Eureka HP5500 Series Owner's Manual

Household type high performance

Advertisement

Quick Links

Part No. 75563
(1/05)

Upright Vacuum Cleaner

PLEA SE R ETAI N
We suggest you record the model, type and serial
numbers below. They are located on the silver rating
plate on your cleaner. For prompt and complete
service information, always refer to these numbers
when inquiring about service.
Model & Type ___________________________
Serial No. ______________________________
It is also important to keep your receipt as proof of
date of purchase.
©2005 Electrolux Home Care Products Ltd.
OWNERʼS GUIDE
HP5500 Series
IMPORTANT
Do not return to the store. For assembly
problems or questions, for replacement
of broken or missing items, or to order
replacement parts and accessories
to be shipped direct to you contact:
Eureka Customer Service toll free at
1-800-282-2886, 8 a.m. to 7:30 p.m.
(CST), Monday - Friday and 10 a.m. to
6:30 p.m. Saturday. Or visit our web site,
www.eureka.com
*En Mexico llame al (55) 5343-4384
TM
Household Type
Printed in China

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP5500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Eureka HP5500 Series

  • Page 1: Upright Vacuum Cleaner

    Eureka Customer Service toll free at 1-800-282-2886, 8 a.m. to 7:30 p.m. (CST), Monday - Friday and 10 a.m. to 6:30 p.m. Saturday. Or visit our web site, www.eureka.com...
  • Page 2: Table Of Contents

    USA. In Canada, write to Electrolux Home Care Products Canada, 866 Langs Drive, Cambridge, position while using attachments. Ontario N3H 2N7. Refer to The Eureka Warranty • Do not pick up anything that is burning or smoking, such as for complete service information.
  • Page 3 How To Assemble CAUTION: Assemble the cleaner completely before plugging into an electrical outlet. CAUTION: Moving parts, stay clear of brush roll when plugging in. NOTE: Features may vary by model yet all parts assemble the same. Step A Remove Bag Cover Step B Attach Handle NOTE: Screws must be installed to properly secure the handle.
  • Page 4 Step C Replace Bag Cover Step D Store Accessories NOTE: Make sure bag is properly installed. Check to see bag has not shifted away from bag inlet during shipping. See page 13 for further instructions. Bag Cover Latch Dusting/ Nesting Upholstery Extension Brush...
  • Page 5: Use

    How To Use 1. Cord Retainer. To use, push electrical cord down into cord retainer. CAUTION: Do not plug in cleaner 2. ON/OFF Switch. International symbol I means On, until you understand all International symbol O means Off. controls and features. 3.
  • Page 6: Thermal Cut Off

    How To Use (continued) 14. Hose Retainers (3). Place hose on retainers to store hose on unit. 15. Carrying Handle. Use this handle to carry unit from one place to another. 16. Dusting/Upholstery Brush. Store dusting brush here. 17. Electrical Cord Hooks (2). Wrap electrical cord around them to store electrical cord on unit.
  • Page 7: Accessories

    How To Use Accessories CAUTION: Do not place cleaner on furniture or steps as the brush roll may cause damage. Place cleaner on floor with the handle in storage position while using accessories. 1. Remove hose from hose adapter on the Dusting/Upholstery Brush is for furniture, blinds, books, back of cleaner.
  • Page 8 How to Check and Clear Hose Blockages Low suction or poor pickup may be due to a blockage in the vacuum cleaner. 1. Remove hose from hose retainer and check suction at end of hose - if little or no suction, check disposable dust bag. Change if needed.
  • Page 9: Brush Roll

    How To Maintain The instructions in this booklet serve as a guide to routine maintenance. To avoid unnecessary service calls, check the bag, belt, and brush roll often. Brush Roll The brush roll turns as it sweeps and combs the carpet nap. Remove hair and threads from the brush roll so it continues brushing the carpet.
  • Page 10: Dust Bag

    12. Tighten screws. 1. Release bag cover by rotating bag cover latch to Use Genuine Eureka brand replacement belt, Style the left pointing to the unlock symbol ( ). Pivot EXT, Part No. 61120A. bag cover away from cleaner and remove.
  • Page 11: Cleaning And Replacing Filters

    filter can be cleaned by vacuuming with another cleaner. 3. Reinstall filter by placing smooth side down in the bottom of the bag compartment. Replace dust bag and bag compartment cover. Use Genuine Eureka brand replacement motor filter, 70772.
  • Page 12: Filters

    4. Place new light bulb into socket; push to secure. 5. Push light bulb and socket back so bulb will not touch lens cover. Lens Cover 6. Replace lens cover. 7. Secure with two screws. Use Genuine Eureka brand replacement light bulb, 57940-3...
  • Page 13: Light Bulb

    Problem Solving NOTE: Turn off the switch and unplug the electrical cord before servicing. PROBLEM CAUSE SOLUTION Motor will not start. Electric Plug Push plug securely into outlet. Try another outlet. Check circuit breaker. Motor suddenly stops. Thermal Cut Off Refer to page 6.
  • Page 14 The Eureka Company Will Do The Eureka Company will, at its option, repair or replace a defective cleaner or cleaner part that is covered by this warranty. As a matter of warranty policy, the Eureka Company will not refund the consumerʼs purchase price.
  • Page 15 (2 screws) Thank you for selecting a Genuine Eureka brand cleaner. Donʼt Forget to Use Genuine Eureka Bags, Belts and Filters www.eureka.com CAUTION: Damages caused by the use of other brand bags and belts are not covered by the Limited Warranty.
