1
QLogic 12000 Series
Hardware Overview
NOTE:
The 12000 series products are shipped fully assembled and tested.

Physical Specifications

Model #
Height (rack
units/inches)
Depth
(without
cables)
Width
Max weight
(lb./kg.)

Environmental Specifications

Operating temperature:
Non-operating temperature:
Relative humidity (non-condensing):
IB0054611-00 A
Table 1-1. 12000 Physical Attributes
12200 12300
1U/1.75" 1U/1.75"
14.5"
(362.5mm)
15/6.8 20/9.1
5° - 40°C (41° - 104°F) at sea level, altitude derating 1°C (34°F) per
300m to 2,400m (984ft to 7874ft)
-40° to 65°C (-40° to 149°F)
Operating 5% - 85%; Non-operating 5% - 90%
12800-040 12800-120 12800-180
5U/8.75" 10U/17.5"
25.75" (654mm)
17.3" (440mm)
100/45.5 155/70.5
12800-360
14U/24.5" 29U/50.75"
285/129.3 536/243.1
1-1
