Summary of Contents for Rosen EM-1

  • Page 1 38114 Rosen_cover.p65 8/3/01, 10:26 AM...
  • Page 2: Specifications

    7 Specifications • Power Supply: DC12V +/- 5% • Power Supply Consumption: 100VAC-240VAC@ 1 Amp • Input: TV/CATV NTSC system, F type connector, Composite NTSC Video/Stereo Audio. • Output: 6.8” TFT Monitor • Stereo speaker output 0.5W(max) Distortion <10%@1KHZ (Volume maximum) •...
  • Page 3 6 Trouble Shooting Your EM1 3 Installing Your EM1 This section will give a brief trouble shooting guide Please call Rosen Technical Support at 888-883-2790 for further information or technical support. • NO AUDIO - Check volume level. Check MUTE button. Check volume level on AUX.
  • Page 4 5 Using Auxiliary Sources 3 Installing Your EM1 Your EM1 has the capability to have one auxiliary source plugged into it at a time. This may include DVD players, closed circuit TV, camcorders, video game systems and other NTSC (RCA type) inputs. Plug in your V (video) L (left audio) and R (right audio) RCA cables into the appropriate spot on the EM1 Tuner module.
  • Page 5 1 EM1 Quick Reference Guide User Remote controller The User remote is used for day to day operation. It has basic functions such as: • Volume Up and Down and Mute • Channel Up and Down • Power On and Off •...
  • Page 6 2 About your EM1 Your Rosen EM1 has the following components: • Fully adjustable 6.8” LCD, Infrared remote receiver, with audio speakers. • Cable ready EM-1 Tuner Module with auxiliary inputs. • Two remote controls (one user remote and one master remote) •...
  • Page 7 Use the cable labeled with “Internal Speakers” to activate the Em-1 internal speakers Use the cable labeled with “External Speakers” to deactivate the Em-1 internal speakers. This sce- nario would be used if external speakers were added to your EM-1 system.
  • Page 8 3 Installing Your EM1 3 Installing Your EM1 • Plug pigtail from monitor into interface cable in J-Box. • Coil excess (service loop) wire in J-box and mount monitor using supplied screws. • Replace base cover. • Test for stability and desired range of motion. Installing Tuner module •...
  • Page 9 3 Installing Your EM1 Note : Mounting plate is only used when you want to surface mount your EM1 Interface cable 1.4 screws 10-32 x 1 Fhp 100 degree 2. # 10 washer ss 100 degree 3. Mounting baseplate 4. EM1 Main FPD Assembly Page 6 3 Installing Your EM1 C.
