SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION
INSTRUCTIONS
Model 80559 For Trimmer T230, T231,
T2500, T2510, 65001
WARNING!
Minimize the risk of injury to yourself and others! Read the Owner's/Opera-
tor's manual originally supplied with the unit that is being upgraded and
familiarize yourself with the contents. Always wear eye and hearing protec-
tion when operating your unit.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 80559 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Shindaiwa 80559

  • Page 1 SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION INSTRUCTIONS Model 80559 For Trimmer T230, T231, T2500, T2510, 65001 WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents.
  • Page 2: Table Of Contents

    The instructions described in this manual are intended to help Always wear a harness when operating this unit you get the most from your Shindaiwa power tool as well as with a blade. A harness to protect you and others from harm. These procedures are is also recommended when using trimmer line.
  • Page 3: General Safety Instructions

    Safety Labels BCC03 IMPORTANT! Safety and Operation Information Labels: Make sure all information labels are undamaged and readable. Immediately replace damaged or missing information labels. A new label is provided in this kit and additional labels are available from your local authorized Shin- daiwa dealer.
  • Page 4: Assembly

    Assembly Removing the Old Cutting Attachment Shield Remove the Existing Cutting Attachment Shield. Socket-Head Cap 1. Remove the four socket-head cap screws, bracket and Screws two shims. See Figure 1. Shim Bracket 2. Remove the retaining nut, washer and gearcase clamp screw.
  • Page 5 New Cutting Attachment Shield Assemble the Cutting Attachment Shield to the Outer Tube. 1. Attach cutting attachment shield Socket-head Cutting Attachment Shield Cap Screws mounting plate to gear case hous- ing using clamp screw, washer, and retaining nut, and tighten finger tight. Upper Clamp 2.
  • Page 6: Install Blade

    Install Blade 1. Turn the unit over so that the gearcase output shaft faces UP. 2. Align the hole in the holder with the notch in the gearcase flange, and then temporarily lock the output shaft by inserting a hex Hex Wrench wrench through both holes.
  • Page 7 WARNING! Install Holder (B) The blade must fit flat against the holder flange. The Spark Plug blade mounting hole must be centered over the raised Wrench boss on blade Holder (A). Blade 9. Lock the blade in place by centering the safety clip on Bolt the output shaft.
  • Page 8: Shoulder Strap

    Shoulder Strap Adjust the shoulder strap so the shoulder pad rests comfortably on the off-side shoulder and the cutting path of the cutting attachment is parallel to the ground. Tighten hanger screw. WARNING! Always wear a shoulder strap when operating this unit with a blade. A shoulder strap is also recommended when using trimmer line.
  • Page 9 NOTES...
  • Page 10 NOTES...
  • Page 11 NOTES...
  • Page 12 If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the Shindaiwa Consumer Product Support Department at 1-877-986-7783 from 8:30 am to 4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
