SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION
INSTRUCTIONS
Model 80575 For Trimmer T254, T344
WARNING!
Minimize the risk of injury to yourself and others! Read the Owner's/Opera-
tor's manual originally supplied with the unit that is being upgraded and
familiarize yourself with the contents. Always wear eye and hearing protec-
tion when operating your unit.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 80575 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Shindaiwa 80575

  • Page 1 SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION INSTRUCTIONS Model 80575 For Trimmer T254, T344 WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents. Always wear eye and hearing protec- tion when operating your unit.
  • Page 2: Table Of Contents

    The instructions described in this manual are intended to help Always wear a harness when operating this unit you get the most from your Shindaiwa power tool as well as with a blade. A harness to protect you and others from harm. These procedures are is also recommended when using trimmer line.
  • Page 3: General Safety Instructions

    Immediately replace damaged or missing information labels. A new label is provided in this kit and additional labels are available from your local authorized Shindaiwa dealer. Prior to installing the new label, Remove old label and clean the outer tube with rubbing alcohol or similar cleaner.
  • Page 4: Assembly

    Assembly Removing the Existing Cutting Attachment Shield If installed, remove nylon line head, adapter plate, shield plate, and plastic shield: a. Align locking hole in adapter plate with notch in edge of gear housing and insert locking tool (A). b. Remove line head (B) by turning it clockwise until head is completely off of shaft.
  • Page 5 Install Hanger 1. Slide hanger (A) onto outer tube & position as shown. Attach with 5x12 socket head cap screw, but do not tighten at this time. Install Handle and Barrier Bar 1. Install handle and barrier. Install Gear Case 1.
  • Page 6: Install Blade

    Install New Cutting Attachment Shield Parts Required: Metal Shield, Shield Bracket, 3 - 5 x 10 mm screws (metal shield to gear housing). 2 - 5 x 8 mm screws, 2 - 5 mm nuts, 2 - 5 mm lock- washers, (bracket to shield).
  • Page 7: Shoulder Strap

    IMPORTANT! Discard blades that are bent, warped, cracked, broken or damaged in any way.Use a sharp blade. A dull blade is more likely to snag and thrust. IMPORTANT! Units with adjustable carburetors must be readjusted for blade use, otherwise serious engine damage can occur. WARNING! A standard grass trimmer unit with loop handle should NEVER be operated with blade-type attachments.
  • Page 8: Using A Brushcutter Blade

    Using A Brushcutter Blade WARNING!  Before working with a blade-equipped unit, always inspect and clean the area of objects that could interfere with or damage the blade.  Never use a blade near sidewalks, fence posts, buildings or other objects that could cause injury or damage. ...
  • Page 9 NOTES...
  • Page 10 NOTES...
  • Page 11 NOTES...
  • Page 12 If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the Shindaiwa Consumer Product Support Department at 1-877-986-7783 from 8:30 am to 4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
