- Page 1 OWNER’S MANUAL MONITOR SIGNAGE Please read this manual carefully before operating the your set and retain it for future reference. MONITOR SIGNAGE MODELS 42VS20 47VS20 55VS20 www.lg.com...
-
Page 2: Table Of Contents
Accessories - Viewing movies Optional Accessories - Viewing photos Parts and buttons - Listening to music Connecting the stand (42VS20) - Viewing the Contents List Connecting the stand (47VS20) - DivX® VOD Guide Connecting the stand (55VS20) - Using PIP/PBP... - Page 3 LICENSES TROUBLESHOOTING SPECIFICATIONS IR CODES CONTROLLING THE MULTIPLE PRODUCT Connecting the cable RS-232C Configurations Communication Parameter Command reference list Transmission / Receiving protocol...
-
Page 4: Licenses
LICENSES LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. -
Page 5: Assembling And Preparing
ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Accessories Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. -
Page 6: Optional Accessories
Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories. Stand kit 42VS20 47VS20 55VS20 Stand... -
Page 7: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Screen Buttons Screen Marks RGB/AV DVI IN DVI OUT AUDIO SPEAKER /COMPONENT OUT RGB/AV /COMPONENT IN Connection panel (See p.51 to p.53) Screen Marks Description INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. Adjust the up and down. -
Page 8: Connecting The Stand (42Vs20)
ASSEMBLING AND PREPARING Connecting the stand Connecting the stand (42VS20) (47VS20) - Only on some models. - Only on some models. Place a soft cloth on the table and put the Place a soft cloth on the table and put the product with the screen facing downward. -
Page 9: Connecting The Stand (55Vs20)
ASSEMBLING AND PREPARING Connecting the stand Connecting the Speakers (55VS20) (42VS20,47VS20) - Only on some models. - Only on some models. Place a soft cloth on the table and put the Connect the input signal cable to the Monitor product with the screen facing downward. -
Page 10: Connecting The Speakers (55Vs20)
ASSEMBLING AND PREPARING Connecting the Speakers Portrait Layout (55VS20) - Only on some models. - Only on some models. When installing in a Portrait Layout, rotate the Connect the input signal cable to the Monitor monitor clockwise 90 degrees (when facing the before installing the speakers. -
Page 11: Mounting On A Wall
If you use improper screw, the product might For more information, refer to the instructions be damaged and drop from mounted position. supplied with the wall mount. In this case, LG Electronics is not responsible for it. VESA compatible. Please use VESA standard as below. -
Page 12: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the Monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching ends to the label inside the compartment, and close the battery cover. - Page 13 USING THE MONITOR SET POWER MONITOR ENERGY INPUT SAVING . , ! PQRS WXYZ 1/a/A CLEAR - * # MARK BRIGHT NESS POWER MUTE MENU MENU AUTO AUTO S.MENU S.MENU BACK BACK TILE TILE EXIT EXIT ENERGY INPUT MONITOR SAVING .
-
Page 14: Using The Monitor Set
USING THE MONITOR SET USING THE MONITOR SET Connecting to a PC RGB connection Transmits the analog video signal from your PC to Your Monitor set supports the Plug & Play* feature. the Monitor set. Connect the PC and the Monitor set with the 15 pin signal cable as shown the * Plug &... -
Page 15: Dvi Connection
USING THE MONITOR SET DVI connection HDMI connection Transmits the digital video signal from your PC to Transmits the digital video and audio signals from the Monitor set. Connect the PC and the Monitor your PC to the Monitor set. Connect the PC and set with the DVI cable as shown the following the Monitor set with the HDMI cable as shown in illustrations. -
Page 16: Dp Connection
USING THE MONITOR SET DP connection Transmits the digital video and audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the DP cable as shown in the following illustrations. Select DP input. Back of the product. -
Page 17: Adjusting The Screen
USING THE MONITOR SET Adjusting the screen Customizing image options Customize basic and advanced options of each Selecting an image mode image mode for the best screen performance. Display images in its optimized settings by Press MENU to access the main menus. selecting one of the preset image modes. -
Page 18: Customizing Pc Display Options
USING THE MONITOR SET Adjusting the sound Advanced Customizes the advanced options. Refer to the Advanced image options. Control Selecting an sound mode Picture Reset Restores the options to the default setting. Play the sound in its optimized settings by selecting one of the preset sound modes. -
Page 19: Customizing Sound Options
If the aspect ratio is set to 4:3 for a long period of time, image burn may occur on the letterboxed area of the screen. Option Description Infinite LG's Infinity Sound option provides Sound 5.1 channel stereo sound from two speakers. NOTE Treble Controls the dominant sounds in the output. - Page 20 USING THE MONITOR SET 16:9 : This selection will allow you to adjust the : This selection will allow you to view a picture horizontally, in linear proportion, to fill the picture with an original 4:3 aspect ratio, black entire screen(useful for viewing 4:3 formatted bars will appear on both the left and right of the DVDs).
-
Page 21: Using The Input List
USING THE MONITOR SET Using the input list Selecting an input source Press INPUT to access the input source list. Press the Navigation buttons to scroll to one of the input sources and press OK. Input source Description AV(CVBS) Watch video from a VCR or other external devices. -
Page 22: Entertainment
ENTERTAINMENT ENTERTAINMENT Connecting to a wired network To set up the network seetings: (Even if your dis- play has already connected automatically, running setup again will not harm anything), (Depending on model) Press MENU to access the main menus. Press the Navigation buttons to scroll to NET- Connect the display to a local area network (LAN) WORK... -
Page 23: Network Status
Press the Navigation buttons to scroll to NET- ble terms of service. For details, contact your WORK and press OK. ISP. LG is not responsible for any malfunction of the Press the Navigation buttons to select Net- display and/or the internet connection feature work Status. -
Page 24: Connecting Usb Storage Devices
ENTERTAINMENT Connecting USB storage devices Tips for using USB storage devices Only a USB storage device is recognizable. Connect USB storage devices such as a USB If the USB storage device is connected flash memory, external hard drive to the display through a USB hub, the device is not recog- and use multimedia features (See "Browsing files"... -
Page 25: Browsing Files
ENTERTAINMENT If the USB HDD does not have an external Browsing files power source, the USB device may not be Access the photo, music, or movie lists and browse detected. So be sure to connect the external files. power source. - Please use a power adaptor for an external Connect a USB storage device. - Page 26 ENTERTAINMENT Supported file format Type Supported file format Music Movie DAT,MPG,MPEG,VOB,AVI,DIVX,MP4,MKV,TS,T Bit rate 32 to 320 RP,TP,ASF,WMV,FLV) y Sampling rate MPEG1 Layer3 : 32 kHz, 44.1 kHz, 48 kHz Movie(*.mpg/*.mpeg/*dat/*.ts/*.trp/*.tp/*.vob/*. y Sampling rate MPEG2 Layer3 : 16 kHz, 22.05 mp4/*.mov/*.mkv/*.divx/*.avi/*.asf/*.wmv/*.flv/*. kHz, 24 kHz avi(motion-jpeg)/*.
-
Page 27: Viewing Movies
ENTERTAINMENT Viewing movies Play a movie. Play video files on display. Your display shows all NOTE of the video files saved in a USB storage device or shared folder on a PC. Non-supported files are displayed the preview image by icon only Abnormal files are displayed in the form of Press the Navigation buttons to scroll to bitmap... - Page 28 ENTERTAINMENT Tips for using playing video files When you are watching the movie by Movie List function, you can adjust an image by Some user-created subtitles may not work Energy Saving key on the remote control. properly. User setup for each image mode does not Some special characters are not supported operate.
- Page 29 ENTERTAINMENT When you select the Set Video Play,, Repeat Turn on/off repeat function of movie playback. When turned on, the Press the Navigation buttons to scroll to show file within the folder will be played the Picture Size, Audio Language, Subtitle back repeatedly.
-
Page 30: Viewing Photos
ENTERTAINMENT When you select the Set Video,, Page 1/1 Photo List USB1 USB Drive Drive1 Page 1/1 Press the Navigation buttons to scroll to make appropriate adjustments. When you select the Set Audio,, Move View Page Change Change Numbers Exit To Music List Mark Mode Press the Navigation buttons to scroll to show... - Page 31 ENTERTAINMENT Using photo options ENERGY Press the ENERGY SAVING button SAVING( repeatedly to change the brightness of Use the following options while viewing photos. your screen. Option Slide Speed: Selects a slideshow speed (Fast, Medium, Slow). TransitionEffect: Set the view mode of the slideshow.
- Page 32 ENTERTAINMENT When you select the Set Photo View, Press the Navigation buttons to scroll to select Slide Speed,Transition Effect or BGM. Press the Navigation buttons to scroll to make appropriate adjustments. Transition Effect Option Option Description Sliding Pushes the current slide out of view as it plays to the next slide. Stairs Pushes the current slide in a staircase shape as it plays to the next slide.
-
Page 33: Listening To Music
ENTERTAINMENT Listening to music When you select the Set Photo View, Press the Navigation buttons to scroll to select Slide Speed or BGM.. Press the Navigation buttons to scroll to My Me- Press the Navigation buttons to scroll to make and press OK. - Page 34 ENTERTAINMENT Tips for playing music files Control playback by using the following buttons. This unit cannot support the ID3 Tag embedded MP3 files. Page 1/1 Music List 3 file(s) Marked Drive1 Page 1/1 NOTE 004. - B04.mp3 005. - B05.mp3 006.
-
Page 35: Viewing The Contents List
ENTERTAINMENT Viewing the Contents List Music options Press MENU to access the Pop-Up menus. Plays back the stored files using the Export option in SuperSign Manager. Press the Navigation buttons to scroll to Set Au- dio Play. or Set Audio. and press OK. Press the Navigation buttons to scroll to Media and press OK. -
Page 36: Divx® Vod Guide
ENTERTAINMENT DivX® VOD Guide DivX® VOD Deregistration You should deregister your device with 8 digit DivX deregistration code from your device at www.divx. com/vod. DivX® VOD Registration In order to play purchased or rented DivX® VOD contents, you should register your device with 10 Press MENU to access the main menus. -
Page 37: Using Pip/Pbp
ENTERTAINMENT Using PIP/PBP Select the PIP or PBP icon from the play list. Displays videos or photos stored in the USB device on a single monitor by dividing it into the main and sub screens. (See p.47) Press the MENU button to move to OPTION and press OK. -
Page 38: Customizing Settings
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Accessing main menus MARK BRIGHT NESS Press MENU to access the main menus. MUTE AUTO S.MENU MENU Press the Navigation buttons to scroll to one of the following menus and press OK. BACK EXIT TILE Press the Navigation buttons to scroll to the setting or option you want and press OK. -
Page 39: Picture Settings
CUSTOMIZING SETTINGS PICTURE settings PICTURE Move • Aspect Ratio : 16:9 ꔋ Press MENU to access the main menus. • Energy Saving : Off • Smart Energy Saving : Off Press the Navigation buttons to scroll to PICTURE • Picture Mode : Standard press OK. - Page 40 CUSTOMIZING SETTINGS Setting Description SCREEN Customizes the PC display options in RGB mode. (In RGB Option Mode Only) Resolution Selects a proper resolution. See “Customizing PC display options”. Auto Configure Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress.
- Page 41 CUSTOMIZING SETTINGS Advanced Control Setting Description Dynamic Adjusts the contrast to keep it at the best level according to the brightness of the screen. The Contrast picture is improved by making bright parts brighter and dark parts darker. (This function can be used (Off/High/ only under AV(CVBS) and Component.) Medium/Low)
-
Page 42: Audio Settings
If sound quality or volume is not at the level you want, it is recommended to use a separate home theater system or amplifier to cope with different user environments. Option Infinite Sound LG's Infinity Sound option provides 5.1 channel stereo sound from two speakers. Treble Controls the dominant sounds in the output. When you turn up the treble, it will increase the output to the higher frequency range. -
Page 43: Time Settings
CUSTOMIZING SETTINGS TIME settings TIME Move • Clock ꔋ Press MENU to access the main menus. • Off Time : Off • On Time : Off Press the Navigation buttons to scroll to TIME and press • Sleep Timer : Off •... -
Page 44: Option Settings
CUSTOMIZING SETTINGS OPTION settings OPTION Move • Language ꔋ Press MENU to access the main menus. • Power Indicator • ISM Method : Normal Press the Navigation buttons to scroll to OPTION and press • DPM Select : On • Fail Over : Off •... - Page 45 CUSTOMIZING SETTINGS Setting Description Tile Mode Tile Mode To use this function - Must be displayed with various other products. - Must be in a function that can be connected to RGB Cable by distributor and RS-232C. Tile mode and choose Tile alignment and set the ID of the current product to set location.
- Page 46 CUSTOMIZING SETTINGS Tile Mode This monitor can be tiled with additional monitors to create a large tiled display. When using 2 monitors When using 4 monitors When using 9 monitors When the Tile Mode option is disabled ID 2 ID 2 ID 3 ID 2 ID 1...
- Page 47 CUSTOMIZING SETTINGS PIP/PBP Displays videos or photos stored in the USB device on a single monitor by dividing it into the main and sub screens. (See p.37) Mode NOTE *PIP(Picture In Picture): Displays the Sub screen in the main screen. The subscreen is only supported when using the USB device.
-
Page 48: Picture Id
CUSTOMIZING SETTINGS Picture ID Picture ID is used to change the settings of a If you press the left/right buttons or press the specific display using a single IR receiver for ON button repeatedly, the Picture ID cycles multi-vision. The set receiving the IR signal through OFF and 0 to 4. -
Page 49: Network Settings
CUSTOMIZING SETTINGS NETWORK settings NETWORK Move • Player Name ꔋ Press MENU to access the main menus. • Network Setting : Wired • Network Status : Not connected Press the Navigation buttons to scroll to NETWORK • Server IP Setting press OK. -
Page 50: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Connect various external devices to the ports on the Monitor set’s back panel. 1 Find an external device you want to connect to your Monitor set shown on the following illustration. 2 Check the connection type of the external device. 3 Go to the appropriate illustration and check the connection details. -
Page 51: Connecting To A Hd Receiver, Dvd, Camcorder, Camera, Gaming Device Or Vcr Player
MAKING CONNECTIONS Connecting to a HD receiver, HDMI connection DVD, Camcorder, Camera, Transmits the digital video and audio signals from Gaming Device or VCR player an external device to the Monitor set. Connect the external device and the Monitor set with the HDMI Connect a HD receiver, DVD, or VCR player to the cable as shown on the following illustration. -
Page 52: Component Connection
MAKING CONNECTIONS Component connection AV(CVBS) connection Transmits the analog video and audio signals from Transmits the analog video and audio signals from an external device to the Monitor set. Connect the an external device to the Monitor set. Connect the external device and the Monitor set with the 15 external device and the Monitor set with the 15 pin signal to RCA cable as shown on the following... -
Page 53: Connecting To The Lan
MAKING CONNECTIONS Connecting to the LAN Connecting to a USB Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or LAN connection a USB memory card reader to the Monitor set and access the USB menu to use various multimedia files. -
Page 54: Daisy Chain Monitors
MAKING CONNECTIONS Daisy Chain Monitors Use this function to share the RGB video signal with other monitors without having to use a separate signal splitter box. • To use different products connected to each other Connect one end of the signal input cable (15-pin D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN connector of other products RGB Cable... -
Page 55: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING No image is displayed Problem Resolution Is the product power cord y See if the power cord is properly connected to the outlet. connected? Is the power indicator light on? y See if the power switch is turned on. y May need service. - Page 56 TROUBLESHOOTING 'Key Lock On' message appears. Problem Resolution The 'Key Lock On' message y The Lock function prevents the OSD settings from being changed appears when pressing the inadvertently. To release the lock, go to Menu and Option and disable Menu button.
- Page 57 TROUBLESHOOTING The audio function does not work. Problem Resolution No sound? y See if the audio cable is connected properly. y Adjust the volume. y See if the sound is set properly. Sound is too dull. y Select the appropriate equalize sound. Sound is too low.
-
Page 58: Specifications
SPECIFICATIONS SPECIFICATIONS 42VS20 LCD Panel Screen Type 1067.31 mm Wide (42 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1067.31 mm Pixel Pitch 0.4845 mm (H) x 0.4845 mm (V) Video Signal Max. Resolution... - Page 59 SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 967 mm x 561 mm x 125 mm / 17.5 kg 967 mm x 633 mm x 259 mm / 18.8 kg 967 mm x 561 mm x 126.5 mm / 18.25 kg 967 mm x 633 mm x 259 mm / 19.55 kg * Applicable only for models that support the speakers Audio...
- Page 60 SPECIFICATIONS 47VS20 LCD Panel Screen Type 1192.87 mm Wide (47 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1192.87 mm Pixel Pitch 0.5415 mm (H) x 0.5415 mm (V) Video Signal Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type.
- Page 61 SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 1079.5 mm x 624.6 mm x 122.9 mm / 22.2 kg 1079.5 mm x 697.7 mm x 298.3 mm / 23.6 kg 1079.5 mm x 624.6 mm x 129.2 mm / 23.0 kg 1079.5 mm x 697.7 mm x 298.3 mm / 24.4 kg * Applicable only for models that support the speakers Audio...
- Page 62 SPECIFICATIONS 55VS20 LCD Panel Screen Type 1387.80 mm Wide (55 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1387.80 mm Pixel Pitch 0.630 mm (H) x 0.630 mm (V) Video Signal Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type.
- Page 63 SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 1251 mm x 722 mm x 104 mm / 34.5 kg 1251 mm x 795 mm x 298 mm / 35.9 kg 1251 mm x 722 mm x 104 mm / 35.2 kg 1251 mm x 795 mm x 298 mm / 36.6 kg * Applicable only for models that support the speakers Audio...
- Page 64 SPECIFICATIONS DTV Mode RGB (PC) supported mode HDMI/DVI Horizontal Vertical Resolution Component Resolution (DTV) Frequency(kHz) Frequency(Hz) 480i 31.469 70.8 640 x 350 576i 31.468 70.8 720 x 400 480p 31.469 59.94 640 x 480 576p 37.5 640 x 480 720p 37.879 60.317 800 x 600...
-
Page 65: Ir Codes
IR CODES IR CODES All models do not support the HDMI/USB function. Code (Hexa) Function Note Energy Saving ( R/C BUTTON R/C BUTTON (ON/OFF) POWER INPUT R/C BUTTON Monitor On R/C BUTTON Monitor Off R/C BUTTON MENU R/C BUTTON Up ( ) R/C BUTTON Down ( ) R/C BUTTON... -
Page 66: Controlling The Multiple Product
CONTROLLING THE MULTIPLE PRODUCT CONTROLLING THE MULTIPLE PRODUCT Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 99 without being duplicated. Connecting the cable Connect the RS-232C cable as shown in the picture. -
Page 67: Command Reference List
CONTROLLING THE MULTIPLE PRODUCT Command reference list COMMAND DATA (Hexadecimal) 01. Power 00H to 01H 02. Input Select Refer to ‘02. Input Select’ 03. Aspect Ratio Refer to ‘03. Aspect Ratio’ 04. Energy Saving Refer to ‘04. Energy Saving’ 05. Picture mode 00H to 04H 06. - Page 68 CONTROLLING THE MULTIPLE PRODUCT COMMAND DATA (Hexadecimal) 39. Tile ID Refer to ‘39. Tile ID’ 40. Tile H Position 00H to 64H 41. Tile V Position 23H to 41H 42. Tile H Size 00H to 32H 43. Tile V Size 00H to 32H 44.
-
Page 69: Transmission / Receiving Protocol
CONTROLLING THE MULTIPLE PRODUCT Transmission / Receiving protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] or [Command1][Command2][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] * [Command1]: First command to control the set. * [Command2]: Second command to control the set. * [Set ID]: Set ID with which you want to communicate. Etner [Set ID] = ‘00(0x00’ to communicate with all sets regardless of their Set ID numbers. - Page 70 CONTROLLING THE MULTIPLE PRODUCT 01. Power (Command: k a) 04. Energy Saving (Command: j q) To control power On/Off the display. To control the energy saving function. Transmission Transmission [k][a][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Data 00 : Power Off Data 00: Off 01 : Power On 01: Minimum...
- Page 71 CONTROLLING THE MULTIPLE PRODUCT 07. Brightness (Command: k h) 10. Tint (Command: k j) To adjust screen brightness. To adjust screen tint. * Only available for AV/Component input. Transmission Transmission [k][h][ ][Set ID][ ][Data][Cr] [k][j][ ][Set ID][ ][Data][Cr] Data 00 to 64: Brightness 0 to 100 Data 00 to 64: Tint 0 to 100(R50 to G50) Acknowledgement Acknowledgement...
- Page 72 CONTROLLING THE MULTIPLE PRODUCT 13. V Position (Command: f r) 16. Balance (Command: k t) To set the Vertical position. To adjust balance. * Only available for Tile Off mode. Transmission Transmission [k][t][ ][Set ID][ ][Data][Cr] [f][r][ ][Set ID][ ][Data][Cr] Data 00 to 64: Left 50 to Right 50 Data 23 to 41: Bottom Max(-15) to Top Max(15) Acknowledgement...
- Page 73 CONTROLLING THE MULTIPLE PRODUCT 19. Bass (Command: k s) 22. Volume Control (Command: k f) To adjust bass. To adjust volume. Transmission Transmission [k][s][ ][Set ID][ ][Data][Cr] [k][f][ ][Set ID][ ][Data][Cr] Data 00 to 64: Bass 0 to 100 Data 00 to 64: Volume 0 to 100 Acknowledgement Acknowledgement [f][ ][Set ID][ ][OK/NG][Data][x]...
- Page 74 CONTROLLING THE MULTIPLE PRODUCT 25. Off Timer(Repeat Mode/ Time) (Command: f e) 27. On Timer Input (Command: f u) To set the Off Timer(Repeat mode/ Time) function. To set the On Timer Input function. Transmission Transmission [f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [f][u][ ][Set ID][ ][Data][Cr] Data1 00: Repeat Off Data 20: AV...
- Page 75 CONTROLLING THE MULTIPLE PRODUCT 30. 4 Hours Off (Command: m n) 33. Power Indicator(Standby Light) (Command: f o) To set the 4 Hours Off function. To set the Power Indicator(Standby Light) function. Transmission Transmission [m][n][ ][Set ID][ ][Data][Cr] [f][o][ ][Set ID][ ][Data][Cr] Data 00: 4 Hours Off Off Data 00: Standby Light Off 01: 4 Hours Off On...
- Page 76 CONTROLLING THE MULTIPLE PRODUCT 36. Reset (Command: f k) 39. Tile ID (Command: d i) To execute the Picture, Screen, Audio and Factory To set Tile ID. reset function. Transmission Transmission [d][i][ ][Set ID][ ][Data][x] [f][k][ ][Set ID][ ][Data][Cr] Data 01 to E1: Tile ID 01 to 225** Data 00: Picture Reset FF: Read Tile ID 01: Screen Reset...
- Page 77 CONTROLLING THE MULTIPLE PRODUCT 42. Tile H Size (Command: d g) 45. DPM Select (Command: f j) To set the Tile Horizontal Size. To set the DPM (Display Power Management) *Set Tile H Position to 0x32 (50) before setting Tile H function.
- Page 78 CONTROLLING THE MULTIPLE PRODUCT 48. OSD Select (Command: k l) 51. S/W Version (Command: f z) To select OSD(On Screen Display) on/off To read the software version. Transmission Transmission [k][l][ ][Set ID][ ][Data][Cr] [f][z][ ][Set ID][ ][Data][Cr] Data 00: OSD Off Data FF: Data should be always ff in hexadecimal.
- Page 79 Make sure to read the Safety Precautions before using the product. E N E RGY STA R i s a s et of p owe r- saving guidelines issued by the U.S. Keep the Owner's Manual(CD) in an accessible Environmental Protection Agency(EPA). place for future reference.
