Summary of Contents for Rosen DVD Entertainment System
Page 1
DVD Entertainment NEW Z10 LOGO System Owner's Manual wireless integrated .mp3 VIDEOGAMES...
Page 3
NOTICES NOTICE OF INTENDED USE Rosen Entertainment Systems are designed to enable viewing of video ONLY for rear-seat occupants, and are not intended for viewing by the driver when the vehicle is in motion. Such use might distract the driver or interfere with the driver’s safe operation of the vehicle, and thus re-...
Table of Contents Getting Started…………………………………………………………………………………………………………………………………....…………………...6 Introduction ……………………..……………………………………………………………………………………………………………………………………..8 Discs Played………………………………………………………………………………………………………………..………………………………………….9 Changing and Adjusting Display Settngs…………………………………………………………………………………………………………..……….……..10 Using the Remote Control…………………………………………………………………………………………………………………………..……….………11 Basic Remote Control Buttons……………………………………………………………………………………………………………………..……….………12 Using Menu and Navigation Buttons, Using Audio Buttons……………………………………………………………………………………..………………13 Using DVD Disc Features……………………………………………………………………………………………………………………………..…….……….14 Replacing the Remote Battery………………………………………………………………………………………………………………………..…….……….14 CD Audio and MP3 Playback………………………………………………………………………………………………………………………………...……..15 Listening Over the Car Speakers...………………………………………………………………………………………………………………….....……..……15 Using the Included Wireless Headphones………………………………………………………………………………………………...…………....16 Replacing the Headphone Batteries ………………………………………………………………………………………………........………….16...
Rosen Z10 Owner’s Manual GETTING STARTED To Watch a DVD: Use the system with the vehicle running or with the ignition key switch 1 Power the system on, unit will default to DVD player and resume play, if a disc is present. in the “accessory”...
Page 7
Rosen Entertainment Systems Side view with DVD slot To Use An External Video Source 1 Connect the RCA audio and video outputs of the device to the Rosen RCA adapter cable. Plug into AUX input port on the side of the monitor.
Rosen Z10 Owner’s Manual • INTRODUCTION When using portable radios and telephones near the system, pic- ture or sound interference may occur. Congratulations on owning a Rosen Entertainment System! Here’s a • list of some things you can do with your system: If your car was parked in a very cold or very hot place, you may see a blank screen, distorted picture or the unit may not be able to load ·...
Rosen Entertainment Systems DISC COMPATIBILITY Incompatible Discs Compatible Discs The following disc types are known to be incompatible with the system: · All DVD-ROM/DVD-RAM/DVD+RAM discs. Note: Not all discs are supported by this system. You may find · Some DVD-R/DVD-RW/DVD+R/DVD+RW discs.
Rosen Z10 Owner’s Manual CHANGING AND ADJUSTING THE DISPLAY To exit the menu: Press the DISPLAY button to save settings and exit. Set the brightness level in daytime conditions with plenty of ambient Selecting a display mode: The system’s “widescreen” display has light.
Rosen Entertainment Systems USING THE REMOTE CONTROL You can use the remote control to operate the system, including access to features not available on the front panel. The unit has an infrared sensor to receive signals located in the control panel. For definitions of each remote control button’s specific function, see the...
Rosen Z10 Owner’s Manual BASIC REMOTE CONTROL BUTTONS Previous Chapter/Track Power Press to jump to the previous title or chapter if available on a DVD, or This button powers on the optional external source unit. (The system to the previous track on an audio CD. Not supported with some VCDs. powers on automatically with the screen position) Next Chapter/Track Play...
Rosen Entertainment Systems USING AUDIO BUTTONS USING MENU AND NAVIGATION BUTTONS Speaker Sound Control SOURCE 13 Source When this button is pressed, “Speaker Sound On” appears on the This button allows you select the Internal DVD/CD player, the Internal screen, along with the FM frequency to which you should tune your Game or the Auxiliary Input.
Rosen Z10 Owner’s Manual • USING DVD DISC FEATURES To adjust the display settings (color, contrast, etc.), press and hold the DISPLAY button for two seconds. 23 Disc Menu DISC MENU For more information about image shapes, see “Managing Black Bars,” Press to see the main menu for the DVD being played.
Rosen Entertainment Systems LISTENING OVER THE CAR SPEAKERS Note: If there seems to be a strong station on the FM Transmit- ter frequency, and you are hearing a radio station mixed in with The system uses a wireless FM Transmitter (FMT) to send audio the system audio, change the FM Transmitter frequency.
Rosen Z10 Owner’s Manual USING THE INCLUDED WIRELESS HEADPHONES The system comes with infrared (IR) wireless fold-flat headphones. These headphones receive a signal from an IR transmitter built into the unit. Headphones allow rear-seat passengers to listen without using the vehicle speakers. To turn the headphones on and off, push the Power ON/OFF but- ton on the earpiece.
Rosen Entertainment Systems USING THE INTEGRATED GAME SYSTEM USING EXTERNAL SOURCES You may use optional external video games, camcorders, and other There are integrated video games built into the system. The Rosen portable video units by connecting the unit to the auxiliary RCA input Game Controller is included.
Rosen Z10 Owner’s Manual DVD TYPICAL SETUP AND CONFIGURATION Speaker Setup The following section explains how to customize various features of the This allows you to customize the speaker setting. Internal DVD Player, including languages, display, and parental control features. Default Settings: Note: Some DVD menu settings do not apply to this system, since it is specifically engineered for automotive use.
Rosen Entertainment Systems FREQUENTLY ASKED QUESTIONS I CAN NOT GET AUDIO ON THE RADIO HOW DO I RESET MY SYSTEM? To receive audio over the radio, the system must have SPEAKERS Periodically the system may need to be reset. ENABLE selected, and the radio must be tuned to the proper station.
Page 20
Solution: Eject the DVD and inspect it for damage, scratches or cracks. Clean the DVD and re-insert the disc. Solution: Reset the system. For other questions and capabilities please contact your authorized Rosen dealer. To locate a Rosen Entertainment Systems authorized dealer, please visit www.rosenentertainment.com.
Terms of the Limited Warranty: Rosen Entertainment Systems, L.P., a California Limited Partnership, (ROSEN) warrants to the original retail purchaser, that the product(s) when installed by a ROSEN Authorized Dealer, in the original vehicle, are free from defects in materials or workmanship under normal use and conditions as follows;...
