- Page 1 12.1" Liquid Crystal Display 2F, No.362, Jui-Kuang Rd., Neihu District, Television Taipei City 114, Taiwan, R.O.C. TEL: 886-2-87520000 ST29-12A1 FAX: 886-2-87527092 www.hannspree.com User's Manual NTSCTVTWEN1203 MAC-001081...
-
Page 3: Table Of Contents
Table of Contents 1. Warranty and Service ............ 3 2. Preface ................. 4 3. Description of Warning Symbols ........5 4. Safety Notices ............... 6 5. Regulatory Information ..........14 6. Introducing the TV ............16 Features ..............16 7. Checking Package Contents ........17 8. - Page 4 Table of Contents 11. Adjusting On-Screen Display (OSD) Settings ....30 OSD Setting Menus ..........30 Picture Setting ............31 Brightness ............32 Contrast ............. 33 Sharpness ............34 Hue ..............35 Saturation ............36 Color ..............37 Preset ..............38 Audio Setting ............
-
Page 5: Warranty And Service
TV). With this product, you will be able to enjoy superior audio and video while enriching your lifestyle with advanced technology. The Hannspree TV is warranted for one year limited service from the date the product is received (as shown on the Warranty and Service Manual);... -
Page 6: Preface
No part of this documentation may be reproduced in any form by any means without prior written authorization of Hannspree, Inc., and its licensors, if any. -
Page 7: Description Of Warning Symbols
Description of Warning Symbols Warning Caution This symbol is used to remind This symbol is used to remind users to pay attention to users to pay attention to the important descriptions regard- danger of electric shocks due ing usage and maintenance to dangerous internal non- (repair) or additional impor- insulated components. -
Page 8: Safety Notices
Safety Notices Power Supply Safety Notes 1. To avoid electric shocks, do not use an extended power cord or an outlet that does not match this product's plug or leaves the plug exposed. 2. This product has a 3-pin grounded plug. The third pin connects to ground;... - Page 9 Before You Proceed 1. Read the Safety Notices and the User’s Manual carefully before turning the product on. 2. Keep your User’s Manual in a safe place for future reference. Keep the box and packaging in case the product needs to be shipped in the future.
- Page 10 Optimal Viewing Area...
-
Page 11: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 12 10. Protect the power cord from being walked on or pinched particularly at the plug, conve- nience receptacles, and the point where they exit from the apparatus. 11. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
-
Page 13: Personal Safety
Personal Safety To avoid overloading the power supply, do not plug too many electrical devices into an outlet or extension cable. Dangerous high-voltage electric power compo- nents are located inside the TV. To avoid electric shock, do not disassemble the casing. Do not place or drop metals, small objects, or flammable materials in the vent to avoid an elec- tric shock or a fire. - Page 14 Installation To avoid damage to power circuits, do not place the TV in locations where there is excessive steam or dust. Do not place the TV on a bed, sofa, carpet, or in a sealed cabinet to avoid blocking the product's vents.
- Page 15 Operation This product is designed for power sources as labeled on the casing. Avoid using any other power accessories to avoid electric shock or other damage. The plug can be inserted into an outlet in only one direction. Notify a qualified service techni- cian if you cannot plug it in correctly.
-
Page 16: Regulatory Information
Regulatory Information FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is sub- ject to the following two conditions: (1) This device may not cause harm- ful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 17: Doc Compliance Notice
DOC Compliance Notice This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.This device complies with Canada ICES-003 Class B. CE Conformity Statement This device complies with the requirements set out in the Council Direc- tive on the approximation of the Laws of the Member States relating to... -
Page 18: Introducing The Tv
Introducing the TV Thank you for purchasing this Liquid Crystal Display TV. Your TV is designed to be safe, versatile, and easy to use. The boombox design makes it a fun addition to any room. You can watch standard NTSC television channels, and easily connect a VCR, VCD, or DVD player to the standard CVBS and S-Video input ports... -
Page 19: Checking Package Contents
Checking Package Contents Make sure the following components are included in the box. Contact your vendor immediately if anything is missing or damaged. User’s Manual Quick Start Guide Warranty and Service Manual Wire Material Package Power Cord Power Adapter 4-in-1 Cable... -
Page 20: Getting To Know Your Tv
Getting to Know Your TV Front View Handle Description Function Headphone line out Connects to headphones. Signal sensor Point the remote control at this sensor. Selects the input source to be displayed Source (TV, AV1, or AV2). Channel up(CH ): Increases the channel number. - Page 21 Description Function Volume up (VOL+): Increases the Adjust volume volume. Volume down (VOL–): Decreases the volume. Turns the on-screen display (OSD) Menu menus on and off. Power Turns the TV on and off. Power LED Green LED indicates power on. Speakers Output audio content.
-
Page 22: Input And Output Ports
Input and Output Ports Description Function Use the included 4-IN-1 Audio/Video cable to connect external devices, such as a VCR, VCD, or DVD player. Audio Input: AV connectors white and red audio cables. Video Input: AV connector video (yellow) or S-Video cables. - Page 23 Description Function Use the AV1 input to connect an external device, such as a VCR, or a VCD, or DVD player. Audio Input: AV connector white and red audio cables. Video Input: AV connector video (yel- low) cable. DC-IN Connects to the included power adapter. Antenna/cable TV Connects to an antenna or CATV cable line in...
-
Page 24: Getting Started
Getting Started Connecting to an Antenna or Cable TV Connect one end of the VHF/UHF (Antenna) or CATV cable to the ANT Jack (VHF/UHF IN Jack) on the back of the TV. Connect the other end of the VHF/UHF (Antenna) or CATV cable to the Antenna or CATV socket. -
Page 25: Connecting To Av Devices
Connecting to AV Devices Connect external devices such as VCD/DVD players or VCRs to the TV using the AV1 and AV2 ports on the back of the TV. Connecting to a VCR, VCD or DVD Player The illustration presented here shows you how to connect your TV to a VCR, VCD or DVD player. -
Page 26: Connecting To A Video Camera
Connecting to a Video Camera The following illustration shows you how to connect the TV to a camcorder. Actual connections may vary according to the make and model of the device. Refer to the user’s manual included with the camcorder for more detailed instructions. S-Video connector 4-in-1 cable... -
Page 27: Connecting Headphones
Connecting Headphones Headphones may be used to listen to the TV instead of using the built-in speakers. Connect headphones to the headphone line out port as illustrated. Headphones Headphone line out port Notes • Headphones are not included with the product. •... -
Page 28: Connecting The Power Adapter
Connecting the Power Adapter Connect the power cord to the power adapter as illustrated. Plug the power adapter connector into the DC-IN on the rear panel of the TV. Plug the three-pronged plug at the other end of the power cord into a power outlet. -
Page 29: Using The Tv
Using the TV Using the Remote Control For best results, use the remote control within a distance of 5 meters (16 feet) from the front of the TV’s signal sensor. Do not exceed an angle of 30 degrees when pointing at the signal sensor. Refer to the following illustration. -
Page 30: Turning The Tv On And Off
Turning the TV On and Off Press the POWER button on the remote control or on the TV control panel. The power LED indicator on CH 33 the front of the TV changes from red to green, indicating that the power is Press the POWER button again. -
Page 31: Switching Source Signals
Switching Source Signals Press the button to select SOURCE different source signals. CH, AV1, and AV2 appear on the CH 33 top right corner of the screen in that order. Note The TV supports S-Video input in addi- tion to normal video and audio signals. The TV detects the signal type auto- matically and gives priority to S-video when two signals are detected at the... -
Page 32: Adjusting On-Screen Display (Osd) Settings
Adjusting On-Screen Display (OSD) Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust your TV's settings. This chapter describes how to change each of the available settings. The OSD can be used with either the front control panel or remote control. Button Descriptions Front Panel Control Menu... -
Page 33: Picture Setting
Picture Setting MAIN MENU PICTURE AUDIO CUSTOMIZE ENTER ENTER MENU MENU Press MENU to enter the OSD Press the VOL UP button to enter Main Menu screen. the PICTURE Menu. Note You can operate the OSD with either the remote control or the front panel control. -
Page 34: Brightness
Brightness Press the VOL UP button. The PICTURE MENU brightness slide bar appears. BRIGHTNESS BRIGHTNESS CONTRAST SHARPNESS SATURATION COLOR NEUTRAL PRESET ENTER ENTER MENU MENU Press the VOL UP button to BRIGHTNESS BRIGHTNESS increase the brightness. Press the VOL DOWN button to decrease the brightness. -
Page 35: Contrast
Contrast Press the CH DOWN button to select PICTURE MENU CONTRAST. BRIGHTNESS CONTRAST Press the VOL UP button. The SHARPNESS contrast slide bar appears. SATURATION COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to CONTRAST CONTRAST increase the contrast. -
Page 36: Sharpness
Sharpness Press the CH DOWN button to select PICTURE MENU SHARPNESS. BRIGHTNESS CONTRAST Press the VOL UP button. The SHARPNESS sharpness slide bar appears. SATURATION COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to SHARPNESS SHARPNESS increase the sharpness. -
Page 37: Hue
Press the CH DOWN button to select PICTURE MENU HUE. BRIGHTNESS CONTRAST Press the VOL UP button. The hue SHARPNESS slide bar appears. SATURATION COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to increase the hue toward the green end of the spectrum. -
Page 38: Saturation
Saturation Press the CH DOWN button to select PICTURE MENU SATURATION. BRIGHTNESS CONTRAST Press the VOL UP button. The SHARPNESS saturation slide bar appears. SATURATION COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to SATURATION SATURATION increase the saturation. -
Page 39: Color
Color Press the CH DOWN button to PICTURE MENU BRIGHTNESS select COLOR. CONTRAST SHARPNESS Press the VOL UP button. The SATURATION current setting appears blinking in COLOR NEUTRAL PRESET the brackets. MENU MENU Neutral Color PICTURE MENU BRIGHTNESS Press the VOL UP button to select CONTRAST NEUTRAL, then press MENU. -
Page 40: Preset
Preset Press the CH DOWN button to PICTURE MENU select PRESET. BRIGHTNESS CONTRAST SHARPNESS Press the VOL UP button. “OK” SATURATION appears in the brackets. All picture COLOR NEUTRAL PRESET settings are returned to the factory- ENTER ENTER ENTER ENTER MENU MENU MENU... -
Page 41: Audio Setting
Audio Setting MAIN MENU PICTURE AUDIO CUSTOMIZE ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the CH UP / DOWN button to select AUDIO. Press MENU to enter the OSD Main Menu screen. Press the VOL UP button to enter the Audio Menu. -
Page 42: Treble
Treble Press the VOL UP button. The AUDIO MENU treble slide bar appears. TREBLE BASS BALANCE ENHANCE PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to TREBLE TREBLE increase the treble. Press the VOL DOWN button to decrease the treble. -
Page 43: Bass
Bass Press the CH DOWN button to select BASS. AUDIO MENU TREBLE Press the VOL UP button. The bass BASS BALANCE slide bar appears. ENHANCE PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to BASS BASS increase the bass. -
Page 44: Balance
Balance Press the CH DOWN button to select AUDIO MENU BALANCE. TREBLE Press the VOL UP button. The BASS BALANCE balance slide bar appears. ENHANCE PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL DOWN button to shift BALANCE BALANCE the balance to the left speaker. -
Page 45: Enhance
Enhance Press the CH DOWN button to select AUDIO MENU ENHANCE. TREBLE Press the VOL UP button to enter the BASS BALANCE setting field. ENHANCE PRESET Press the VOL UP button to turn ENTER ENTER ENTER ENTER MENU MENU MENU MENU enhance on or off. -
Page 46: Tv Setting
TV Setting MAIN MENU PICTURE AUDIO CUSTOMIZE ENTER ENTER MENU MENU Press the CH UP / DOWN button to select TV. Press MENU to enter the OSD Main Menu screen. Press the VOL UP button to enter the TV Menu. Note You can operate the OSD with either the remote control or the front panel control. -
Page 47: Tv/Catv
TV/CATV Press the VOL UP button. The MENU current setting appears flashing in TV/CATV CATV ADD/ERASE the brackets. AUTO PROGRAM ENTER ENTER MENU MENU Receiving Cable TV MENU Press the VOL UP button to select TV/CATV CATV CATV, then press MENU. “CATV” ADD/ERASE AUTO PROGRAM appears in the brackets. -
Page 48: Channel Add/Erase
Channel Add/Erase Press the CH DOWN button to MENU select CH ADD/ERASE. TV/CATV CATV ADD/ERASE Press the VOL UP button. The OSD AUTO PROGRAM menu display switches to the ENTER ENTER MENU MENU following screen. Press the CH UP / DOWN button on the front panel to select a channel. -
Page 49: Auto Program
Auto Program Press the CH DOWN button to MENU select AUTO PROGRAM. TV/CATV CATV ADD/ERASE AUTO PROGRAM ENTER ENTER MENU MENU Press the VOL UP button to begin auto programming. The screen AUTO PROGRAM displays channels incrementally as the TV scans for available channels. -
Page 50: Customize Setting
Customize Setting MAIN MENU PICTURE AUDIO CUSTOMIZE ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press MENU to enter the OSD Press the CH UP / DOWN Main Menu screen. button to select CUSTOMIZE. Press the VOL UP button to enter the Customize Menu. -
Page 51: Sleep Timer
Sleep Timer The sleep timer turns the TV off automatically after a set time. Press the VOL UP button to select CUSTOMIZE MENU a value: OFF, 30, 60, 90, or 120 SLEEP TIMER TIMEOUT minutes. LANGUAGE ENGLISH ENTER ENTER MENU MENU Press MENU to confirm your CUSTOMIZE... -
Page 52: Osd Timeout
OSD Timeout This setting allows you to set the length of time the OSD menus appear on the screen when a button is not pressed. Press the CH DOWN button to CUSTOMIZE MENU select OSD TIMEOUT. SLEEP TIMER TIMEOUT Press the VOL UP button. The LANGUAGE ENGLISH +ADJ... -
Page 53: Taking Care Of Your Tv
Taking Care of Your TV Turn the power off before you begin cleaning the For best results, use a clean lens cloth to remove dust and fingerprints from the screen. Do not wipe the shell of the TV with alcohol, methanol, gasoline or oil products to avoid damaging the finish. -
Page 54: Troubleshooting
Troubleshooting Situation Solution • Connect the power cord properly. • Press the POWER button on the con- trol panel or remote control. • Press the SOURCE button to cycle through connected video sources. • Press the Channel up or channel No picture and sound. - Page 55 Situation Solution • If OSD items are colored light blue, the system is in a state such that Cannot operate menus. those settings are not available. For example, video setting is available in TV mode. • Make sure the video signal cable is No image but have sound.
-
Page 56: Specifications
Specifications ST29-12A1 LCD Panel Size 12.1-inch TFT Aspect Ratio Best Resolution 800 (horizontal) x 600 (vertical) Maximum Display Area 246.0 mm (H) x 184.5 mm (V) TV System NTSC AV1: Composite Video (RCA jack; yellow) Video System AV2: mini-DIN 10-pin (Composite + S- Video) AV1: L/R RCA jacks (audio input) AV2: mini-DIN 10-pin L/R RCA jacks (audio... -
Page 57: Glossary
Glossary Aspect Ratio The ratio of width to height of a film, image or display screen. Broadcast TV Broadcasting video signals using high-frequency electromagnetic waves to distribute television channels to viewers (standard TV broadcast). CATV Community Antenna Television, the original name for cable TV. A television distribution system that uses coaxial cable instead of the traditional radio broad- casting (over-the-air) method to deliver television, FM radio, and other services to consumers.
