ATOMIC CLOCK WITH OUTDOOR WIRELESS TEMPERATURE
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this state-of-the-art Atomic Clock as an example of superior design
and engineering. Providing WWVB radio-controlled time, date, time zone, indoor and outdoor
temperature display, this innovative clock is ideal for home or office use. Operation of this product is
simple and straightforward. By reading this operating manual, the user will however receive a better
understanding of the Atomic Clock together with the optimum benefit of all its features.
FEATURES:
ATOMIC CLOCK:
LCD1
display
LCD2
display
• WWVB Radio controlled time with manual time setting
• 12/24 hour time display
• Time display: hour, minute, second
• Alarm setting with snooze function
• Calendar display
• Weekday display (3 languages to choose from: English, French and Spanish)
• Time zone setting
• Daylight savings time ON/OFF option (DST)
• ºC or ºF temperature display selectable
WS-8017U
Function keys
Foldable stand
Battery cover
Foldable stand
• Indoor temperature display
• Outdoor temperature display via 433MHz transmission
• Wall mount or freestanding
OUTDOOR TEMPERATURE TRANSMITTER:
Hanging holes
• Remote transmission of outdoor temperature to the Atomic clock by 433 MHz signals
• Wall mounting case
TO INSTALL AND REPLACE BATTERIES IN THE ATOMIC CLOCK
The Atomic Clock uses 2 x AA, 1.5V batteries. To install and replace the batteries, please follow the
steps below:
1.
Insert finger or other solid object in the space at the bottom center of the battery compartment
and lift up to remove the cover.
2.
Insert batteries observing the correct polarity (see marking).
3.
Replace compartment cover.
DO NOT SET THE CLOCK.
TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER
The transmitter uses 2 x AA,1.5V batteries. To install and replace the batteries, please follow the
steps below:
1.
Remove the cover.
2.
Insert the batteries, observing the correct polarity (see marking).
3.
Replace the battery cover on the unit.
Alkaline batteries are recommended for use in both units. Avoid using rechargable batteries.
SETTING UP:
Holder
