How To Assign A Function To A P KEy (Programmable Function Button)
There are 3 Programmable Function Buttons on the J Series radio (P1, P2 and P3). See FIG 3 below for their location on the radio. You can
assign each of these buttons or P keys to perform 1 specific function when pressed. The functions you may choose from are listed below:
Options Description of the feature
P KEy will perform no function when pressed.
[NONE]
[SCAN KEy] When P KEy pressed, radio will scan marked
channels. Icon will display when ON. See CH SCAN on page 14.
When P KEy pressed, radio sends Emergency signal to other
[EMERGENC]
radios on same frequency.
[CALL KEy] Press and hold the P KEy to send a unique Call Tone to let others
know you are about to talk.
When P KEy pressed, radio will monitor traffic on the channel
[MONITOR]
without tone.
[TX PWR KEy] When P KEy pressed, will toggle
channel frequency, between HI and LOW power. Icon H or L will
be displayed.
[2T SEND] 2T SEND can only be assigned to P3 Key. When P3 Key is pressed,
the radio sends programmed 2-TONE code for the channel in use.
To Program P KEy's :
PRESS & HOLD the MONITOR button and turn radio ON.
Step 1.
Radio will sound triple beep, then [PROGRAM] will flash
on the display for 3 sec. [VOX LEV] will appear first
on display.
Step 2. Use buttons to scroll to the PFB you wish to
program: [P1 KEy], [P2 KEy] or [P3 KEy].
Step 3. Press to see current setting of the specific
P KEy you have selected.
* NOTE: Certain frequencies are limited by the FCC to 2 Watt maximum output. See pages 15 &16.
18
*
transmit power of selected
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
FIG. 3
P2
Step 4. Use buttons to scroll sub-list setting
options listed above.
Step 5. Press the button
Display will then show the last P KEy programmed;
e.g. [P_ KEy].
Step 6. To program another [P_ KEy] repeat Steps 2 - 5
or...
To return to normal operation turn radio OFF and
Step 7.
then ON.
3 Programmable
Function Buttons
P1 (Orange)
P3
to SAVE your sub-listing option.
