- Page 1 12/30 HERITAGE TRACTOR CODE143P INSTRUCTION BOOK FROM SERIAL NO:143P001001 MANUAL PART NO: 143002(REV.0.) F−98857...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTERNATIONAL SYMBOLS ......HOW TO START WITH A WEAK BATTERY ....OPERATING TIPS . -
Page 3: International Symbols
INTERNATIONAL SYMBOLS IMPORTANT: The following symbols are located on your unit or on literature supplied with the product. Before you operate the unit, learn and understand the purpose for each symbol. Safety Warning Symbols WARNING Shield Eyes. No Sparks, Flames Sulphuric Acid Can Flush Eyes Immediately IMPORTANT... -
Page 4: Safe Operation Practices
IMPORTANT SAFE OPERATION PRACTICES FOR RIDE−ON (RIDING) ROTARY MOWER MACHINES Training engage clutch slowly, always keep machine in gear, espe- cially when travelling downhill; Read the instructions carefully. Be familiar with the controls and machine speeds should be kept low on slopes and during the proper use of the equipment. -
Page 5: Responsibility Of The Owner
IMPORTANT OWNER’S INFORMATION This instruction book is for several different models. The instructions are written for a person with some mechanical ability. Like most service books, not all the steps are described. Steps on how to loosen or tighten fasteners are steps anyone can follow with some mechanical ability. Read and follow these instructions before you use the unit. -
Page 6: Slope Operation
IMPORTANT 19. Do not operate this machine if you are taking drugs or other medication which can cause drowsiness or affect your ability to operate this machine. 20. Do not use this machine if you are mentally or physically unable to operate this machine safely. SLOPE OPERATION: Slopes and rough terrain are major factors related to loss of control and tip over accidents which can result in severe injury or death. -
Page 7: Safe Mowing Guide
SAFE MOWING GUIDE Each person that operates power of the controls and how they work. In an equipment must learn to use correct and emergency, how fast you can stop the safe mowing procedures. To help you blade is important. Learn how to control learn, carefully read the following the mower at all times. - Page 8 SAFE MOWING GUIDE Before you start cutting, make sure the engine is running. Do not touch these mower was completely assembled parts of the mower. Stop the engine. Let according to the Instruction Book. If the the engine and transmission cool before mower was completely assembled by the servicing the mower.
- Page 9 SAFE MOWING GUIDE speed. The engine and transmission will mower for damage. Before you start the cut the grass with a blade that is not also run cooler at maximum engine engine again, make the necessary sharp or at a slow engine speed you can speed.
-
Page 10: Steps To Follow
STEPS TO FOLLOW BEFORE MOWING F Be sure to dress correctly. Wear hard shoes, not sandals or tennis shoes. F Examine the blade. A blade that is bent, cracked, or damaged must be replaced with a factory replacement blade. F Fill the fuel tank outside. Clean off spilled fuel. F Read and follow the Owner’s Manual, the instructions with the engine, and the instructions with any attachments. -
Page 11: Assembly
ASSEMBLY ASSEMBLY NOTE: Torque is measured in foot pounds (metric N.m). This measurement describes how tight a nut or bolt must be. The Read and follow the assembly and adjustment instructions for your torque is measured with a torque wrench. mower. -
Page 12: How To Install The Front Wheels
ASSEMBLY HOW TO INSTALL THE FRONT WHEELS Use a knife and cut the four sides of the container. Install the front After the front wheels are installed, lift the tractor from the sup- wheels in the container. Use the fasteners shown below to install port. -
Page 13: Maintenance Free Battery
ASSEMBLY MAINTENANCE FREE BATTERY HOW TO CHARGE THE MAINTENANCE FREE BATTERY IMPORTANT: Before you attach the battery cables to the WARNING: When you charge the battery, do not battery, check the battery date. The battery date tells if the smoke. Keep the battery away from any sparks. The battery must be charged. -
Page 14: How To Install The Seat
ASSEMBLY HOW TO INSTALL THE SEAT Use the fasteners shown below to install the seat. The fasteners are WARNING: For correct and safe operation of the unit, shown at full size. fasten the connector to the wire harness. If the connector is not attached, the engine will not start. -
Page 15: How To Prepare The Engine
ASSEMBLY HOW TO PREPARE THE ENGINE NOTE: The engine was shipped from the factory filled with oil. Check the level of the oil. Add oil as needed. See the engine manufacturer’s instructions for the type of fuel and oil to use. Before you use the unit, read the information on safety, operation, maintenance, and storage. -
Page 16: Operation
OPERATION Lift Lever Ignition Headlight Switch Throttle Control Lever Î Î Î Î Blade Rotation Control Î Î Î Î Parking Brake Lever Clutch / Brake Pedal Shift Lever Figure 9 LOCATION OF CONTROLS BLADE ROTATION CONTROL: SHIFT LEVER: Use the blade rotation Use the shift lever to change the speed of the control to start and stop the rotation of the blade. -
Page 17: Attachments
OPERATION ATTACHMENTS Before you start the engine, make sure the blade rotation con- trol is in the DISENGAGE position. This unit can use many different attachments. See the attachment Move the blade rotation control to the ENGAGE position to page in this book. This unit can pull attachments like a lawn rotate the blade(s). -
Page 18: How To Set The Parking Brake
OPERATION HOW TO SET THE PARKING BRAKE Button Completely push the clutch/brake pedal forward. Lift the parking brake lever (Figure 11). Remove your foot from the clutch/brake pedal and then release the parking brake lever. Make sure the parking brake will hold the unit. -
Page 19: How To Operate With The Mower Housing
OPERATION HOW TO OPERATE WITH THE MOWER HOUSING WARNING: The deflector is a safety device. Do not re- Move the shift lever to one of the speed settings. move the deflector. The deflector forces the dis- NOTE: When you mow in heavy grass or mow with a charged material toward the ground. -
Page 20: Before Starting The Engine
OPERATION BEFORE STARTING THE ENGINE CAUTION: A mixture of alcohol (ethanol or methanol) and petrol (called gasohol), will attract moisture and cause acid CHECK THE OIL deposits during storage. While the unit is in storage, the acids in the fuel can damage the fuel system. NOTE: The engine was shipped from the factory filled with SAE 30 weight oil. -
Page 21: Operating Tips
OPERATION OPERATING TIPS Check the blade rotation control for correct adjustment. For the Before you make an inspection, adjustment (except for the car- blade(s) to disengage correctly, the adjustment must be cor- burettor) or repair, make sure the wire from the spark plug is dis- rect. -
Page 22: Maintenance
MAINTENANCE MAINTENANCE CHART FIRST EVERY EVERY EVERY EACH BEFORE STORAGE PROCEDURE HOURS HOURS HOURS HOURS Blade, Inspect and Sharpen √ Blade Rotation Control, Check √ Brake, Check √ √ Clutch, Check √ √ Tyres, Check Battery, Check and Charge √ √... -
Page 23: How To Remove And Install The Blade
MAINTENANCE INSPECT BLADE Tighten the nut that holds the blade to a torque of 30 foot pounds (41,5 N−m). WARNING: Before you inspect or remove the blade, 10. Install the mower housing. See “How To Install The Mower disconnect the wire to the spark plug. If the blade hits Housing”. -
Page 24: How To Adjust The Blade Rotation Control
MAINTENANCE HOW TO ADJUST THE BLADE ROTATION CONTROL Blade Rotation Control Engage Position WARNING: To prevent an injury, the blade rotation control must operate correctly. Stop the engine. Disconnect the wire from the spark plug. Throttle Before you adjust the blade rotation control, check and level Control Ï... -
Page 25: How To Check And Adjust The Drive Brake
MAINTENANCE HOW TO CHECK AND ADJUST THE DRIVE BRAKE Completely push the clutch/brake pedal forward. Set the parking brake. Move the shift lever to the neutral (N) position. Push the unit. If the rear wheels rotate, adjust or replace the brake pads. Adjust the Drive Brake drive brake as follows. -
Page 26: Maintenance Free Battery
MAINTENANCE MAINTENANCE FREE BATTERY HOW TO REMOVE THE BATTERY HOW TO CHARGE THE BATTERY To charge or clean the battery, remove the battery from the unit as WARNING: When you charge the battery, do not follows. smoke. Keep the battery away from any sparks. The fumes from the battery acid can cause an explosion. -
Page 27: Where To Lubricate
MAINTENANCE WHERE TO LUBRICATE Lubricate the areas shown with engine oil. Apply grease with a brush to the areas shown. NOTE: Apply grease to the steering gear assembly. CAUTION: If the unit is operated in dry areas that have sand, use a dry graphite spray to lubricate the unit. -
Page 28: How To Remove The Mower Housing
MAINTENANCE HOW TO REMOVE THE MOWER HOUSING Attach the front hanger to the axle support with the hanger rod. Fasten with the fasteners as shown. See illustration “F”. Move the lift lever to the lowest position. Move the blade rotation control to the DISENGAGE position. Make sure the mower drive belt is between the stack pulley and the two belt guides. -
Page 29: How To Level The Mower Housing
MAINTENANCE HOW TO LEVEL THE MOWER HOUSING Disconnect both adjuster rods from the adjuster rod brackets (Figure 25). If the mower housing is level, the blade will cut easier and the lawn Turn the adjustable nut clockwise to lower the front or counter- will look better. -
Page 30: How To Replace The Motion Drive Belt
MAINTENANCE HOW TO REPLACE THE MOTION DRIVE BELT Drive Pulley REMOVAL Motion Remove the mower housing. See the instructions on “How To Drive Belt Remove The Mower Housing”. Idler Pulley Completely push the pedal forward and engage the parking brake. Remove the idler pulley (Figure 27). -
Page 31: How To Replace The Mower Drive Belt
MAINTENANCE HOW TO REPLACE THE MOWER DRIVE BELT Remove the mower housing. See the instructions on “How To Make sure the “V” side of the mower drive belt is against the Remove The Mower Housing”. mandrel pulley as shown. Pull the belt retainer away from the idler pulley and remove Pull the belt retainer away from the idler pulley. -
Page 32: How To Replace The Fuse
MAINTENANCE HOW TO REPLACE THE FUSE Install a new light bulb. Align the light socket with the notches in the bezel and turn the light socket to lock in position. If the fuse is blown, the engine will not start. The location of the fuse is next to the battery. -
Page 33: Trouble Shooting Chart
TROUBLE SHOOTING CHART PROBLEM: The engine will not start. PROBLEM: A hot engine causes a decrease in power. Follow the steps, “How To Start The Engine” in this book. Clean the air screen. Electric−Start Models: Clean the battery terminals. Tighten the Check the oil. -
Page 34: Index
INDEX Adjustments Filter, Fuel, 27 Blade Rotation Control, 24 Check, 20 Fuel, Type, 20 Clutch, 25 Type, 20 Fuse, 32 Drive Brake, 25 Operation Mower Housing, Level, 29 Attachments, 17 Attachments, 17 Blade Control Lever, 17 Headlight, Replace Light Bulb, 32 Blade Rotation Control, 16 Clutch / Brake Pedal, 16 Headlight Switch, Location, 16... -
Page 35: Slope Guide
F−98857... - Page 36 NOTES F−98857...
-
Page 37: Repair Parts
12/30 HERITAGE TRACTOR CODE143P REPAIR PARTS Use only manufacturer’s authorized or approved replacement parts. The letter placed on the end of the part number denotes the type of finish for the part, C for chrome, Z for zinc, a PA for purchased assembly. It is important that you include this when ordering a part. Do not use attachments or accessories not specifically recommended for this unit. -
Page 38: Parts List
MODEL CODE143P REPAIR PARTS CHASSIS & HOOD Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î F−98857... - Page 39 MODEL CODE143P REPAIR PARTS CHASSIS & HOOD Description Part No. Description Part No. Seat 91965 Screw 26x239 Screw 26x270 Plate Assembly, Switch 91963Z Spring, Compression 164x26 Support, Dash 92331E700 Spring, Seat 91964 Frame Assembly 92515E541 Glide, Spring 91822 Bracket, Left Grille 92347E700 Bolt, Shoulder 9x38...
-
Page 40: Motion Drive
MODEL CODE143P REPAIR PARTS MOTION DRIVE F−98857... - Page 41 MODEL CODE143P REPAIR PARTS MOTION DRIVE Description Part No. Description Part No. Guide, Belt 91754Z Washer 17x148 Locknut, Flange 15x84 Plate, Belt Guide 92694E700 Nut, Flange 15x79Z Bolt, Hex 1x145 Bolt, Hex 1x124 Lockwasher 18x32 Grip 92724 Washer 17x180 Screw 26x214 Transaxle −...
- Page 42 MODEL CODE143P REPAIR PARTS STEERING F−98857...
- Page 43 MODEL CODE143P REPAIR PARTS STEERING Part Description Wheel, Steering 92078 Nut, Hex 15x118 Bolt, Hex 1x66 Post, Steering 91714Z Bolt, Hex 1x74 Screw 26x249 Bracket, Sector 91716E700 Gear, Pinion 92715 Bearing 92716 Bolt, Hex 1x84 Locknut, Flange 15x87 Spacer 92564 Gear, Sector 92316 Bracket, Sector...
-
Page 44: Mower Housing Suspension
MODEL CODE143P REPAIR PARTS MOWER HOUSING SUSPENSION F−98857... - Page 45 MODEL CODE143P REPAIR PARTS MOWER HOUSING SUSPENSION Part Description Grip 92698 Control, Blade Rotation 91781Z Bolt, Hex 25x3 Locknut, Hex 15x67 Lever Assembly, Switch 91917E700 Bolt, Carriage 2x53 Spring, Torsion 166x32 Bracket, Rear Hanger 92066E700 Nut, Flange 15x79 Nut, Adjusting 92131 Nut, Adjusting 92132...
-
Page 46: Mower Housing
MODEL CODE143P REPAIR PARTS MOWER HOUSING 54 55 F−98857... - Page 47 MODEL CODE143P REPAIR PARTS MOWER HOUSING Description Part No. Description Part No. Rod, PTO 92283Z Bracket Assembly, Right Lifter 92205E700 Locknut 15x100 Link 92064E700 Lockwasher 18x33 Nut, Flange 15x68 Locknut, Flange 15x84 Guide, Belt 91797E700 Pulley, Splined 91951 Nut, Hex 15x82 Pulley, Idler 91801...
- Page 48 MODEL CODE143P REPAIR PARTS ELECTRICAL SYSTEM Î Î F−98857...
-
Page 49: Electrical System
MODEL CODE143P REPAIR PARTS ELECTRICAL SYSTEM Part Description Switch, Seat Sensor 91031 Bolt 6x99 Wingnut 14x79 Battery 91414 −− Acid, Battery (Electrolyte) 55702 Cable, Battery Ground 24x9 Screw 26x249 Cable, Red Battery 24x29 Cap, Ignition 91488 Solenoid 24285 91489 Screw 26x214 Switch, Ignition 92377... - Page 50 MODEL CODE143P REPAIR PARTS ENGINE MOUNT F−98857...
- Page 51 MODEL CODE143P REPAIR PARTS ENGINE MOUNT Part Description Fuel Cap 92317 Fuel Tank 92342 Hose Clamp 95197 Fuel Line 23717 Hose Clamp 95197 Screw 26x201 Support, Dash 92331E700 Throttle Control 92371 Engine* −−−−− Bolt, Engine Mount 25x7 Stack Pulley Assembly 92318 Z Lockwasher 19x35...
