Bottom View; Zoom Width - Humminbird 141c Operation Manual

bottom and structure on the display. Structure ID® represents weak returns in blue and
strong returns in red. WhiteLine® highlights the strongest sonar returns in white
resulting in a distinctive outline. This has the benefit of clearly defining the bottom on
the display (See Bottom Presentation for more information).
To adjust the Bottom View:
1. Highlight Bottom View on the Sonar menu.
2. Use the LEFT or RIGHT 4-Way Cursor Control keys to change the Bottom View
setting. (Structure ID, WhiteLine, Default = Structure ID)
To change the Zoom Width Setting:
1. Highlight Zoom Width on the Sonar main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the Zoom Width
setting. (Narrow, Medium, Wide, Default = Wide)

Bottom View

Bottom View selects the method used to represent

Zoom Width

Zoom Width adjusts the width of the Zoom window on
the Sonar Zoom View.
29
