END USER WARRANTY
EGO SYSTEMS, INC. warrants the return policy to its original purchaser as follows: All EGO
SYSTEMS INC.'s products, under normal use, will be free from fault as long as the purchaser
owns this product for a period of twelve (12) months from the date of purchase
.
EGO SYSTEMS INC. will, at its sole option, repair or replace a product, which is found to be
defective. This warranty shall be invalid if, in the sole opinion of EGO SYSTEMS INC., a product
failure is the result of misuse, abuse, modification, or misapplication. Except as expressly
provided above, EGO SYSTEMS INC. products are provided, 'as is' without any kind of warranty.
No claim is made for merchantability or fitness for any purpose. In no event will EGO SYSTEMS
INC. be liable for any direct, indirect, consequential, or incidental damages arising out of use
of the product.
The purchaser must contact EGO SYSTEMS INC. or its regional representative to receive prior
approval before returning a faulty unit.
To obtain warranty service, the buyer or his authorized dealer must send an email to
before returning the product. EGO SYSTEMS INC. will then issue an
techsupport@audiotrak.net
authorization number.
All such returns must be shipped to EGO SYSTEMS INC. headquarters in Seoul, Korea or the U.S,
packaged in the original or equivalent protective packaging material (rack, PCI card, power
cables, connection cables), with freight prepaid and adequate insurance. Any shipments
without freight prepaid will not be accepted. If the returned product is deemed to be defective,
the repaired or replacement product will be returned at no extra charge via the carrier chosen
by EGO SYSTEMS INC.
Trademarks
AUDIOTRAK and MAYA7.1 are trademarks of EGO SYSTEMS Inc. Windows is a trademark of Microsoft Corporation. Other
product and brand names are trademarks or registered trademarks of their respective companies.
Radio Frequency Interference and COMPATIBILITY
NOTE: This equipment has been tested and found to comply with the limits for EN55022 Class B:1998, EN55024:1998 of
CE Test Specifications. This equipment generates, uses, and can radiate radio frequency energy. If not installed and
used in accordance with the instruction, it may cause interference to radio communications. This device also complies
with Part 15 of class B of the FCC Rules. Operation is subject to the following two conditions: This device may not
cause harmful interference, and must accept any interference received, including interference that may cause
undesired operation.
Correspondence
For technical support inquiries, contact your nearest dealer or EGO SYSTEMS directly at:
Ego Systems Inc.
3003N. First St., Suite 303,
San Jose, CA 95134, USA
Website: www.audiotrak.net
E-mail: sales@audiotrak.net
Technical Support (English only)
techsupport@audiotrak.net
All features and specifications subject to change without notice.
AUDIOTRAK MAYA 7.1 User's Guide
- i -

Advertisement

Table of Contents
loading

Summary of Contents for Audiotrak AUDIOTRAK MAYA 7.1

  • Page 1 END USER WARRANTY EGO SYSTEMS, INC. warrants the return policy to its original purchaser as follows: All EGO SYSTEMS INC.’s products, under normal use, will be free from fault as long as the purchaser owns this product for a period of twelve (12) months from the date of purchase EGO SYSTEMS INC.
  • Page 2: Table Of Contents

    Contents Overview ..................1 Features ......................3 Minimum System Requirements................3 MAYA 7.1 PCI Card .................5 Hardware Installation ..............7 Speaker Installation ...............9 Driver and Software Installation............11 Control Panel ................19 Working with Applications.............. 23 Win DVD ....................23 Maven 3D Pro – Emersys ................25 nTrack Studio –FARSOFT ................
  • Page 3: Overview

    VERVIEW Enter a new world of home theater entertainment with the MAYA 7.1 surround sound audio card. MAYA 7.1 provides two high-fidelity analog inputs and eight discrete analog multi-channel outputs for Dolby Digital 5.1, EX, and DTS 5.1, ES for true surround sound and virtual surround sound for 5.1, 6.1 and 7.1 speaker configurations.
  • Page 4 AUDIOTRAK MAYA 7.1 User’s Guide - 2 -...
  • Page 5: Features

    EATURES Listen to 7.1 Channel Surround Sound on Your PC Plug In with Analog Inputs (2) and Outputs (8) plus an Optical Digital Output Play DVDs, CDs, and MP3s in 7.1 Surround Sound with Included Software* Emulate Multi-Channel Surround Sound with SRS TruSurround XT with Enhanced Bass and Dialog* Independent Surround Sound Channel Volume Control Optical Digital Output for MiniDisc Recorders and Portable Digital Devices...
  • Page 6 AUDIOTRAK MAYA 7.1 User’s Guide - 4 -...
  • Page 7: Maya 7.1 Pci Card

    MAYA 7.1 PCI C 1. MIC IN (PINK): Connect to an external microphone for voice input. 2. LINE IN (BLUE): Connect to an external device (such as a Cassette, DAT, or Mini Disc player). Caution: Inputting the line through the power amp can damage the card. 3.
  • Page 8 AUDIOTRAK MAYA 7.1 User’s Guide - 6 -...
  • Page 9: Hardware Installation

    ARDWARE NSTALLATION Before you begin the installation, please consult the manual of your computer for detailed instructions on installing a PCI card in your computer. 1. Shut down the computer and all other hardware devices connected to your computer. Leave the power cable attached to your computer, if you will be using the computer’s power supply as the grounding outlet.
  • Page 10 4. Choose an available PCI slot and remove the cover plate (and the screw that holds it in place) from the slot on the back of the computer. 5. Before handling the MAYA 7.1 PCI card, make sure once again that you are properly grounded then remove the card from its protective envelope.
  • Page 11: Speaker Installation

    PEAKER NSTALLATION There are many types of speakers for various multimedia systems. This section lists the settings for various speaker configurations. 1) Connecting regular stereo speakers If you have general stereo PC speaker, just connect to Front Out (green color). 2) Speaker configuration of Dolby Laboratories Inc.
  • Page 12 AUDIOTRAK MAYA 7.1 User’s Guide - 10 -...
  • Page 13: Driver And Software Installation

    RIVER AND OFTWARE NSTALLATION After completing the installation of hardware and speakers for the MAYA 7.1, you should install the MAYA 7.1 driver software. Note: The motherboard, which utilizes a new chipset, may need a patch installed. The patch should be available from the motherboard company or chipset manufacturer. Check the manufacturer and model number of the chipset of your motherboard and then download patch from one of the following links: http://support.intel.com/support/chipsets/...
  • Page 14 3. Choose ‘Search for the best driver in these locations’, and then select ‘Include this location in the search”. Insert the AUDIOTRAK Installation CD into the CD-ROM drive. Click the Browse button to locate the CD directory listed in the following image. Once you have located the directory, click Next to continue.
  • Page 15 Windows will begin copying the files to your computer. 5. When Windows finished copying the files, the ‘Completing the Found New Hardware Wizard’ window will appear. Click Finish to continue to the next step of the installation. AUDIOTRAK MAYA 7.1 User’s Guide - 13 -...
  • Page 16 6. Windows will automatically continue with the installation. The following window will appear. Click Next. 7. Ignore the following message and click Continue Anyway. AUDIOTRAK MAYA 7.1 User’s Guide - 14 -...
  • Page 17 8. When Windows finished copying the files, the ‘Completing the Found New Hardware Wizard’ window will appear. Click Finish to continue to the next step of the installation. 9. Windows will automatically continue with the installation. The following window will appear.
  • Page 18 10. Ignore the following message and click Continue Anyway. Windows will begin copying the files to your computer. AUDIOTRAK MAYA 7.1 User’s Guide - 16 -...
  • Page 19 11. When Windows finished copying the files, the ‘Completing the Found New Hardware Wizard’ window will appear. Click Finish. The installation is now complete. 12. Restart your computer. AUDIOTRAK MAYA 7.1 User’s Guide - 17 -...
  • Page 20 13. After rebooting, Go to ‘My Computer -> Control Panel -> System -> Device Manager’. Check the devices under ‘Sound, video and game controllers’. You should see the following new devices: Maya 7.1 EWDM Controller by AUDIOTRAK Maya 7.1 EWDM Wave MIDITRAK 2120 by AUDIOTRAK AUDIOTRAK MAYA 7.1 User’s Guide - 18 -...
  • Page 21: Control Panel

    ONTROL ANEL After successfully installing the MAYA 7.1 PCI card and software, the AUDIOTRAK logo will appear in the system tray. Click on the AUDIOTRAK logo to launch the MAYA 7.1 Control Panel. File –> Exit will close the MAYA 7.1 Control Panel window but it will not shut down the Control Panel.
  • Page 22 IF you are using Sonar, you should click ‘Wave Profiler’ again after changing the latency. Changing the latency affects all applications. – F ONFIG ACTORY EFAULT Returns all MAYA 7.1 Control Panel settings to the original shipping state. ONFIG LWAYS Keeps the MAYA 7.1 Control Panel on top of all open windows.
  • Page 23 ECORDING IXER The Recording Mixer adjusts only the recording level of the inputs. Selecting MIX adjusts all recording levels. You can also change the levels of the LINE, MIC, AUX, CD individually by clicking on the MIX button until the preferred input name is displayed. IXER AND ASTER OLUME...
  • Page 24 AUDIOTRAK MAYA 7.1 User’s Guide - 22 -...
  • Page 25: Working With Applications

    ORKING WITH PPLICATIONS * This chapter only contains the basic setup for some of the software. For more detailed information, please refer to the manual of the software. The MAYA 7.1 can playback 5.1, 6.1, or 7.1 audio when used in conjunction with the WinDVD software player.
  • Page 26 In the WinDVD main Window, click the right mouse button, and choose ‘Setup.’ Select ‘8 Speaker Output’. Now you can enjoy DVD with 5.1-, 6.1- or 7.1-channel surround sound. * For more detailed information, features and operation, please refer to the ‘Help’ menu of the software.
  • Page 27: Maven 3D Pro - Emersys

    3D P – E AVEN MERSYS After launching Maven 3D Pro, Go to ‘Option’ -> Audio Device Setup and choose the settings as shown in the diagram below. You can use both WDM and ASIO drivers with Maven 3D Pro. This program is 5.1 channel surround sound software.
  • Page 28: Ntrack Studio -Farsoft

    –FARSOFT RACK TUDIO After launching nTrack, go to Files -> Settings -> Preference -> Audio Devices. When Wave devices menu appear, select ‘ WDM:2-Maya7.1 Multi channel’. You can also use MME and Direct Sound driver with nTrack. After click ‘Advanced tab’ on ‘Wave Devices’ menu, you can choose the proper driver. AUDIOTRAK MAYA 7.1 User’s Guide - 26 -...
  • Page 29 * Caution: nTrack and MAYA 7.1 working with 48kHz audio source. If you use 44.1kHz audio source, you may get an error message. For more detailed info, please refer to the Help file of the software. AUDIOTRAK MAYA 7.1 User’s Guide - 27 -...
  • Page 31: Specifications

    PECIFICATIONS Input Type: Analog 2 Input – Line-In (3.5mm Jack), Mic-In (3.5mm Jack) Aux-In, CD-In Output Type: Analog 8 Output (3.5mm Jack), SPDIF_Out (TOSLINK) Input LEVEL: -10dBV Unbalanced, -10dBV Nominal, +9dBV Max Output LEVEL: -10dBV Unbalanced, -10dBV Nominal, 0dBV Max Input Impedance: Mic in 47K ohm, Line in 10K ohm Output Impedance: Output 1,2 : 700 ohm, Output 3,4, 5,6, 7,8: 100 ohm IN 1,2 Record Gain: Analog 0dB ~ 22.5dB, 1.5dB Step Size...
