 7: Introduction

    Introduction CAUTION INSTALLATION *Locate the TV in the room where light Never tamper with any components inside the TV, or any other adjustment controls not does not strike the screen directly. described in this manual. All LED-TV's are *Total darkness or a reflection on the high voltage electrical equipment.
  • Page 8 PRESET MODE V.Freq.(Hz) H.Freq.(KHz) RESOLUTION 640x480 31.47 800x600 37.88 1024x768 48.36 1360x768 47.7 1280x1024 63.98 1920x1080 66.64 (Olny for 21.5",23.6") P.07...
  • Page 9: Base Stand Assembly Instruction

    Base Stand Assembly Instruction 2. Insert the stand Ass'y into back cover 1. Insert the stand support pillar into the as the arrow indicated direction,and stand as the arrow indicated direction, then fastened with one screw. and then fastened with one screw. (22",24") (22",24") 2.
  • Page 10: Wall Mounting Installation Guidelines

    WALL MOUNTING INSTALLATION GUIDELINES 1.Place the LED LCD Television onto a 2.Remove the screws from the lower part of solid surface. Please place some soft the television, where the base joins to the TV, material over the front of the screen to and take away the stand (put the stand protect it from any damage.
  • Page 11: Control Panel

    Front control panel SOURCE MENU VOL+ VOL- STANDBY SOURCE Display the input source menu. Remote control sensor. MENU Display main MENU. Indicator LED: In TV mode,press CH+ or CH- to change CH+/CH- the channel up and down. BLUE: POWER ON. RED: STAND BY. In MENU, press CH+ or CH- to select items .
  • Page 12: Connecting Your Tv

    Connecting to your Haier TV Connecting a DVD player / Satellite / cable To select the device connected with the AVI set top box receiver / games console / PC or cable press the SOURCE button on the remote Laptop...
  • Page 13: Common Interface

    COMMON INTERFACE The common interface (CI) slot is designed to accept the conditional Access (CA) Module and Smart card in order to view the pay TV programmes and additional services. Contact your Common Interface service provider to get more information about the modules and subscription.
  • Page 14: Remote Control

    Remote control 1.POWER:Press to turn on the TV. 2.D.MENU:No function. 3.P.Mode:To switch picture mode. 4.INFO:Press to display the current signal status,including input source and channel audio mode. 5.AUDIO I/II: Press to select MONO,Nicam stereo for ATV channel. Select Audio language for DTV channel.
  • Page 15 REMOTE CONTROL TELETEXT Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language(cable networks, satellite channels, etc.) Press: You will obtain :...
  • Page 16: Operation

    OPERATION Installation Guide 1.CHANNEL MENU The installation guide only appear when the TV The first item of the MENU is channel menu( for first time turn on or reset to factory set. TV or DTV source only). WELCOME! Auto Tuning Thank you for choosing DTV Manual Tuning ATV Manual Tuning...
  • Page 17: Sound Menu

    Favourite DTV Manual Tuning Press to choose the program , press FAV button , it will show on the right side of the VHF CH program.Choose the FAV program , press FAV button again , you can cancel the FAV, will disappear .
  • Page 18: Time Menu

    4.TIME MENU NOTE: The forth item of the menu is the TIME MENU Restore factory default will clear all the programs You can adjust the clock, power on/off time, and password. sleep time etc Press to move, press OK to adjust.
  • Page 19 Record Press the red key ,It can set the program to be recorded. OSD Language English Audio Languages English Subtitle Languages English Remind Country UK Press the blue key to choose one program PVR File System < > OPTION Restore Factory Default and set up one reminder time, the TV screen will Automatic power-down(4H) skip to the choosed program in the reminder time...
  • Page 20 2.Record the program (Suggest to format the format the device by “High Speed Fs...”, which can speed up As playing the DTV source, choose the channel and click “record”, the record the record.) frame will pop up. Click “record” again, Format disk the record frame will disappear and the “REC”...
  • Page 21: Timeshift Function

    9.Timeshift function 1.Prepare to record the program 00:00:33/00:04:22 This TV allows you to pause and record the currently watched digital program to a USB Play Prev. Next Stop storage device, and to resume to the point Pause where it was paused. NOTE: NOTE: Formatting a USB 2.0 storage device will...
  • Page 22 Time Shift limitations: 1. When the Time Shift feature is activated, only the PLAY/PAUSE/STOP/FWD/REV/ VOL+/VOL-/MUTE keys and some basic operation keys (ENTER/EXIT/navigation keys) are available. 2. Video playback may not be smooth and skip if USB recording speed does not meet the minimum requirements .
  • Page 23 10.USB Player Press source key, and selsct USB in soure 00:00:33/00:04:22 list, press OK button to enter the USB menu. Pause Prev. Next Stop Repeat ALL Set A Press to select the function icon, press OK USB 2.0 button to confirm the function. Press or EXIT button to exit the control bar.
  • Page 24: Trouble Shooting

    Trouble shooting Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction Ghost Normal audio or connection electronic equipment,car/ Interference Noise motorcycle,fluorescent light Volume(check if mute is activated or if the audio system Normal Picture connections are not correct) Mute...
  • Page 25 Trouble Shooting Digital TV Problems and possible Solutions. Picture Breaks into Pixels A typical example of a reception problem includes the break up of pictures (pixilation) or the picture freezing, sometimes there are clicking or squeaking sounds or the sound drops out or there is NO reception at all.
  • Page 26: Specification

    Specification 22" Full HD 1080P Digital LED LCD TV Full HD Integrated digital. Television picture quality: Screen Size: 55"cm Resolution 1920 x 1080 pixels 50Hz. 2 HDMI sockets. 1 SCART socket. PC input socket. Component video socket. Connectivity: Composite. 1 USB port. 1 Headphone port.
  • Page 27 Specification 24" Full HD 1080P Digital LED LCD TV Full HD Integrated digital. Television picture quality: Screen Size: 60"cm Resolution 1920 x 1080 pixels 50Hz. 2 HDMI sockets. 1 SCART socket. PC input socket. Component video socket. Connectivity: Composite. 1 USB port. 1 Headphone port.
  • Page 28 Specification 26" HD Ready Digital LED LCD TV HD Ready Integrated digital. Television picture quality: Screen Size: 66"cm Resolution 1366 x 768 pixels 50Hz. 2 HDMI sockets. 1 SCART socket. PC input socket. Component video socket. Connectivity: Composite. 1 USB port. 1 Headphone port.

This manual is also suitable for:

Let26t1000fLet24t1000f
