Genelec 1032B Operating Manual page 4

1032B Operating Manual
AUDIO PRECISION 1032anec
LEVEL(dBr)
95
90
85
80
75
70 100
65
95
90
85
80
20 100
Figure 4. The upper curve group shows the horizontal directivity
characteristics of the 1032B in vertical configuration measured at 1 m.
The lower curve is a 1/3 octave band power response, measured in an
IEC approved reverberation chamber.
SYSTEM SPECIFICATIONS
Lower cut-off frequency, -3 dB:
Upper cut-off frequency, -3 dB:
Free field frequency response of system:
42 Hz - 21 kHz (±2.5 dB)
Maximum short term sine wave acoustic output on
axis in half space, averaged from 100 Hz to 3 kHz:
@ 1m > 113 dB SPL
@ 0.5m > 119 dB SPL
Maximum long term RMS acoustic output in same
conditions with IEC weighted noise (limited by
driver unit protection circuit):
@ 1m >103 dB SPL
@ 0.5m >109 dB SPL
Maximum peak acoustic output per pair above
console bridge, @ 1 m from the listening position
with music material:
Self generated noise level in free field @ 1m
on axis: < 10 dB (A-weighted)
Harmonic distortion at 90 dB SPL @ 1m on axis:
Freq: 50...100 Hz
> 100 Hz
Drivers: Bass 10" (250 mm) cone
Treble 1" (25 mm) metal dome
Both drivers are magnetically shielded.
Weight: 21,7 kg (48 Ib.)
Dimensions:
1
Height 495 mm (19
Width 320 mm (12 5
7
Depth 290 mm (11
Genelec Document D1032R001 Copyright Genelec Oy 2.2013. All data subject to change without prior notice
vs
FREQ(Hz) 02 FEB 93 18:56:42
0°
15°
30°
45°
1k 10k 20k
CROSSOVER SECTION
<40 Hz Input connector XLR female:
>22 kHz
Input impedance:
Input level for 100 dB SPL output @ 1m:
Input level for maximum short term sine wave output
113 dB SPL @1m:
Subsonic filter below 40 Hz :
Ultrasonic filter above 25 kHz:
Crossover frequency, Bass/Treble:
> 124 dB
Crossover acoustical slopes:
Treble tilt control operating range in 2 dB steps:
< 1%
< 0.5% Bass roll-off control operating range in 2 dB steps:
Bass tilt control operating range in 2 dB steps:
The 'CAL' position is with all tone controls set to 'off'
/ ") and the input sensitivity control to maximum (fully
2
/ ") clockwise).
8
/ ")
16
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
AUDIO PRECISION 1032anec LEVEL(dBr)
95
90
BASS TILT
85
80
90
85
80
BASS ROLL-OFF
75
70
65
60
20 100
Figure 5. The upper curve group shows the effect of the bass tilt
control on the free field response. The lower curves show the effect
of the treble tilt and bass roll-off controls.
Bass amplifier short term output power with a
pin 1 gnd 4 Ohm load:
pin 2 +
pin 3 -
Treble amplifier short term output power with an
10 kOhm balanced 8 Ohm load:
variable from +6 to -6 dBu Long term output power is limited by driver unit
protection circuitry.
Slew rate
variable from +19 to +7 dBu
Amplifier system distortion at
18 dB/octave nominal output:
12 dB/octave
1.8 kHz
Signal to Noise ratio, referred to full output:
24 - 32 dB/octave
from +2 to -4 dB & MUTE Mains voltage:
from 0 to -8 dB @ 40 Hz
Voltage operating range:
Power consumption:
from 0 to -8 dB @ 80 Hz
& MUTE
In the U.S. please contact:
In China please contact:
Genelec, Inc., 7 Tech Circle
Beijing Genelec Audio Co. Ltd.
Natick, MA 01760, USA
Jianwai SOHO, Tower 12, Room 2605
Phone +1 508 652 0900
39 East 3rd Ring Road
Fax +1 508 652 0909 Chaoyang District
Email genelec.usa@genelec.com
Beijing 100022, China
Phone +86 10 5869 7915, Fax +86 10 5869 7914
FREQ(Hz) 02 FEB 93 18:51:59
vs
TREBLE TILT
1k 10k
AMPLIFIER SECTION
180 W
120 W
80V/µs
THD < 0.05%
SMPTE-IM < 0.05%
CCIF-IM < 0.05%
DIM 100 < 0.05%
Bass > 100 dB
Treble > 100 dB
230, 100/200 or 115/230V
according to region
±10%
Idle 20 W
Standby <0.5 W
Full output 200 W
