5.29.1 Supported Diagnostic Pages
If the Send Diagnostics command requests the Supported Diagnostics Pages list (PF bit = 1), the drive returns
data in the format shown in Table 141 after receiving the Receive Diagnostic Results command. It lists all of the
diagnostics pages supported by the drive.
Table 141: Supported Diagnostic Pages
Bit 7
Byte
0 Page Code (00h)
1 Reserved
2 (MSB)
3
4
: Supported Page List [2]
n
Notes.
[1] The Page Length field specifies the length in bytes of the following supported page list.
[2] The Supported Page List field shall contain a list of all diagnostic page codes implemented by the drive in
ascending order beginning with page code 00h. The drive presently supports only pages 00h (Table 141)
and 40h (Table 142).
5.29.2

Translate Address page (40h)

The Translate Address page allows the initiator to translate a logical block address into a physical sector
address or a physical sector address to a logical block address. The address to be translated is passed to the
target during the Data Out phase associated with the Send Diagnostic command and the results are returned
to the initiator during the Data In phase following the Receive Diagnostic Results command. The translated
address is returned in the Translate Address page—Receive Diagnostic (Table 142).
Table 142: Translate Address page—Receive Diagnostic (40h)
Bit 7
Byte
0 Page Code (40h) [1]
1 Reserved
2 (MSB)
3
4
5 RAREA [4] ALTSEC [5]
6
: Translated Address (if available) [8]
13
Notes.
[1] The Translate Address page contains a four byte page header which specifies the page code and length
followed by two bytes which describe the translated address followed by the translated address.
[2] The Page Length field contains the number of parameter bytes which follow.
[3] The Supplied Format field contains the value from the Send Diagnostic command supplied format field
(see Table 166).
6 5
Page Length (n-3) [1]
6 5
Page Length (000A) or (0002) [2]
Reserved
ALTTK [6] Reserved
4 3
4 3
Supplied Format [3]
Translated Format [7]
2 1
(LSB)
2 1
(LSB)
183
