Alvin LB1218 Instructions

ALVIN Satin-Glow Lightboxes
• Double-strength window glass*
* It is best to purchase glass from a glass dealer rather than a hardware or home center.
1. To install glass, remove the two aluminum
strips on the top surface of the lightbox. For
your own safety, use gloves when handling
glass. Place the glass on top of the Plexiglas
sheet and replace the aluminum strips.
2. To operate, depress the on/off switch and
hold for one or two seconds until the lights
illuminate. Note: Bulbs may loosen during
shipping. If bulbs don't illuminate check that
they are properly seated in fixture.
1. "Daylight" bulbs with CRI of 70 or
greater are recommended. Always use
direct replacement lamps in order to
prevent overheating.
2. Disconnect the power cord.
3. Remove the screws and aluminum strips from
the top surface of the lightbox. Carefully
remove glass and Plexiglas panels.

Degrees of Illumination

MODEL No. Lumens
per Tube
LB1218 650
LB1620 650
LB1824 650
LB2436 1750
All electrical components are U.L. listed.
Alvin & Company, Inc.

Instructions for Cutting Glass

MODEL No.
LB1218
LB1620
LB1824
LB2436

IMPORTANT NOTE

It is highly recommended that these dimensions be
double-checked against your lightbox before cutting glass.

Care and Use Instructions

To Replace Fluorescent Tubes

Tubes Lumens at
per Box Light Box Surface
1 F15T8 650
2 F15T8 1300
2 F15T8 1300
3 F30T8 5100
Bloomfield, CT
• Thickness: 1 ⁄ " • Chamfer smooth all edges
8
Cut Glass to This Size
11 ⁄ " x 17
15 15
16
15 15 ⁄ " x 19 15
16
17 15 ⁄ " x 23 15
16
23 ⁄ " x 35
15 15
16
3. The Satin-Glow Lightbox is designed to
operate on 110V AC, 60 cycle. Please do
not use any other power source.
4. Removal of the back panel or tampering
with the electrical circuitry will void the
warranty and releases the manufacturer
from all responsibility for damages, loss
of property and/or personal injury.
4. Remove the hold-down screws and lift
off the light diffusers.
5. Remove and replace fluorescent tubes.
6. Return diffusers, glass and Plexiglas
panels to their original positions.
Re-install aluminum strips and screws.
Grand Prairie, TX
⁄ "
16
⁄ "
16
⁄ "
16
⁄ "
16
www.alvinco.com
