Your impact driver has been engineered and manufactured to our high standards for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
14.4 VOLT 1/4 in. IMPACT DRIVER
R82320
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R82320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RIDGID R82320

  • Page 1 Your impact driver has been engineered and manufactured to our high standards for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS n Introduction ...2 n General Safety Rules ... 3-4 n Specific Safety Rules...4 n Safety Rules for Charger ...5 n Symbols... 6-7 n Features... 8-9 n Assembly ...9 n Operation ... 10-13 n Maintenance ...14 n Warranty ...15 n Customer Service Information...16 INTRODUCTION This tool has many features for making its use more pleasant and enjoyable.
  • Page 3: General Safety Rules

    Use battery only with charger listed. MODEL BATTERY PACK R82320 130252003, 130252004 n Do not abuse the cord. Never use the cord to carry the charger. Keep cord away from heat, oil, sharp edges, or moving parts. Replace damaged cords immediately.
  • Page 4: Specific Safety Rules

    Following this rule will reduce the risk of seri- ous personal injury. n Do not use the impact driver as a drill. The impact driver is not designed to be used as a drill. n Do not drive a screw where there may be hidden wiring behind the surface.
  • Page 5: Safety Rules For Charger

    SAFETY RULES FOR CHARGER WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. n Before using battery charger, read all instructions and cautionary markings in this manual, on battery charger, battery, and product using battery to prevent misuse of the products and possible injury or damage.
  • Page 6: Symbols

    SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpreta- tion of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current...
  • Page 7 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL DANGER: WARNING: CAUTION: CAUTION: SERVICE Servicing requires extreme care and knowledge and should be performed only by a qualified service technician. For service we suggest you return the product to your nearest AUTHORIZED SERVICE CENTER for repair.
  • Page 8: Features

    FEATURES PRODUCT SPECIFICATIONS Motor ...14.4 Volt DC Switch... Variable Speed No Load Speed ... 0-2850/min. Blows Per Minute ... 0-2800/BPM Charger Input ... 120 V, 60 Hz, AC only Charge Rate ... 20 minutes Torque... Maximum 1400 in.lb. COUPLER DIRECTION OF ROTATION SELECTOR (FORWARD / REVERSE LOCK - OFF)
  • Page 9: Assembly

    Minute (BPM). Blows Per Minute is the number of impacts per minute. BIT STORAGE Bit storage is located on the base of the impact driver for safe convenient storage of a bit not in use. ELECTRIC BRAKE The electric brake will stop the bit rotation after the operator releases the switch trigger.
  • Page 10: Operation

    OPERATION WARNING: Do not allow familiarity with your tool to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury. WARNING: Always wear safety goggles or safety glasses with side shields when operating tools. Failure to do so could result in objects being thrown into your eyes resulting in possible serious injury.
  • Page 11 OPERATION OPERATION LED FUNCTION OF CHARGER See Figure 3. INDICATOR Power Evaluate Evaluate Evaluate Evaluate Charging Full POWER INDICATOR EVALUATE INDICATOR CHARGING INDICATOR FULL INDICATOR BATTERY PACK Without battery pack Hot battery pack Flashing Cold battery pack Flashing Deeply discharged Flashing Thermistor shorted Flashing...
  • Page 12: Installing Bits

    Remove the battery pack from the driver. n Pull the coupler away from the driver. n Remove driver bit from the coupler. CAUTION: The impact driver is not designed to be used as a drill. RELEASE COUPLER PULL COUPLER...
  • Page 13: Switch Trigger

    OPERATION SWITCH TRIGGER See Figure 7. n To turn your driver ON, depress the switch trigger. To turn it OFF, release the switch trigger. VARIABLE SPEED See Figure 7. This tool has a variable speed switch that delivers higher speed and torque with increased trigger pressure. Speed is controlled by the amount of switch trigger depression.
  • Page 14: Maintenance

    Only the parts shown on the parts list are intended to be repaired or replaced by the customer. All other parts should be replaced at a RIDGID authorized service center. BATTERY PACK REMOVAL AND PREPARATION FOR RECYCLING...
  • Page 15: Additional Limitations

    2/1/04 and after. This product is manufactured by One World Technologies, Inc. The trademark is licensed from RIDGID, Inc. All warranty communications should be directed to One World Technologies, Inc., attn: RIDGID Hand Held and Stationary Power Tool Technical Service at (toll free) 1-866-539-1710.
  • Page 16: Customer Service Information

    R82320 Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgid.com.
