User Manual
HDR-1

Advertisement

Table of Contents
loading

Related Manuals for Sangean HDR-1 - 04-2007

Summary of Contents for Sangean HDR-1 - 04-2007

  • Page 1 User Manual HDR-1...
  • Page 2 HD Radio™ Technology Manufactured Under License From iBiquity Digital Corporation. iBiquity Digital and the HD Radio and HD logos are registered trademarks of iBiquity Digital Corporation. HD Radio is a trademark of iBiquity Digital Corporation. U.S. and Foreign Patents. 2007/4/30, ¤U¤È 01:43 20070425_HDT-1&HDT-1X_381R20S-A.p65...

  • Page 3: Important Safety Instructions

    Important Safety Instructions 1. Read these instructions. 11. Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus. When a cart is used, 2. Keep these instructions. use caution when moving the cart/apparatus combination to avoid injury from tip-over.

  • Page 4: Main Unit Controls

    Main Unit Controls (Front & Remote Control) Unit Button Remote Button Action/Combination Function Turns unit on/off 10 Digit Keypad Programs Memory Presets FREQ Allows Direct Entry of Channel Frequency Preset Allows recall of memory presets Clock Set Allows Direct Time Entry for Clock Remote Sensor LCD Display Tuning...
  • Page 5 2007/4/30, ¤U¤È 01:43 20070425_HDT-1&HDT-1X_381R20S-A.p65...
  • Page 6 Main Unit Controls (Rear) External FM antenna socket SPDIF Optical Connection (Optional on HDT-1X) External AM loop antenna socket AC power cord socket 15. 16. Line Out socket 2007/4/30, ¤U¤È 01:43 20070425_HDT-1&HDT-1X_381R20S-A.p65...
  • Page 7 Accessories Detachable power Cord x 1 FM Dipole Antenna x 1 AM Loop antenna x 1 2007/4/30, ¤U¤È 01:44 20070425_HDT-1&HDT-1X_381R20S-A.p65...
  • Page 8 RCA type audio cable x 1 Remote control unit x 1 Instruction manual x 1 Warranty cardSeek Function To seek to another clear station, use the SEEK toggle button . Press 2007/4/30, ¤U¤È 01:44 20070425_HDT-1&HDT-1X_381R20S-A.p65...

  • Page 9: Getting Started

    Getting started Step 1. NOTE WHICH INPUT YOU ARE USING WHEN CONNECTING THE Inspect package to insure that all parts & accessories are included. HDT-1/HDT-1X TUNER TO YOUR AV SYSTEM FOR LATER REFERENCE. Step 2. a. Using RCA Cables Find a proper location for your new HDT-1/HDT-1X HD Radio Tuner i.

  • Page 10: Navigating The Display

    Navigating the Display There are many display functions. This will help you understand what the display is telling you, making navigation and setup easier. (A)Radiotext, (B)Time, (C)Signal quality, (D)Frequency, (E)and Audio spectrum. : HD RADIO Indicator : Siqnal Indicator : Station Name-MulticastSetIndex : Artist : Title : Program Type...
  • Page 11 Setting up and Programming your HDT-1/HDT-1X Setting the clock Clock setting can be done when the tuner is in Standby (power off) 1. Press and hold “INFO” button for approx. 2 seconds until display flashes “clock set “to enter Clock Set mode. 2.

  • Page 12: Radio Controls

    Radio Controls To turn the radio on, press the Standby button. Pressing the Standby button again will put the unit into standby. In standby, the tuner will display the time, dim the backlight and standby LED will be on. Selecting the radio band Press the BAND button to select the appropriate band .

  • Page 13: Manual Tuning

    Manual Tuning Press the TUNING rocker switch UP or DOWN to tune up or down to select a radio station. Tuning step per press for AM band is 10 kHz and 100 kHz for FM band. Direct Tuning By using numbered key pad, you can directly tune to a radio station. For example, to tune to station 93.30 FM, press BAND button to select FM band followed by pressing FREQ button and numbered buttons 9-3-3.
  • Page 14 Receiving HD radio stations When the radio is tuned to a station broadcasting HD radio signal, the LCD will display a blinking “HD “logo. Once the tuner acquires the HD radio signal, the “HD” logo will stay on and a Signal Strength indication will appear in the top right hand corner.

  • Page 15: Seek Function

    Seek Function HD SEEK function To seek to another clear station, use the SEEK toggle button. Using the HD SEEK button, the tuner will seek to the next available HD Press and release the SEEK UP or DOWN will go to the next available station.
  • Page 16 Recall preset stations To recall preset stations, select required band by pressing BAND selection button. Press PRESET button to enter PRESET recall mode. Display will show “GO TO PRESET”. Then followed by using one of the following methods to recall the stations. 1.
  • Page 17 Advanced Information Long press INFO button for 2 seconds to enter Advanced Information. Press and release INFO button will cycle through information of RESET, LCD Contrast Adjust, Backlight Brightness Control, (For HDT-1X: Stereo/Mono Mode, Analog Mode, Split Audio Mode), Bit Error Rate, The carrier to noise ratio, FUSE Bit Check , Transmission Mode, Station ID and Software version.

  • Page 18: Advanced Menu Options

    Advanced Menu Options Menu Option Function Controls Controls Backlight Brightness Backlight Mono/Stereo Mode Mono/Stereo switch Tuning Up to activate option Tuning Down to deactivate Analog Mode (HD OFF) Eliminated HD Radio Signal Tuning Tuning Up to activate option Tuning Down to deactivate Split Audio Mode Provides Digital Signal in Left Audio Channel Tuning Up to activate option...

  • Page 19: Troubleshooting

    AC Power Cable is not properly connected AC Outlet power not turned on Check circuit breakers/fuses Defective/Malfunctioning Unit Call Sangean Service Department at 888-SANGEAN Remote Doesn’t Work Remove plastic piece located at bottom of remote Remote Battery Not Activated Battery is Dead...
  • Page 20 “Force Analog” setting to “ON” Stange sound when radio is off Malfunctioning component If the HDT-1/HDT-1X is making a stange but detectable when the unit is on and off disconnect power immediately and contact Sangean Service Department at 888-SANGEAN 2007/4/30, ¤U¤È 01:44 20070425_HDT-1&HDT-1X_381R20S-A.p65...

  • Page 21: Specifications

    Specifications Power: Antenna System: Mains: AC 120 Volts 60 Hz only, 10 Watt maximum FM - Dipole type ( supplied ) Battery ( remote control ): 3.0V CR 2025 AM - Loop type ( supplied ) Frequency coverage: Dimension ( W x H x D ): 430x70x256 mm FM 87.50 - 108.10 MHz 520 - 1710 kHz Weight: 2.6 kg.
  • Page 22 HDT-1/HDT-1X Brief User Interface: UI KEY function Button Action Function Status Function Note standby short StandBy / PowerOn / StandBy toggle recall the last station PowerOn on last band Band short PWR ON FM1 FM2 AM1 AM2 short PWR ON RT CT SSI Freq Spectrum System Reset Contrast Bit Error Rate Carrier To Noise Ratio...
  • Page 23 1.To press preset button then to Recall Preset 0~9 FM1 BFM2 press number button finish setting Recall Preset 0~9 AM1 BAM2 Preset 2.To press number button long 2s PWR ON Store to Preset 0~9 FM1 BFM2 store channel Store to Preset 0~9 AM1 BAM2 3.When preset memory is full.

This manual is also suitable for:

Hdr-1Hdt-1Hdt-1x
