- Page 1 111-0444(A) 19/1/06 8:55 am Page 1.1 Envoy CODE 100D OWNER'S HANDBOOK (English Version) CODE FROM SERIAL NO: 100D 260000001 HANDBOOK: 111-0444(REV .A.) ISSUE: 28.11.05...
-
Page 2: Specifications
111-0444(A) 19/1/06 8:55 am Page 1.2 MAIN FEATURES /SPECIFICATIONS Main Features Handlebar Securing Knob. Cable. Switch Control Unit. Bail Arm. Handlebar. Cable Cleat. Grassbag Assembly. Rear Deflector. Serial No. Decal. Height of Cut Lever Motor Housing Specifications Code 100D Supply 220-240V~50Hz Rated Input 1.4 kW... -
Page 3: Table Of Contents
111-0444(A) 19/1/06 8:55 am Page 1.3 CONTENTS 1.2 Main Features/Specifications 1.19 - 1.22 Mower Maintenance 1.19 - Deck Housing 1.3 Contents 1.19 - Securing Nuts and Bolts 1.19 - Lubrication 1.4 Introduction 1.19 - Motor 1.19 - Switch Control Unit 1.5 Warranty 1.20 - Cutterblade Removal... -
Page 4: Introduction
Any arbitrary modifications carried out to this machine may relieve Hayter Limited of liability for any resulting damage or injury. Hayter mowers are robustly constructed and designed for efficient economical performance under normal mowing conditions. Correct operation and maintenance will ensure a long and satisfactory service life. -
Page 5: Warranty
111-0444(A) 19/1/06 8:55 am Page 1.5 WARRANTY LIMITED WARRANTY Hayter Limited warrants to the original user/purchaser that this unit shall be free from defects in material or workmanship under normal use for a period of two years from the date of purchase. To qualify for the full benefit of the warranty, the warranty registration card must be returned to Hayter Limited within 14 days of purchase. -
Page 6: 1.9 Safety Precautions
111-0444(A) 19/1/06 8:55 am Page 1.6 SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury. - Page 7 111-0444(A) 19/1/06 8:55 am Page 1.7 SAFETY PRECAUTIONS Preparation Always ensure that the mower is in a safe operating condition. Frequently check all nuts, bolts and screws for tightness. Use only gen- uine Hayter parts. A damaged cutterblade and loose fixing bolt are major hazards. Before use, visually inspect the cutting mechanism to ensure that it is in good condition.
- Page 8 111-0444(A) 19/1/06 8:55 am Page 1.8 SAFETY PRECAUTIONS Operation Use extreme caution when reversing or pulling the mower towards you. Switch off if the mower has to be tilted for transportation when cross- ing surfaces other than grass and when transporting the mower to and from the area to be mowed.
-
Page 9: Safety Symbols
111-0444(A) 19/1/06 8:55 am Page 1.9 SAFETY PRECAUTIONS Safety Symbols Safety Alert - Be aware to the Danger of severing toes or fin- Danger of being hit by thrown possibility of injury. gers in cutting mechanism. objects. Carefully read the Owners Switch off and remove plug Keep bystanders at a safe dis- Handbook before using the... -
Page 10: Assembling The Mower
111-0444(A) 19/1/06 8:55 am Page 1.10 ASSEMBLING THE MOWER Delivery Checklist Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Instruction Sheet 2. Grassbag Frame 3. Grassbag Top Cover 4. -
Page 11: 1.15 Operating The Mower
111-0444(A) 19/1/06 8:55 am Page 1.11 OPERATING MOWER Electrical Connection Position the mower on the grass area to be cut. Carefully uncoil the supply cable clear of the mower. Ensure that the mains socket is switched 'OFF' before connecting. Switch 'ON'. Note: We recomend the use of a RCCB unit- Refer to "Safety Precautions"... -
Page 12: Stopping
111-0444(A) 19/1/06 8:55 am Page 1.12 OPERATING THE MOWER Stopping Release the bail arm to stop the motor. WARNING: AVOID ACCIDENTS - The cutterblade may contin- ue to rotate after the mower is switched off Height of Cut Move the height of cut lever sideways to disengage it from the locking notch, then push forwards to lower or pull backwards to raise the height of cut. -
Page 13: Grassbag
111-0444(A) 19/1/06 8:55 am Page 1.13 OPERATING MOWER Grassbag To empty the grassbag raise the rear deflector and pass the grassbag under the handlebar and lower the rear deflector to rest against the rear of the mower. Pour out the grass clippings and shake the grassbag vigorously to clean the airways. -
Page 14: Safe Mower Practice
111-0444(A) 19/1/06 8:55 am Page 1.14 OPERATING THE MOWER Safe Mower Practice WARNING: PREVENT ACCIDENTS -Take extreme care do not mow across the supply cable. If this should occur, switch off immedi- ately and disconnect the plug from the power supply. Carefully exam- ine the cable for cuts and damage. -
Page 15: Overloading Protection
111-0444(A) 19/1/06 8:55 am Page 1.15 OPERATING MOWER Overloading Protection Do not let the motor labour or slow down through being overloaded in work. When this situation occurs, raise the front of the mower slightly by bearing down on the handlebar, allow the motor to reach maximum speed and proceed to mow at a slower pace. -
Page 16: Lawn Care Calendar
111-0444(A) 19/1/06 8:55 am Page 1.16 LAWN CARE CALENDAR To be used as a guide only. January There is very little work to do this month apart from brushing away leaves. Keep off the grass if frozen or waterlogged. February Rake the grass thoroughly. -
Page 17: Lawn Stripes
111-0444(A) 19/1/06 8:55 am Page 1.17 LAWN CARE CALENDAR August Keep mowing regularly and watering as necessary. Fill any cracks caused by drought with a mixture of sharp sand and soil. In dry weath- er conditions leave the grass longer to help retain ground moisture. September Raise the height of cut to allow the grass to thicken and protect the roots from the winter frost and snow. -
Page 18: Maintenance Schedule
111-0444(A) 19/1/06 8:55 am Page 1.18 MAINTENANCE SCHEDULE Follow the hourly or calendar intervals, whichever occurs first. More frequent service will be required if working for prolonged periods under dusty, dry conditions, or when airborne debris is present or after extensive operation cutting tall, dry grass. -
Page 19: 1.22 Mower Maintenance
111-0444(A) 19/1/06 8:55 am Page 1.19 MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. Securing Fasteners Regularly check that all securing nuts and bolts are tight. Replace missing or damaged items immediately. Bolt - Cutterblade fixing Torque 20Nm Plastic Screws - Bottom of Handlebar Torque 3.5Nm General Screws - Used on plastic parts 1.5Nm (Note: Use manual... -
Page 20: Cutterblade Removal
111-0444(A) 19/1/06 8:55 am Page 1.20 MOWER MAINTENANCE Cutterblade Removal Turn the mower on its side. Firmly grip the end of the cutterblade (2) with a gloved hand and remove bolt (1). When replacing ensure that the new cutterblade is the correct way up with the turned edges facing towards the motor before locating onto the two carrier pins. -
Page 21: Cutterblade Sharpening
111-0444(A) 19/1/06 8:55 am Page 1.21 MOWER MAINTENANCE Cutterblade Sharpening A slightly worn cutterblade may be re-sharpened. Both blade edges 30°-45° must be sharpened equally to ensure balance. Sharpen the cutterblade every 25 mowing hours or more frequently if conditions require. Remove the cutterblade from the mower and clean using a brush and water. -
Page 22: Storage
111-0444(A) 19/1/06 8:55 am Page 1.22 MOWER MAINTENANCE Storage Handlebar storage: To collapse the handlebar first unscrew the two top securing knobs to allow the top section of the handlebar to pivot forward to rest against the middle section then unscrew the bottom two securing knobs sufficiently to allow both top and middle sections to be folded forwards. -
Page 23: 1.24 Trouble Shooting
111-0444(A) 19/1/06 8:55 am Page 1.23 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Motor fails to start. Mains supply socket dead. Test socket by plugging in anoth- er appliance. RCCB tripped. Remove mower plug and check RCCB action. Check the supply cable for any obvious signs of damage and replace immediately if defective. - Page 24 111-0444(A) 19/1/06 8:55 am Page 1.24 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Motor vibrates excessively. Mounting bolts loose. Tighten bolts. Cutterblade bolt loose. Tighten bolt. Cutterblade out of balance. Balance cutterblade. Uneven cut Undulating ground contours. Change direction of travel. Cutterblade worn.
-
Page 25: Ec Declaration Of Conformity
111-0444(A) 19/1/06 8:55 am Page 1.25 EC DECLARATION OF CONFORMITY Manufactured for: HAYTER LIMITED, Address: Spellbrook, Bishop’s Stortford, Herts. CM23 4BU. ENGLAND declare that the lawnmower: Model name: Envoy Type: Pedestrian Rotary Electric Lawnmower Model No: CODE 100D Cutting width: 360 mm Speed of rotation of the cutting device: 2800 rpm... -
Page 26: Parts List
111-0444(A) 19/1/06 8:55 am Page 1.26 PARTS LIST DESCRIPTION ITEM NO. PART NO. QTY. ITEM NOTE Motor HY100001 Capacitor HY100002 Underdeck HY100003 Throw Plate HY100004 Wheel - Wide Assy HY100506 Bearing - Wheel HY100033 Hub - Cap HY100036 Starlock 12mm HY100047 Rod - Rear Axle HY100068... - Page 27 111-0444(A) 19/1/06 8:55 am Page 1.27 PARTS LIST DESCRIPTION ITEM NO. PART NO. QTY. ITEM NOTE Spring - Deflector HY100009 Knob - HOC HY100039 Ratchet - HOC 111-0539 Washer - Spring M8 100119 Grassbag - Fabric/base 100513 Frame - Grassbag 100016 Top - Grass Bag HY100075...
- Page 28 111-0444(A) 19/1/06 8:55 am Page 1.28 PARTS LIST 1.28 2C100C02B...
- Page 29 111-0444(A) 19/1/06 8:55 am Page 1.29 NOTES Notes:- 1.29...
- Page 30 111-0444(A) 19/1/06 8:55 am Page 1.30 NOTES Notes:- 1.30...
- Page 31 111-0444(A) 19/1/06 8:55 am Page 1.31 NOTES Notes:- 1.31...
-
Page 32: Customer Information
111-0444(A) 19/1/06 8:55 am Page 1.32 CUSTOMER INFORMATION Serial No: Motor Type 220-240V~50Hz (100D) Date of Sale:- Your Local Dealer:-...
