Sangean H202 User Manual

Am/fm shower radio with bluetooth playback
Hide thumbs
Table of Contents

Advertisement

Quick Links

H202
GB
Version 1

Advertisement

Table of Contents
loading

Related Manuals for Sangean H202

Summary of Contents for Sangean H202

  • Page 1 H202 Version 1...
  • Page 2 Features . Built-in AM/FM antenna for best reception 2. 0 presets (5 each wave band) 3. Water resistant up to JIS7 standard 4. Auto seek stations 5. Large and easy to read LCD display 6. Easy to fix bracket and hanger 7.

  • Page 4: Lcd Display

    Controls LCD Display Preset stations (preset : Bluetooth pair button / preset 3: setting tuning step) Nap timer (Short timer) Power button Band and Time Set button Tuning Control Volume Control Speaker DC IN socket Hanger Ring Emergency Buzzer Torch button Torch Multi Purpose Handle Bracket Holder...

  • Page 5: Installing Batteries

    Installing batteries . Position the radio face down on a soft surface. 2. Remove the catch as shown and lift out the battery cover. 3. Insert 2 x “D“ size/UM-1/LR20 batteries. 4. Replace the battery cover and catch. 5. Reduced power, distortion, a “stuttering“ sound are all signs that the batteries may need replacing.

  • Page 6: Using The Ac Adaptor

    Using the AC adaptor ( not supplied ) . Remove the rubber cover of DC in socket on the left hand side of your radio. 2. Insert the adaptor plug into the DC socket. 3. Plug the adaptor into mains socket outlet. Whenever the adaptor is used, the batteries are automatically disconnected.

  • Page 7: Operating Your Radio

    Operating your radio Your radio is equipped with three tuning methods – Manual Tuning, Search tuning and Memory preset tuning. Manual Tuning . Press the Power button to turn on the radio. 2. Select the required waveband by repeatedly pressing the Band button.
  • Page 8 Search tuning . Press the Power button to turn on the radio. 2. Press the Band button to get required waveband, then extend and position telescopic aerial (FM) or rotate the radio (AM). 3. Press and hold down either Tuning up or Tuning down buttons for more than 0.5 seconds to commerce Search tuning.
  • Page 9 Memory preset tuning Storing stations in preset memories There are 5 presets for each waveband. . Press the Power button to turn on the radio. 2. Tune to the required station using one of the methods previously described. 3. Press and hold down required preset until the radio beeps (more than 2 seconds).

  • Page 10: Recalling Preset Stations

    Recalling preset stations . Press the Power button to turn on the radio. 2. Select the required waveband by pressing the Band button. 3. Momentarily press the required Preset button, the preset number and station frequency will appear in the display. Software version The software display cannot be altered and is just for your refer- ence.

  • Page 11: Setting Tuning Step

    With some mobile, you may need to input the pass code “0000”. 3. Press and release the Pair button on your H202. Now the Bluetooth icon will flash with 1 second interval. You can start the search of H202 on your Bluetooth device.

  • Page 12: Disconnecting Your Bluetooth Device

    Bluetooth-enabled device via H202. Note: a) If there are 2 Bluetooth devices searching for H202, it will show its availability on both devices. However, if one device links with the H202 first, then the other Bluetooth device won't find the H202 on its list.
  • Page 13 Sleep function – Auto Off The sleep timer will automatically switch off your radio after a pre- set time has elapsed. . Press and continue to hold down the Power button, the display will cycle through the available sleep times in the order 50-40-30-20- 0-60-50…………...

  • Page 14: Factory Reset

    Nap timer (short timer) You can set the Nap timer (short timer) either radio is on or off. Press Nap timer button , display will appear and flash last nap timer time. Press Tuning up/down button to select required nap timer time, press Nap timer button again to complete setting.

  • Page 15: Display Backlight

    Display backlight The display backlight will be switched on for approximately 15 sec- onds when any button is pressed. Emergency buzzer To activate Emergency buzzer, press and release Emergency buzzer button . Press and release the button again to switch off the buzzer.
  • Page 16 Bracket You may install the supplied bracket on the wall with the help of the double sides tape back side to hang the radio.

  • Page 17: Carrying Strap

    Carrying strap Using the supplied carrying strap, you may hang or carry the radio when not used in bathroom.

  • Page 18: Specifications

    Specifications Power requirements Mains via AC adaptor (not supplied) AC 230 volts, 50 Hz or AC 20 volts, 60 Hz ~ only/DC 3V 500 mA Batteries: 2 x UM1 (D size, LR20) Battery Life: Approx. 120 hours of listening for 4 hours a day at normal volume using alkaline batteries.
