Grizzly G1023SLWX Machine Data Sheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G1023SLWX 10" 5 HP SINGLE-PHASE LEFT TILT
Product Dimensions:
Weight.............................................................................................................................................................. 430 lbs.
Length/Width/Height....................................................................................................................... 56 x 40-3/4 x 34 in.
Foot Print (Length/Width)................................................................................................................. 20-1/2 x 20-1/2 in.
Shipping Dimensions:
Type......................................................................................................................................................... Not Available
Content.................................................................................................................................................... Not Available
Weight.................................................................................................................................................................... N/A
Length/Width/Height........................................................................................................................... N/A x N/A x N/A
Electrical:
Switch......................................................................................................................................... Heavy Duty Magnetic
Switch Voltage...................................................................................................................................................... 220V
Cord Length.......................................................................................................................................................... 10 ft.
Cord Gauge....................................................................................................................................................12 gauge
Minimum Circuit Size........................................................................................................................................ 30 amp
Plug Included............................................................................................................................................................ No
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................5 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps.............................................................................................................................................................25A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ...............................................................................................................................Triple V-Belt
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Blade Information
Maximum Blade Diameter.......................................................................................................................... 10 in.
Maximum Width Of Dado...................................................................................................................... 13/16 in.
Blade Tilt....................................................................................................................................... Left 0-45 deg.
Arbor Size..................................................................................................................................................5/8 in.
Arbor Speed....................................................................................................................................... 4200 RPM
Arbor Bearings................................................................................................................ Sealed and Lubricated
Rim Speed........................................................................................................................................10996 FPM
The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Model G1023SLWX
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MACHINE DATA
CABINET SAW
SHEET
PAGE 1 OF 3
