1030A Data Sheet
SYSTEM SPECIFICATIONS
1030A
Lower cut-off frequency, -3 dB < 52 Hz
Upper cut-off frequency, -3 dB > 20 kHz
Free field frequency response 55 Hz - 18 kHz (± 2.5 dB)
Maximum short term sine wave acoustic
output on axis in half space, averaged
from 100 Hz to 3 kHz @ 1 m > 105 dB SPL
@ 0.5 m > 111 dB SPL
Maximum long term RMS acoustic
output in same conditions with
IEC-weighted noise (limited by driver @ 1 m > 99 dB SPL
unit protection circuit) @ 0.5 m > 105 dB SPL
Maximum peak acoustic output per pair
@ 1 m from the engineer with music
material > 115 dB
Self generated noise level in free field
@ 1 m on axis < 10 dB (A-weighted)
Harmonic distortion at 90 dB SPL Freq:
@ 1 m on axis
Drivers Bass
Treble
Both drivers are magnetically shielded
Weight
7,6 kg (17 lb)
Speaker dimensions Height
Width
Depth
Note that the cable connectors require additional
100 mm (4") of space behind the speaker cabinet.
Genelec Document BBA30001a. Copyright Genelec Oy 9.2003. All data subject to change without prior notice
60...150 Hz < 3%
> 150 Hz < 0.5%
170 mm (6 1/2") cone
19 mm (3/4") metal dome
312 mm (12 1/4")
200 mm ( 7 7/8")
240 mm (9 7/16")
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
AMPLIFIER SECTION
1030A
Bass amplifier output power with
an 4 Ohm load Short term 80 W
Treble amplifier output power with
an 8 Ohm load Short term 50 W
Long term output power is limited by driver unit
protection circuitry.
Amplifier system distortion at THD
nominal output SMPTE-IM
CCIF-IM
DIM 100
Signal to Noise ratio, Bass
referred to full output Treble
Mains voltage: 230, 100/200 or 115/230 V
according to region
Voltage operating range: ±10%
Power consumption Idle
Full output
CROSSOVER SECTION
1030A
Input connector: XLR female pin 1 gnd
pin 2 +
pin 3 -
Input impedance 10 kOhm balanced
Input level for 100 dB SPL output @ 1m variable from +6 to -6 dBu
Input level for maximum short term sine variable from +11 to -1 dBu
wave output of 105 dB SPL @ 1m
Subsonic filter below 50 Hz 18 dB/octave
Ultrasonic filter above 25 kHz 12 dB/octave
Crossover frequencies Bass/Treble 3.5 kHz
Crossover acoustical slopes 24 - 32 dB/octave
Treble tilt control operating range in +2 to -4 dB & MUTE
2 dB steps
Bass roll-off control operating range in from 0 to -8 dB @ 50 Hz
2 dB steps
Bass tilt control operating range in from 0 to -6 dB @ 100 Hz & MUTE
2 dB steps
The 'CAL ' position is with all tone controls set to 'off'
and input sensitivity control to maximum and
corresponds to a maximally flat free field response.
In the U.S. please contact
Genelec, Inc., 7 Tech Circle
Natick, MA 01760, U.S.A
Phone 508 652 0900
Fax 508 652 0909
Email genelec.usa@genelec.com
<0.08%
<0.08%
<0.08%
<0.08%
>95 dB
>95 dB
10 VA
100 VA
