2–Site Planning
Power
Figure 2-1. 12800-Series Power Distribution examples
NOTE:
Power strips are not supplied by QLogic
Region/Countr
North America
North America
North America
2-4
Table 2-1. AC Plug Types
Voltage
y
Rating
100-127
200-240
200-240
Plug Type
Misc/Notes
NEMA
5-20P
NEMA
L6-20P
NEMA
Three phase AC
L15-30P
IB0054611-00 A
