imagine the possibilities
Thank you for Durcnaslng this Samsung product.
To receive more complete service, olease register
your broduct at
www.samsun g.com/register
Mode
Serial No.

Advertisement

Table of Contents

   Related Manuals for Samsung UN46C6800

   Summary of Contents for Samsung UN46C6800

  • Page 1 Samsung Electronics America, Inc. 105 Challenger Road Ridgefield Park, NJ 07660-0511 imagine the possibilities Thank you for Durcnaslng this Samsung product. To receive more complete service, olease register your broduct at www.samsun g.com/register Mode Serial No. © 2010 Samsung Electronics Co., Ltd.
  • Page 2 SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originallyspecified, and to the Original Purchaser only.
  • Page 3: Table Of Contents

    Contents • List of Features ............• Network Connection ..........• Accessories .............. Connecting to a Wired Network • Install the Stand ............Connecting to a Wireless Network • Media Play.............. • Viewing the Control Panel ......... Connecting a USB Device •...
  • Page 4 Intemet@l%_: You can use various internet services and view useful information and entertaining content (p, 42). • AliShare: AIIShare connects your TV and compatible Samsung mobile phones/devices through a network (p. 49), • Self Diagnosis: You can check to make sure picture and sound operate normally (p. 28), Please make sure the following items are included with your LED TV.
  • Page 5 See s eparate guide for i nstalling the stand. (M4 X LS) Follow the steps below to connect the TV to the stand. Screws(M4X LS) .._ T It 1F Topview ....Stand..Rear __ 1. Connect the Guide Stand to the Stand using four screws (M4 X LS) as shown. Screws(M4X LS) .
  • Page 6 Getting Started The product color and shape may vary depending on the model. Power Indicator SOURCE[_ MENU -- VOL+ CH A Speakers Remote control sensor Aim the remote control towards this spot on the TV. Remote control sensor Blinks and turns off when the power is on and lights up in standby mode. Power Indicate- Toggles between all the available input sources.
  • Page 7 (p. 18-_19). and Anynet+ (HDMI-CEC) modes FAV, CH: Displays FavoriteChannel Lists (p. 32, 39). on the screen (p. 13). Controls recording for Samsung RSIZE: Selects the picture size (p. 16). recorders that have the Anynet+ CC: Controls the caption decoder feature) (p.
  • Page 8 Getting Started When the TV is initially powered on, basic settings proceed automatically. The product color and shape may vary depending on the model. Connecting the power cord and antenna. VHF/UHF Antenna PowerInput When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWER (b button.
  • Page 9 Connections Using an HDMI or HDMI/DVI cable: HD connection (up to 1080p) We recommend using the HDMI connection for the best quality HD picture. Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver HDMt Cable/Not Supplied/ H ©fv}] to O\8 Cable (Not Supp_led} White Audio Cable(Not S upplied)
  • Page 10 Connections Using an OpticaJ (Digital) or Audio (Analog) Cable Connection Available devices: Digital Audio System, Amplifier, DVD home theater Audio Cable/Not SuppJied) DIGITAL AUDIO OUT (OPTICAL} * When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL} jack, decrease the volume of both the TV and the system, * 5,1 OH (channel) audio is available when the TV is connected to an external device supporting 5,1 OH.
  • Page 11 Using an HDMI/DVI Cable or a D-sub Cable HDMI to DVI Cable (Not Supplied) Display Modes (D-Sub and HDMm/DVm Input) Optimal resolution is 1920 X 10S0 @ G0 Hz. 640 x 350 31.469 70.086 25.175 720 x 400 31.469 70.087 28.322 640 x 480 35.000...
  • Page 12 Connections Edit Name MENU rlTl _ input _ Edit Name _ ENTERI_ Source List VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / DVI Use to select TV or an external input sources SOURCE Devices / TV / IPrv / Bin-ray / HD DVD / DMA: Name...
  • Page 13: Seeing Channels

    Using Favorite Channels MENUITTI _ Channel _ Channel List _ ENTERI_ Seeing Channels Add to Favorite / Delete from Favorite Channel List Add, delete or set Favorite channels and use the program guide for digital broadcasts. Select a channel and press the TOOLS button. MENU rlTI _ Channel _ Channel List Add or delete a channel using the Add to Favorite or ENTERI_...
  • Page 14: Channel Menu

    Basic Features * After all the available channels are stored, it starts Timer Viewing: You can set a desired channel to be to remove scrambled channels. The Auto Program displayed automatically at the reserved time. Set the current time first to use this function. menu then reappears.
  • Page 15: Changing The Preset Picture Mode

    / Brightness (Advanced Settings are available in Standard / Movie mode) Sharpness!Color!Tint(G!R) ................. Compared to previous models, new Samsung TVs have a Your television has several setting options for picture quality more precise picture. control. In PC mode, you can only make changes to Dynamic...
  • Page 16: Picture Menu

    Basic Features Black Tone (Off / Dark / Darker / Darkest): Select the xvYCC (Off/On): Setting the xvYCC mode on black level to adjust the screen depth. increases detail and color space when watching movies from an external device (e.g. BD/DVD player) connected Dynamic Contrast (Off / Low / Medium / High): Adjust to the HDMI or Component IN jacks.
  • Page 17: Setting Up The Tv With Your Pc

    Screen Fit: D isplays the full i mage without any c ut-off MPEG Noise Filter (Off / Low / Medium / High / when HDMI (720p / 1080i / 1080p) or Component Auto): Reduces MPEG noise to provide improved (1080i / 1080p) signals are inputted. picture quality.
  • Page 18: Changing The Preset Sound Mode

    PC will probably look different, but the same basic set-up information will apply in most cases. MENUrrrl _ Sound --_ ENTERI_ (If not, contact your computer manufacturer or Samsung Dealer.) Click on "Control Panel" on the Windows start menu.
  • Page 19: Setting The Time

    Multi-Track Sound (MTS) (analog channels only) Setting the Time Mono: Choose for channels that are broadcasting in mono or if you are having MENUrlTI -_ Setup -_ Time -_ ENTERE_ difficulty receiving a stereo signal. Stereo: Choose for channels that are Time broadcasting in stereo.
  • Page 20: Setting The On / Offtimer

    Basic Features Setting the On / Off Timer Locking Programs MENUFITI _ Setup _ Time _ Timer 1 MENU iTrl _ Setup -_ Security -_ ENTERE_ ENTER I_ You can set the TV to turn on automatically at a preset time. Security Timer 1 / Timer 2 / Timer 3: Three different on / off The PIN input screen appears, Enter your 4 digit PIN number.
  • Page 21: Other Features

    The V -Chip will automatically block any * Even if you set the on-screen display to another category that deals with more sensitive material. language, the Downloadable U.S. Rating For e xample, ifyou block the PG-13 category, menu will appear in English only. then R ,N0-17 and Xwill a utomatically * The rating will automatically block certain blocked.
  • Page 22: Setup Menu

    W!reless Remote Control (Off / On) and the Background Opacity to Transparent, Turn on/off or give permission to Samsung mobile phones/ devices. You must have a Samsung Mobile phone/device which supports Wireless Remote Control. For more details, refer to each device's manual.
  • Page 23: Sound Menu

    Yes. There may be a * You may notice that the picture in the PIP window problem with the TV. Contact Samsung's Call Center for becomes slightly unnatural when you use the main assistance (1-800-SAMSUNG).
  • Page 24 Software Upgrade can be performed by network Refer to this information when connecting external devices to the T_. connection or downloading the latest firmware from "www. samsung.com," to a USB memory device. Current Version - the software already installed in the TV. Contact Samsung Software is represented as "Year/Month/DayVersion".
  • Page 25: Network Connection

    Advanced Features You can set up your 77/so that it can access the Internet through your local area network (LAN) using a wired or wireless connection. Connecting to a Wired Network You can attach your 77/to your LAN using cable in three ways: •...
  • Page 26 Advanced Features Network SetuP(Auto )........................Network Setup (Manual) ........ Use the Automatic Network Setup when connecting your Use the Manual Network Setup when connecting your TV to TV to a network that supports DHCR To set up your TV's a network that requires a Static IP address. cable network connection automatically, follow these steps: Getting the Network Connection Values How to set up automatically...
  • Page 27: Connecting To A Wireless Network

    Configuration) or PIN (Personal Identification Number), WPS will automatically configure the SSID and WPA key in either mode. " If your router, modem, or device isn't certified, it may not connect to the TV via the "Samsung Wireless LAN Adapter." " Connection Methods: You can setup the wireless network connection six ways.
  • Page 28 Notice The picture may appear corrupted or have static for some channels when the TV is connected to the Samsung Wireless LAN Adapter. In such a case, establish a connection using one of the following methods or connect the Samsung Wireless LAN Adapter using a USB cable in a place that is not affected by radio interference.
  • Page 29 How to set up automatically Network SetuP (PBC 0NPS)) ..................To set up the wireless connection automatically, follow these steps: How to set up using PBC (WPS) Follow Steps 1 through 6 in the "How to set up using If your router has a PBC (WPS) button, follow these steps: PBO (WPS)"...
  • Page 30 On the dialog that appears, click the Support tab. You can connect to a mobile device without an access point through the "Samsung Wireless LAN Adapter" by using a On the Support tab, click the Details button. The peer to peer network.
  • Page 31 Link) ............Your TV may not be able to connect to the Internet This function lets you connect your TV to a Samsung device because your ISP has permanently registered the (router, etc,) that supports PBC (WPS). You can connect the MAC address (a unique identifying number) of your TV to the device even if a sharer is not connected to the TV.
  • Page 32: Media Play

    TV and the PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**) Using a LAN cable, connect between the external modem and the PC onto which the Samsung PC Share Manager Program will be installed.
  • Page 33 Divx DRM, Multi-audio, embedded captions are not supported. Samsung PC Share manager should be permitted by the firewall program on your PC. When you use Media Play mode through a network connection, depending on the functions of the provided server: * The sorting method may vary.
  • Page 34: Screen Display

    Advanced Features Screen Display Move to the desired file using the up/down/righ'dleft buttons and then press the ENTER[__ or FCq (Play) button. The file is played. Supports the View Devices and Home in Media Play homepage. You can ascertain the selected file name and the number of files and page.
  • Page 35 WMA sampling rate 22050Hz mono is not supported. Below 1280 x 720:60 frame max - Above 1280 x 720:30 frame max • GMC 2 over is not supported. • Only Samsung Techwin MJPEG is supported. • H.263is not supported. Eng,,sh...
  • Page 36 Advanced Features Playing movie continuously (Resume Play) If you exit the playing movie function, the movie can be played later from the point where it was stopped. If you press the ENTERI_ button (Chaptering) during playing the file, you can explore scene divided into 5 chapters you want.
  • Page 37: Playing Multiple Files

    Photos Viewing a Photo (or Slide Show) Press the 41 or I_ button to select Photos, then press the ENTER[_ button in the Media Play menu. Press the 41/_/A/T button to select the desired photo in the file list. Press the ENTERE_ button or [_q (Play) button. - While a photo list is displayed, press the Fcq (Play) / ENTER I_ button on the remote control to start the slide show.
  • Page 38 Advanced Features Videos/Music/Photos Play Option menu During file playback, press the TOOLS button. Title You can move directly to another Title. Repeat Mode You can play movie and mush fibs repeatedly. Picture Size You can adjust the picture size to your preference. (Model / Mode2 / Original) Pbture Setting You can adjust the picture setting.
  • Page 39 Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV's remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.
  • Page 40: Anynet

    * If you have selected external input mode by pressing the SOURCE button, you cannot use the Anynet+ function. Make sure to switch to an Anynet+ device by using the Device List, Recording You can make a recording of a TV Program using a Samsung recorder. Select Recording, When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed.
  • Page 41: Listening Through A Receiver

    Listening through a Receiver You can listen to sound through a receiver (i.e Home Theater) instead of the rv Speaker. Select Receiver and set to On. Press the EXIT button to exit. If your receiver supports audio only, it may not appear in the device list. The receiver will work when you have properly connected the optical in jack of the receiver to the DIGITAL AUDIO OUT (OPTICAL} jack of the TV.
  • Page 42: Getting Started With Internet@tv

    View -. Internet@TV --_ ENTER E_ Screen Display TV Screen: Recommended Applications: Dbplays tlse current channel. Displays the recommended service by Samsung. You are not able to add or delete a service in this list. information: Display applications, and advertisements brought to...
  • Page 43: Setting Up Internet@tv

    Account Login System Setup For an application with multiple accounts, use ,_ and I_ to Ticker Autorun (Off / On): You can set Ticker Autorun access the different accounts. to come on when powering on the TV. The Ticker application provides useful News, Weather, and Stock Market information.
  • Page 44 6. Accountcreated. You can use theservices p rovided The keypad QSD will be displayed on the screen. by all users of your Samsung TV with a single Using the Keypad Iogin by linking the users' account to the TV ID. if Pressing the = button on the remote while you are you want to register a service site ID, select Yes.
  • Page 45 Apps • Video: Displays various video media such as movies, TV shows and short length videos. Samsung Apps is a store for downloading applications to be • Sports: Displays various sports media such as match used on Samsung TV/AV equipment.
  • Page 46 Advanced Features Yahoo Engine. You can monitor financial stocks, share photos with friends and family, and track news and weather all through the Yahoo!® Widget Engine. When running Internet@TV for the first time, you will be prompted to configure the basic settings. Internet@TV provides an integrated Internet and television experience powered by the Yahoo!®...
  • Page 47: Profilewidget

    • From the Administrative Controls menu you can: PROFILE Widget - Configure the Screen Saver timeout to avoid screen Set up user profiles through Profile Widget. You can set up burn-in. multiple profiles, each with its own list of widgets. Use the - Create Owner PIN and set a Security Question to Switch Profile option to switch to a different user profile.
  • Page 48: Help Website

    Samsung may impose limits on the use of or access to certain services or content, in any case and without notice or liability.
  • Page 49 Media, or ScreenShare function. The Media function is available in all mobile devices About AIIShare which support AIIShare, AllShare connects your TV and compatible Samsung mobile Allowed / Denied: Allows/Blocks the mobile phone. phones/devices through a network. On your TV, you can Delete: Deletes the mobile phone from the list.
  • Page 50 * the warning popup window appears. Press the ENTERE_ button to select Allow, then you can use Media function on that device. Using your Samsung Phone to Operate Your TV Before you can use this feature, you must connect to a Samsung mobile phone that supports ScreenShare functions.
  • Page 51 Other Information Stand Type Enclose the cables in the Cable Tie so that the cables are not visible through the transparent stand. 7_W_W_W_W_W_W_W_W_W_W_W_W_W_WI_W_W_W_W_W_W_W_W_W_W_W_W_W77 .._ __ ..® ® Wall-Mount Type ® !: i!i Do not pull the cables too hard when arranging them. This may cause damage to the product's connection terminals. English 51...
  • Page 52 For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others ifyou elect to install the TV on your own.
  • Page 53 Do not i nstall your Wall Mount Kit w hile your TV isturned on. I tmay result inpersonal injury due t o electric shock. The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method TV Rear °°...
  • Page 54 Other Information Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang over or destabilize the TV; doing so may cause the TV to tip over, causing serious injuries or death, Follow all safety precautions provided on the included Safety Flyer,For added stability, install the anti-fall device for safety purposes, as follows.
  • Page 55 Ifthe TV seems tohave aproblem, first try this list ofpossible problems and s olutions. Ifnone ofthese troubleshooting tips apply, visit "www.samsung.com," then c lick onSupport, orcall Samsung customer service at1-800-SAMSUNG. Poo! picture Eirstof all, please perform the Picture Test and confirm that your TV is properly displaying test image.
  • Page 56 If you are using an HDMI connection, check the audio output setting on your PC. Network Connection The wireless network connection failed. • The Samsung Wireless USB dongle is required to use a wireless network. • Make sure the Network Connection is set to Wireless (p. 27). •...
  • Page 57 A "Mode Not Supported" message • Check the supported resolution of the T_, and adjust the external device's output resolution appears, accordingly. Referto the resolution settings on page 11 of this manual. Caption on TV menu is greyed out, • Caption can not be selected in the TV menu when connected via HDMI or Component (p.
  • Page 58 Other Information SrS_ TheaterSound, SRS and the <_ symbol are trademarks of SRS Labs, Inc. TheaterSound technology is incorporated under license form SRS Labs, Inc. TheaterSound DOLI3Y Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are EHGITALPLUS ] trademarks of Dolby Laboratories.
  • Page 59 Panel native 1920 x 1080 @60 Hz Environmental Considerations Operating Temperature 50°F to 104°F (10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to %0, non-condensing Stand Swivel (Left/Right) -20°...
  • Page 60 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your T_. Not responsible for typographical or printed errors. © 2010 Samsung Electronics America, Inc English...
  • Page 61: Aiishare

    AIIShare FAV, C H button 7, 13 Receiver Amplify Favorite Channel Recording Antenna Film Mode Remote Control Anynet+ Fine Tune Repeat Mode AVD_O OVT Flesh Tone RGB Only Mode Auto Adjustment Frequency Rotate Auto Volume HDMI 9, 39 Self Diagnosis Background Music Home Theater 10, 39...
  • Page 62 Samsung Electronics America, Inc. 105 Challenger Road Ridgefield Park, NJ 07660-0511 imagine the possibilities Thank you for Durcnaslng this Samsung product. To receive more complete service, olease register your broduct at www.samsun g.com/register Mode Serial No. © 2010 Samsung Electronics Co., Ltd.
  • Page 63 SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originallyspecified, and to the Original Purchaser only.
  • Page 64: Assembling The Cables

    Contents • List of Features ............• Network Connection ..........• Accessories .............. Connecting to a Wired Network • Install the Stand ............Connecting to a Wireless Network • Media Play.............. • Viewing the Control Panel ......... Connecting a USB Device •...
  • Page 65 Intemet@l%_: You can use various internet services and view useful information and entertaining content (p, 42). • AliShare: AIIShare connects your TV and compatible Samsung mobile phones/devices through a network (p. 49), • Self Diagnosis: You can check to make sure picture and sound operate normally (p. 28), Please make sure the following items are included with your LED TV.
  • Page 66 See s eparate guide for i nstalling the stand. (M4 X LS) Follow the steps below to connect the TV to the stand. Screws(M4X LS) .._ T It 1F Topview ....Stand..Rear __ 1. Connect the Guide Stand to the Stand using four screws (M4 X LS) as shown. Screws(M4X LS) .
  • Page 67 Getting Started The product color and shape may vary depending on the model. Power Indicator SOURCE[_ MENU -- VOL+ CH A Speakers Remote control sensor Aim the remote control towards this spot on the TV. Remote control sensor Blinks and turns off when the power is on and lights up in standby mode. Power Indicate- Toggles between all the available input sources.
  • Page 68 (p. 18-_19). and Anynet+ (HDMI-CEC) modes FAV, CH: Displays FavoriteChannel Lists (p. 32, 39). on the screen (p. 13). Controls recording for Samsung RSIZE: Selects the picture size (p. 16). recorders that have the Anynet+ CC: Controls the caption decoder feature) (p.
  • Page 69 Getting Started When the TV is initially powered on, basic settings proceed automatically. The product color and shape may vary depending on the model. Connecting the power cord and antenna. VHF/UHF Antenna PowerInput When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWER (b button.
  • Page 70 Connections Using an HDMI or HDMI/DVI cable: HD connection (up to 1080p) We recommend using the HDMI connection for the best quality HD picture. Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver HDMt Cable/Not Supplied/ H ©fv}] to O\8 Cable (Not Supp_led} White Audio Cable(Not S upplied)
  • Page 71 Connections Using an OpticaJ (Digital) or Audio (Analog) Cable Connection Available devices: Digital Audio System, Amplifier, DVD home theater Audio Cable/Not SuppJied) DIGITAL AUDIO OUT (OPTICAL} * When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL} jack, decrease the volume of both the TV and the system, * 5,1 OH (channel) audio is available when the TV is connected to an external device supporting 5,1 OH.
  • Page 72 Using an HDMI/DVI Cable or a D-sub Cable HDMI to DVI Cable (Not Supplied) Display Modes (D-Sub and HDMm/DVm Input) Optimal resolution is 1920 X 10S0 @ G0 Hz. 640 x 350 31.469 70.086 25.175 720 x 400 31.469 70.087 28.322 640 x 480 35.000...
  • Page 73 Connections Edit Name MENU rlTl _ input _ Edit Name _ ENTERI_ Source List VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / DVI Use to select TV or an external input sources SOURCE Devices / TV / IPrv / Bin-ray / HD DVD / DMA: Name...
  • Page 74 Using Favorite Channels MENUITTI _ Channel _ Channel List _ ENTERI_ Seeing Channels Add to Favorite / Delete from Favorite Channel List Add, delete or set Favorite channels and use the program guide for digital broadcasts. Select a channel and press the TOOLS button. MENU rlTI _ Channel _ Channel List Add or delete a channel using the Add to Favorite or ENTERI_...
  • Page 75 Basic Features * After all the available channels are stored, it starts Timer Viewing: You can set a desired channel to be to remove scrambled channels. The Auto Program displayed automatically at the reserved time. Set the current time first to use this function. menu then reappears.
  • Page 76 / Brightness (Advanced Settings are available in Standard / Movie mode) Sharpness!Color!Tint(G!R) ................. Compared to previous models, new Samsung TVs have a Your television has several setting options for picture quality more precise picture. control. In PC mode, you can only make changes to Dynamic...
  • Page 77 Basic Features Black Tone (Off / Dark / Darker / Darkest): Select the xvYCC (Off/On): Setting the xvYCC mode on black level to adjust the screen depth. increases detail and color space when watching movies from an external device (e.g. BD/DVD player) connected Dynamic Contrast (Off / Low / Medium / High): Adjust to the HDMI or Component IN jacks.
  • Page 78 Screen Fit: D isplays the full i mage without any c ut-off MPEG Noise Filter (Off / Low / Medium / High / when HDMI (720p / 1080i / 1080p) or Component Auto): Reduces MPEG noise to provide improved (1080i / 1080p) signals are inputted. picture quality.
  • Page 79 PC will probably look different, but the same basic set-up information will apply in most cases. MENUrrrl _ Sound --_ ENTERI_ (If not, contact your computer manufacturer or Samsung Dealer.) Click on "Control Panel" on the Windows start menu.
  • Page 80 Multi-Track Sound (MTS) (analog channels only) Setting the Time Mono: Choose for channels that are broadcasting in mono or if you are having MENUrlTI -_ Setup -_ Time -_ ENTERE_ difficulty receiving a stereo signal. Stereo: Choose for channels that are Time broadcasting in stereo.
  • Page 81 Basic Features Setting the On / Off Timer Locking Programs MENUFITI _ Setup _ Time _ Timer 1 MENU iTrl _ Setup -_ Security -_ ENTERE_ ENTER I_ You can set the TV to turn on automatically at a preset time. Security Timer 1 / Timer 2 / Timer 3: Three different on / off The PIN input screen appears, Enter your 4 digit PIN number.
  • Page 82 The V -Chip will automatically block any * Even if you set the on-screen display to another category that deals with more sensitive material. language, the Downloadable U.S. Rating For e xample, ifyou block the PG-13 category, menu will appear in English only. then R ,N0-17 and Xwill a utomatically * The rating will automatically block certain blocked.
  • Page 83 W!reless Remote Control (Off / On) and the Background Opacity to Transparent, Turn on/off or give permission to Samsung mobile phones/ devices. You must have a Samsung Mobile phone/device which supports Wireless Remote Control. For more details, refer to each device's manual.
  • Page 84 Yes. There may be a * You may notice that the picture in the PIP window problem with the TV. Contact Samsung's Call Center for becomes slightly unnatural when you use the main assistance (1-800-SAMSUNG).
  • Page 85 Software Upgrade can be performed by network Refer to this information when connecting external devices to the T_. connection or downloading the latest firmware from "www. samsung.com," to a USB memory device. Current Version - the software already installed in the TV. Contact Samsung Software is represented as "Year/Month/DayVersion".
  • Page 86 Advanced Features You can set up your 77/so that it can access the Internet through your local area network (LAN) using a wired or wireless connection. Connecting to a Wired Network You can attach your 77/to your LAN using cable in three ways: •...
  • Page 87 Advanced Features Network SetuP(Auto )........................Network Setup (Manual) ........ Use the Automatic Network Setup when connecting your Use the Manual Network Setup when connecting your TV to TV to a network that supports DHCR To set up your TV's a network that requires a Static IP address. cable network connection automatically, follow these steps: Getting the Network Connection Values How to set up automatically...
  • Page 88 Configuration) or PIN (Personal Identification Number), WPS will automatically configure the SSID and WPA key in either mode. " If your router, modem, or device isn't certified, it may not connect to the TV via the "Samsung Wireless LAN Adapter." " Connection Methods: You can setup the wireless network connection six ways.
  • Page 89 Notice The picture may appear corrupted or have static for some channels when the TV is connected to the Samsung Wireless LAN Adapter. In such a case, establish a connection using one of the following methods or connect the Samsung Wireless LAN Adapter using a USB cable in a place that is not affected by radio interference.
  • Page 90 How to set up automatically Network SetuP (PBC 0NPS)) ..................To set up the wireless connection automatically, follow these steps: How to set up using PBC (WPS) Follow Steps 1 through 6 in the "How to set up using If your router has a PBC (WPS) button, follow these steps: PBO (WPS)"...
  • Page 91 On the dialog that appears, click the Support tab. You can connect to a mobile device without an access point through the "Samsung Wireless LAN Adapter" by using a On the Support tab, click the Details button. The peer to peer network.
  • Page 92 Link) ............Your TV may not be able to connect to the Internet This function lets you connect your TV to a Samsung device because your ISP has permanently registered the (router, etc,) that supports PBC (WPS). You can connect the MAC address (a unique identifying number) of your TV to the device even if a sharer is not connected to the TV.
  • Page 93 TV and the PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**) Using a LAN cable, connect between the external modem and the PC onto which the Samsung PC Share Manager Program will be installed.
  • Page 94 Divx DRM, Multi-audio, embedded captions are not supported. Samsung PC Share manager should be permitted by the firewall program on your PC. When you use Media Play mode through a network connection, depending on the functions of the provided server: * The sorting method may vary.
  • Page 95 Advanced Features Screen Display Move to the desired file using the up/down/righ'dleft buttons and then press the ENTER[__ or FCq (Play) button. The file is played. Supports the View Devices and Home in Media Play homepage. You can ascertain the selected file name and the number of files and page.
  • Page 96 WMA sampling rate 22050Hz mono is not supported. Below 1280 x 720:60 frame max - Above 1280 x 720:30 frame max • GMC 2 over is not supported. • Only Samsung Techwin MJPEG is supported. • H.263is not supported. Eng,,sh...
  • Page 97 Advanced Features Playing movie continuously (Resume Play) If you exit the playing movie function, the movie can be played later from the point where it was stopped. If you press the ENTERI_ button (Chaptering) during playing the file, you can explore scene divided into 5 chapters you want.
  • Page 98 Photos Viewing a Photo (or Slide Show) Press the 41 or I_ button to select Photos, then press the ENTER[_ button in the Media Play menu. Press the 41/_/A/T button to select the desired photo in the file list. Press the ENTERE_ button or [_q (Play) button. - While a photo list is displayed, press the Fcq (Play) / ENTER I_ button on the remote control to start the slide show.
  • Page 99 Advanced Features Videos/Music/Photos Play Option menu During file playback, press the TOOLS button. Title You can move directly to another Title. Repeat Mode You can play movie and mush fibs repeatedly. Picture Size You can adjust the picture size to your preference. (Model / Mode2 / Original) Pbture Setting You can adjust the picture setting.
  • Page 100 Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV's remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.
  • Page 101 * If you have selected external input mode by pressing the SOURCE button, you cannot use the Anynet+ function. Make sure to switch to an Anynet+ device by using the Device List, Recording You can make a recording of a TV Program using a Samsung recorder. Select Recording, When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed.
  • Page 102 Listening through a Receiver You can listen to sound through a receiver (i.e Home Theater) instead of the rv Speaker. Select Receiver and set to On. Press the EXIT button to exit. If your receiver supports audio only, it may not appear in the device list. The receiver will work when you have properly connected the optical in jack of the receiver to the DIGITAL AUDIO OUT (OPTICAL} jack of the TV.
  • Page 103 View -. Internet@TV --_ ENTER E_ Screen Display TV Screen: Recommended Applications: Dbplays tlse current channel. Displays the recommended service by Samsung. You are not able to add or delete a service in this list. information: Display applications, and advertisements brought to...
  • Page 104 Account Login System Setup For an application with multiple accounts, use ,_ and I_ to Ticker Autorun (Off / On): You can set Ticker Autorun access the different accounts. to come on when powering on the TV. The Ticker application provides useful News, Weather, and Stock Market information.
  • Page 105 6. Accountcreated. You can use theservices p rovided The keypad QSD will be displayed on the screen. by all users of your Samsung TV with a single Using the Keypad Iogin by linking the users' account to the TV ID. if Pressing the = button on the remote while you are you want to register a service site ID, select Yes.
  • Page 106 Apps • Video: Displays various video media such as movies, TV shows and short length videos. Samsung Apps is a store for downloading applications to be • Sports: Displays various sports media such as match used on Samsung TV/AV equipment.
  • Page 107 Advanced Features Yahoo Engine. You can monitor financial stocks, share photos with friends and family, and track news and weather all through the Yahoo!® Widget Engine. When running Internet@TV for the first time, you will be prompted to configure the basic settings. Internet@TV provides an integrated Internet and television experience powered by the Yahoo!®...
  • Page 108 • From the Administrative Controls menu you can: PROFILE Widget - Configure the Screen Saver timeout to avoid screen Set up user profiles through Profile Widget. You can set up burn-in. multiple profiles, each with its own list of widgets. Use the - Create Owner PIN and set a Security Question to Switch Profile option to switch to a different user profile.
  • Page 109 Samsung may impose limits on the use of or access to certain services or content, in any case and without notice or liability.
  • Page 110 Media, or ScreenShare function. The Media function is available in all mobile devices About AIIShare which support AIIShare, AllShare connects your TV and compatible Samsung mobile Allowed / Denied: Allows/Blocks the mobile phone. phones/devices through a network. On your TV, you can Delete: Deletes the mobile phone from the list.
  • Page 111 * the warning popup window appears. Press the ENTERE_ button to select Allow, then you can use Media function on that device. Using your Samsung Phone to Operate Your TV Before you can use this feature, you must connect to a Samsung mobile phone that supports ScreenShare functions.
  • Page 112 Other Information Stand Type Enclose the cables in the Cable Tie so that the cables are not visible through the transparent stand. 7_W_W_W_W_W_W_W_W_W_W_W_W_W_WI_W_W_W_W_W_W_W_W_W_W_W_W_W77 .._ __ ..® ® Wall-Mount Type ® !: i!i Do not pull the cables too hard when arranging them. This may cause damage to the product's connection terminals. English 51...
  • Page 113 For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others ifyou elect to install the TV on your own.
  • Page 114 Do not i nstall your Wall Mount Kit w hile your TV isturned on. I tmay result inpersonal injury due t o electric shock. The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method TV Rear °°...
  • Page 115 Other Information Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang over or destabilize the TV; doing so may cause the TV to tip over, causing serious injuries or death, Follow all safety precautions provided on the included Safety Flyer,For added stability, install the anti-fall device for safety purposes, as follows.
  • Page 116 Ifthe TV seems tohave aproblem, first try this list ofpossible problems and s olutions. Ifnone ofthese troubleshooting tips apply, visit "www.samsung.com," then c lick onSupport, orcall Samsung customer service at1-800-SAMSUNG. Poo! picture Eirstof all, please perform the Picture Test and confirm that your TV is properly displaying test image.
  • Page 117 If you are using an HDMI connection, check the audio output setting on your PC. Network Connection The wireless network connection failed. • The Samsung Wireless USB dongle is required to use a wireless network. • Make sure the Network Connection is set to Wireless (p. 27). •...
  • Page 118 A "Mode Not Supported" message • Check the supported resolution of the T_, and adjust the external device's output resolution appears, accordingly. Referto the resolution settings on page 11 of this manual. Caption on TV menu is greyed out, • Caption can not be selected in the TV menu when connected via HDMI or Component (p.
  • Page 119 Other Information SrS_ TheaterSound, SRS and the <_ symbol are trademarks of SRS Labs, Inc. TheaterSound technology is incorporated under license form SRS Labs, Inc. TheaterSound DOLI3Y Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are EHGITALPLUS ] trademarks of Dolby Laboratories.
  • Page 120 Panel native 1920 x 1080 @60 Hz Environmental Considerations Operating Temperature 50°F to 104°F (10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to %0, non-condensing Stand Swivel (Left/Right) -20°...
  • Page 121 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your T_. Not responsible for typographical or printed errors. © 2010 Samsung Electronics America, Inc English...
  • Page 122 AIIShare FAV, C H button 7, 13 Receiver Amplify Favorite Channel Recording Antenna Film Mode Remote Control Anynet+ Fine Tune Repeat Mode AVD_O OVT Flesh Tone RGB Only Mode Auto Adjustment Frequency Rotate Auto Volume HDMI 9, 39 Self Diagnosis Background Music Home Theater 10, 39...
