Genelec 5051A Operating Manual page 7

SyStem SpecificAtiOnS
Free field frequency response (± 3 dB)
Maximum short term sine wave SPL output
averaged from 30 to 85 Hz, measured in half
space at 1 meter
Self generated noise level in half space at 1 m
on axis (A-weighted)
Driver, magnetically shielded
Weight
Dimensions
Height
Diameter
AmplifieR SectiOn
Amplifier short term output power
(Long term output power is limited by driver
unit protection circuitry)
Amplifier system THD at nominal output
Mains voltage
Power consumption (average)
Stand by
Idle
Full output
cOnnectORS
5051A
Main 27 Hz...85 Hz Main channels IN/OUT, LFE channel IN unbal-
LFE 27 Hz...120 Hz
anced female RCA connectors
102 dB
Stereo IN/OUT balanced XLR connectors
≤ 15 dB SPL
205 mm (8")
Input impedance
9.8 kg (21.6 lb)
300 mm (11 13 / ")
16
362 mm (14 / ")
1
4
cROSSOVeR SectiOn
5051A
150 W
Subsonic filter (18 dB/octave) below
Crossover frequency
(subwoofer/main channels)
≤ 0.05 %
LFE channel cutoff frequency
100, 120 or 230 V
Midband rejection >400 Hz
Input level for 90 dB SPL output at 1 m
0.5 VA
12 VA
120 VA
Sensitivity adjustment range
Bass Roll-Off control operating range
in 2 dB steps
Phase matching control in 90° steps
Pin
Ring
Pin 1
Pin 2
Pin 3
5051A
+
gnd
gnd
+
-
10 kOhm balanced
5051A
27 Hz
85 Hz
120 Hz
>50 dB
-18 dBu at level control
max
18 dB
From 0 to -6 dB @ 27 Hz
From 0 to -270° @ 85 Hz
