Radio Controls
The numbers below refer to the illustrations on the next page.
FIG. - 1:
1. On-Off / Volume Knob
Turn clockwise to turn the radio ON. Turn fully
counter clockwise to turn OFF. Rotate to adjust
volume.
2. Push to Talk Button (PTT)
Push and hold to transmit; release to listen.
3. Up/ Down Scroll Buttons
4. LED Indicator
Lights RED while transmitting.
Lights Green while receiving a call.
5. LCD Display
6. Keypad Lock/Menu
Keypad Lock function is permanently assigned to
this button in normal operation. Also serves as Menu Button in
programming mode. See additional notes on page 11.
7. Microphone
8. Speaker
9. Antenna
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
FIG. - 2:
10. Accessory Connector
Connects headsets, remote speaker/
microphones and other accessories. Replace attached
dust cap when not in use.
11. Spring Action Belt Clip
12. Battery Release Latches
FIG. - 3:
P Keys or Programmable Function Buttons (PFB)
These buttons can be re-programmed for one of several functions
refer to page 18.
P Key Location
(on radio)
P1 Orange (top)
P2 Side
P3 P (front)
Default Function
Emergency Call
Monitor
(press momentarily)
Scan
(also serves as SAVE in
programming mode)
3
