Site Planning

Moving Considerations

Dimension of pallet/container for all models
Mechanical lift for x360 & x180
WARNING!!
To avoid injury, do not lift manually when fully loaded. The 12800-180, when
fully-populated, weighs 270lbs (125kg). The 12800-120 weighs 199 lbs (91
kg). Use a mechanized lift only. For a manual lift, unload the product to
minimize the weight (an empty chassis weighs 100lbs/45kg). Use a team of
people appropriate to the weight of the product and in conjunction with
applicable laws and guidelines.
WARNING!!
To avoid injury, install the 12800-360 using a mechanized lift only. When
fully-populated, the switch weighs 535lbs (244kg) (an empty chassis weighs
197lbs/90kg).
Lifting considerations for x040 and edges
WARNING!!
To avoid injury, use a team of people appropriate to the weight of the
product and in conjunction with applicable laws and guidelines. The
12800-040, when fully-populated, weighs 95lbs (43kg).
IB0054611-00 A
12800-120: 26" x 36"
12800-180: 26" x 36"
12800-360: 40" x 36"
2-1
