- Page 1 TE 7 C Operating instructions Mode d’emploi Manual de instrucciones Manual de instruções...
- Page 2 This Product is Listed Ce produit est homologué Producto homologado por Este produto está registrado...
-
Page 4: Table Of Contents
In these operating instructions, the designation “the Always keep these operating instructions power tool” always refers to the TE 7-C rotary ham- together with the power tool. mer. Ensure that the operating instructions are... -
Page 5: Description
Changes or modifications to the power tool are not permissible. To avoid the risk of injury, use only genuine Hilti accessories and insert tools. Observe the information printed in the operating instructions concerning operation, care and maintenance. - Page 6 1 Power tool 1 TE‑C CLICK chuck 1 Side handle with depth gauge 1 Operating instructions 1 Hilti toolbox 1 Cleaning cloth 1 Grease 2.8 Using extension cords Use only extension cords of a type approved for the application and with conductors of adequate cross section.
-
Page 7: Insert Tools, Accessories
2.9 Using extension cords outdoors When working outdoors, use only extension cords that are approved and correspondingly marked for this application. 2.10 Using a generator or transformer This power tool may be powered by a generator or transformer which fulfills the following conditions: The unit must provide a power output in watts of at least twice the value printed on the rating plate on the power tool. -
Page 8: Safety Instructions
Power tool TE 7‑C Rated voltage 120 V Rated current input 6.3 A Mains frequency 60 Hz Weight of the tool, including side handle 3.5 kg Dimensions (L x W x H) 341 mm x 86 mm x 217 mm Drilling speed without hammering 0…900/min Hammer drilling speed... - Page 9 the power tool or these instructions to operate 5.1.3 Personal safety the power tool. Power tools are dangerous in the a) Stay alert, watch what you are doing and use hands of untrained users. common sense when operating a power tool. Do e) Maintain power tools.
- Page 10 Hilti Service Center. Under unfavorable cir- direct dust away from the face and body. Avoid cumstances, dampness or dust adhering to the prolonged contact with dust.
-
Page 11: Before Use
c) If the work involves breaking right through, take hat, ear protection, protective gloves and breathing the appropriate safety measures at the opposite protection while the machine is in use. side. Parts breaking away could fall out and / or fall down and injure other persons. - Page 12 7.1.2 Fitting the insert tool 4 7.1.5 Fitting the chuck 7 CAUTION CAUTION Wear protective gloves when changing the insert tool. Remove the depth gauge from the side handle and the insert tool from the chuck in order to avoid injury. Disconnect the supply cord plug from the power outlet.
-
Page 13: Care And Maintenance
7.2.2 Drilling without hammering 8 7.2.4 Chiseling Turn the function selector switch until it engages NOTE in the “Drilling without hammering” position. Do The chisel can be adjusted to 18 different positions not operate the function selector switch while (in 20° increments). This ensures that flat chisels and the motor is running. -
Page 14: Troubleshooting
Clean the sealing lip by wiping it carefully and then grease it again lightly 8.5 Checking the power tool after care and with Hilti grease. It is essential that the dust shield maintenance is replaced if the sealing lip is found to be damaged. -
Page 15: Disposal
10. Disposal Most of the materials from which Hilti power tools or appliances are manufactured can be recycled. The materials must be correctly separated before they can be recycled. In many countries, Hilti has already made arrangements for taking back your old power tools or appliances for recycling. Please ask your Hilti customer service department or Hilti representative for further information. - Page 16 Fax: +423 / 234 29 65 www.hilti.com Hilti = registered trademark of Hilti Corp., Schaan W 3090 0406 00-Pos. 3 1 Printed in China © 2006 202931 / A Right of technical and programme changes reserved S. E. & O.
