Your impact driver has been engineered and manufactured to our high standards for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
12 VOLT 1/4 in. RIGHT ANGLE
IMPACT DRIVER
R82233
1
Advertisement
Table of Contents
Related Manuals for RIDGID R82233
Summary of Contents for RIDGID R82233
- Page 1 When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. Thank you for buying a RIDGID product. SAVE THIS MANUAL FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ..................................2 General Safety Rules ..............................3-4 Specific Safety Rules ...............................4 Safety Rules for Charger ..............................5 Symbols ..................................6-7 Features ..................................8-9 Assembly ..................................9 Operation ................................. 10-14 Maintenance ..................................15 ... -
Page 3: General Safety Rules
Tools are dangerous in the hands MODEL BATTERY PACK CHARGER of untrained users. R82233 130252002 140276001 140276002 When battery pack is not in use, keep it away from Do not abuse the cord. Never use the cord to carry other metal objects like: paper clips, coins, keys, nails, the charger. -
Page 4: Specific Safety Rules
GENERAL SAFETY RULES SERVICE When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section Tool service must be performed only by qualified of this manual. Use of unauthorized parts or failure to repair personnel. Service or maintenance performed by follow Maintenance Instructions may create a risk of unqualified personnel may result in a risk of injury. -
Page 5: Safety Rules For Charger
SAFETY RULES FOR CHARGER Do not let gasoline, oils, petroleum-based products, WARNING! etc. come in contact with plastic parts. They contain READ AND UNDERSTAND ALL INSTRUCTIONS. chemicals that can damage, weaken, or destroy plastic. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal ... -
Page 6: Symbols
SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) - Page 7 If you do not understand the warnings and servicing, use only identical replacement parts. instructions in the operator’s manual, do not use this product. Call RIDGID customer service for assistance. WARNING: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage.
-
Page 8: Features
FEATURES PRODUCT SPECIFICATIONS Blows Per Minute ...........0-3,100 BPM Coupler ............1/4 in. Keyless Torque ..............700 in.lb. Motor ..............12 Volt DC Charger Input ........120 V, 60 Hz, AC only Switch ......Variable Speed Reversible (VSR) No Load Speed ........0-2,200 r/min. (RPM) COUPLER BIT STORAGE DIRECTION OF... -
Page 9: Assembly
FEATURES KNOW YOUR IMPACT DRIVER ELECTRIC BRAKE See Figure 1. The electric brake will stop the bit rotation after the operator releases the switch trigger. The safe use of this product requires an understanding of the information on the tool and in this operator’s manual as MINIMUM REACTIVE TORQUE well as a knowledge of the project you are attempting. -
Page 10: Operation
OPERATION WARNING: Do not allow familiarity with tools to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury. WARNING: Always wear safety goggles or safety glasses with side shields when operating tools. Failure to do so could result in objects being thrown into your eyes resulting in possible serious injury. - Page 11 OPERATION LED FUNCTION OF CHARGER See Figure 3. BATTERY GREEN ACTION INDICATOR PACK Power Without battery pack Ready to charge battery pack Evaluate Hot battery pack Flashing When battery pack reaches cooled temperature, charger begins fast charge mode Evaluate Cold battery pack Flashing When battery pack reaches warmed temperature, charger begins fast...
- Page 12 OPERATION TO INSTALL BATTERY PACK See Figure 4. Place the battery pack in the impact driver, aligning raised rib on battery pack with groove in the driver’s battery port. Make sure the latches on each side of the battery pack snap into place and the battery pack is secured to the impact driver before beginning operation.
- Page 13 OPERATION DIRECTION OF ROTATION SELECTOR See Figure 6. TURN ON The direction of bit rotation is reversible and is controlled by DIRECTION OF TURN OFF a direction of rotation selector. With the impact driver held in ROTATION SELECTOR normal operating position, the direction of rotation selector (FORWARD/REVERSE/ should be positioned to the left of the paddle switch for CENTER LOCK)
- Page 14 OPERATION WARNING: Do not drive a screw where there is likely to be hidden wiring behind the surface. Contact with a “live” wire will make exposed metal parts of the tool “live” and shock the operator. If you must drive a screw where hidden wire may be present, always hold tool by insulated gripping surfaces (handle) when performing the operation to prevent a shock...
-
Page 15: Maintenance
WARNING: repaired or replaced by the customer. All other parts should To avoid serious personal injury, always remove be replaced at a RIDGID authorized service center. the battery pack from the tool when cleaning or performing any maintenance. BATTERY PACK REMOVAL AND... - Page 16 NOTES...
-
Page 17: Warranty
RIDGID branded hand held ® directed to One World Technologies, Inc., attn: RIDGID Hand and stationary power tools. Consumable accessories pro- Held and Stationary Power Tool Technical Service at (toll vided with the tool such as, but not limited to, blades, bits free) 1-866-539-1710. -
Page 18: Customer Service Information
R82233 Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgid.com.
