G. Summing Module

G.1 Introduction

G.2 Connection

INSERT LINE IN
SEND/ 1 – 8
RTN
1 – 4

G.3 Operation

G.3.1 Input 1/2 and Input 3/4
G.3.2 Input 5/6 and Input 7/8
1
2
X-Rack 8 Input Summing Module
XR624
SEL
INPUT 1/2
INPUT 3/4
INPUT 5/6
INPUT 7/8
INS
MONO
ON
1
INS
MONO
ON
MONO
ON
2
MONO
ON
Page G-1
