Physical Specifications

Front Panel

Dimensions
Height
Width
Depth
Front Panel Indicators
presence. This detection procedure occurs at the time the Audio Deck is powered on
or the R-1 software application is booted. The Audio Deck does not offer manual
selection of the Sample Rate source from its front panel.
THERE ARE NO USER SERVICEABLE PARTS IN THE AUDIO DECK
R-1 Audio Deck Manual
1
3 ½ inches ,
19 inches
17 inches D (18.5 inches including connector depth).
AES - Locked to AES Input for Sample Rate
Word - Locked to Word Clock Input for Sample Rate
MADI - Locked to MADI Input for Sample Rate
Internal Locked to its own internal crystal for Sample Rate
This order of LEDs is the same order in which signals are tested for their
©1999 Euphonix, Inc.
AUDIO DECK
2
AES
WORD
AD
MADI
801
INTERNAL
Page 6
