Audiotrak MAYA EX7 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARRANTY
Ego Systems Inc. warrants the return policy to its original purchaser as follows; All the EGO
SYSTEMS INC.'s products, under normal use, will be free from faulty as long as the purchaser
owns this product.
The terms of warranty is 15 months to EGO SYSTEMS INC. distributors considering a 3-month
temporary stock period ahead of being sold to the end user.
Therefore, the actual terms of warranty is 12 months to the end user.
EGO SYSTEMS INC. will, at its sole option, repair or replace a product, which is found to be
defective. This warranty shall be invalid if, in the sole opinion of EGO SYSTEMS INC., a product
failure is the result of misuse, abuse, modification, or misapplication. Except as expressly provided
above, EGO SYSTEMS INC. products are provided, 'as is' without any kind of warranty. No claim
is made for merchantability or fitness for any purpose. In no event will EGO SYSTEMS INC. be
liable for any direct, indirect, consequential, or incidental damages arising out of use of the product.
The purchaser must contact EGO SYSTEMS INC. or its regional representative to receive prior approval
before returning a faulty unit.
To obtain warranty service, the buyer or his authorized dealer must send the email to
sales@audiotrak.net
or
before returning the product. EGO SYSTEMS INC. will then issue an
techsupport@audiotrak.net
authorization number.
All such returns must be shipped to EGO SYSTEMS INC.' headquarters in Seoul, Korea as being
packaged in the original or equivalent protective packaging material (Rack, PCI card, Power
Cables, connection cables), with freight prepaid and adequate insurance.
Any Shipments without freight prepaid will not be accepted.
If the returned product is deemed to be defective, the repaired or replacement product will be back
to you at no extra charge via the carrier chosen by EGO SYSTEMS INC.
T R A D E M A R K S
AUDIOTRAK, MAYA EX7 are trademarks of EGO SYStems Inc. Windows is a trademark of Microsoft
Corporation. Other product and brand names are trademarks or registered trademarks of their respective
companies.
R A D I O F R E Q U E N C Y I N T E R F E R E N C E A N D C O M P A T I B I L I T Y
NOTE: This equipment has been tested and found to comply with the limits for EN55022 Class
A:1998+A1:2001, EN55024:1998 of CE Test Specifications

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUDIOTRAK MAYA EX7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Audiotrak AUDIOTRAK MAYA EX7

Summary of Contents for Audiotrak AUDIOTRAK MAYA EX7

  • Page 1 WARRANTY Ego Systems Inc. warrants the return policy to its original purchaser as follows; All the EGO SYSTEMS INC.’s products, under normal use, will be free from faulty as long as the purchaser owns this product. The terms of warranty is 15 months to EGO SYSTEMS INC. distributors considering a 3-month temporary stock period ahead of being sold to the end user.
  • Page 2 This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instruction, it may cause interference to radio communications. This device also complies with part 15 class A of the FCC Rules. Operation is subject to the following two conditions; This device may not cause harmful interference, and must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Table Of Contents

    CONTENTS 1. OVERVIEW........................ 4 2. FEATURES ......................... 5 3. SYSTEM REQUIREMENT ..................5 4. HARDWARE INSTALLATION ................6 5. DRIVER INSTALLATION ..................7 6. SURROUND SPEAKER INSTALLATION............12 1) 7.1 ..............12 CHANNEL SPEAKER CONFIGURATION 2) 5.1 ..............12 CHANNEL SPEAKER CONFIGURATION 7.

  • Page 4: Overview

    1. Overview Thank you for choosing AUDIOTRAK MAYA EX7. MAYA EX7 is the premier external audio solution featuring a set of 8 discrete RCA outputs in a compact, portable slim design. The stereo S/PDIF optical output is the ideal way to transfer digital audio data to external recorders or amplifiers without the loss of audio quality.

  • Page 5: Features

    2. Features 102/100dB 24-bit 96kHz High Fidelity 8 Channel Digital to Analog Converter Plug In with Analog Outputs(8) plus an Optical Digital Output Transfer Pure Audio to Digital Devices with Optical Digital Output Compose Seamlessly with all DJ Music Software Emulate Multi-Channel Surround Sound with SRS TruSurround XT with Enhanced Bass and Dialog * Experience Stereo Audio Sources with Expanded 7.1 Channel Surround...

  • Page 6: Hardware Installation

    4. Hardware Installation Before you begin, make sure you have to read your computer’s manual on installing USB devices. Your computer’s manual should describe the precautions you should take. Shutting down computer wouldn’t need for installing an USB device to the computer. However, we will take it from the start to make sure you can follow every detail installation.

  • Page 7: Driver Installation

    5. Driver Installation 1. After hardware installation was done properly, your computer will automatically detect the MAYA EX7 as USB composite device will be installed. This installation step is the case of Windows 98SE. If your OS is Windows ME, 2000 or XP, installation step would be simpler than the case of 98SE.
  • Page 8 2. When you prompt, choose “Search for the best driver for your device” and hit “Next” button. 3. Select the drive that contains Windows 98SE (your computer will automatically find proper driver) and go to “Next.”...
  • Page 10 4. Keep going to install follows the instruction.
  • Page 11 5. After rebooting computer, you can find “USB composite device” under the “Universal serial Bus controller” section. As above picture, the MAYA EX7 is set as a “USB Composite Device.” Now you can use Windows Direct sound, MME and 7.1 surround system.

  • Page 12: Surround Speaker Installation

    6. Surround Speaker Installation There are many types of speakers for various multimedia systems. This section lists the settings for various speaker configurations. 1) 7.1 channel speaker configuration L/R: front: Arrange the speaker at an angle of 45 degrees from the listener. Lc/Rc: Center L/R: Extra channel.

  • Page 13: Working With Applications

    7. Working with Applications This chapter only contains the basic setup for some of the software. For more detailed info, please refer to the manual of the software. Windows Audio Setting 1. Go to System -> Device Manager -> Set Windows Audio setting as below pictures.
  • Page 14 Click ‘Advanced’ on speaker settings and go to ‘Advanced Audio Properties’ and choose ‘7.1 Surround Speakers’.
  • Page 15 2. You must check volume of Windows setting. Otherwise, you cannot hear MAYA EX7’s output 1,2...

  • Page 16: Windvd4

    2) WinDVD4 * You must check “DMA” in your DVD-Rom drive settings. If you don’t check DMA, you cannot attain a crisp picture. On the WinDVD main applet, click the right mouse button, and choose ‘Setup.’ Select the ‘Audio’ Tab. Select ‘8 Speaker Output.’...
  • Page 17 * This order is the case of Windows 2000. It will be varied by your operating systems. Output channel 7.1 surround sound route Stereo Sound route Front L Front R Center Woofer Surround Left Surround Right Center L Center R Digital out All outputs Same as Analog out L,R...

  • Page 18: Emersys Maven 3D Pro

    3) Emersys Maven 3D pro This software is 3D Multi-track Audio Editor from Emersys corp. In Maven 3D pro, Go to Option -> Audio Device setup.

  • Page 19: Pcdj

    4) PCDJ 1. After launching PCDJ software, click ‘cfg (config)’ and you must set as below. Check ‘Multi channel mode’ and ‘No. 5 External mixer player….’ 2. Go to ‘Soundcard 1’ and click ‘Start test’.
  • Page 20 3. You can use MAYA EX7’s output 1,2 and 5,6 with PCDJ. Player A will be linked with MAYA EX7 Output 1,2. Player B will be linked with MAYA EX7 Output 5,6. Monitoring source will be linked with available output between Output 1,2 and Output 5,6.

  • Page 21: Bpm Studio

    5) BPM Studio After launching BPM studio software, click ‘Option’ and you must set as below. Otherwise, it isn’t working properly.
  • Page 22 Choose ‘DirectSound Driver’ on Driver menu. And also Choose ‘USB Audio Device 1+2’ on Monitor menu, Choose ‘USB Audio Device 3+4’ on Player A. Choose ‘USB Audio Device 5, 6’ on Player B. Caution: Do not choose ‘USB Audio Device 7+8’. Otherwise, it isn’t working properly.

  • Page 23: Specification

    Specification 1. Interface : USB Spec Ver1.1, USB Audio Class Spec Ver1.0 2. Output Type : Analog 8 Channel Output (RCA Jack) Digital 2 Channel Output (TOS-LINK) Headphone Output (3.5mm Mini Phone Jack) 3. Analog Output Level : -10dBV Unbalanced, -10dBV Nominal, +0.5dBV Maximum 4.
