- Page 2 Important Safety Information Be sure to read all the safety information before you begin to use this product. WARNING" To reduce the risk of fire or shock hazard, do not expose camcorder or AC adapter/charger to rain or moisture. This symbol indicates "dangerous voltage"...
- Page 3 We want to make sure you enjoy your new camcorder, if you have any questions, call: Camcorder Exchange Warranty ... 800-283-6503 (pages 55-56) Customer Service ........800-336-1900 (page 54) Accessories ..........800-338-0376 (pages 41-47) First Time Operation ....Battery Level Indicator ..13 Battery Care ......
-
Page 4: Table Of Contents
TiltAdjustment ......21 Stop-Action P ause ....34 BrightControl ......Tracking ......Playback o naTV Using Viewfinder D isplays ....22 A/V Inputs ....... 36 DisplayButton....24 Installation ......QuickReview Feature ..2 4 Camera E dit Feature .... 25 Howto CopyTapes ontheVCR ...... - Page 5 This section describes the steps necessary to set up your camcorder to record. Refer to the other sections for detailed operation and feature options. Assistance The toll-free numbers are available to help you with any problem you may encounter. Camcorder Exchange Warranty ....800-283-6503 Customer Service ........
-
Page 6: Quickreview Feature
Attach the adapter/charger. To AC 120V, 50/60 Hz Adapter/ Charger 7 IN 9.6V Jack 2. Attach the other end of the cable Since the battery must be charged before it can be used the first time, to the DC IN 9.6V jack on the camcorder. - Page 7 Insert a tape. Safety Tab STOP/EJECT Button Tape Windows Cassette _Cassette Door Press Here to Close • Press the cassette down gently Press STOP/EJECTto open the until it locks into place, and close cassette compartment. the cassette compartment door. insert the cassette with the safety tab facing up and the tape windows •...
- Page 8 Eyepiece Focus Control Electronic Viewfinder (Grasp here to move.) x ,iece BRIGHT Control (Underneath) REC/PA USE Button 7. Start and stop recording. 6. Adjust the viewfinder eyepiece focus control. • Press and release the REC/PAUSE button to start recording. • Grasp the viewfinder and rotate it appears in the viewfinder...
- Page 9 RE W/ PLAY REVIEW Button CAMERA/ Button OFF/VCR EJECT Button R E C/PA USE 9. Set the CAMERA/OFF/VCR Play back what you have recorded. switch to OFF to turn off the camcorder. • Press the REC/PAUSE button to pause recording. 10.
- Page 10 11. Review camcorder's operating controls. DISPLAY Button RE W (Rewind)/RE VIE W Button (Also - Button) RESET Button PLAY Button DATE/TIME Button EFWD (Fast Forward) Button TITLER Button (Also + Button) STOP/EJECT CAMERA/ Button OFF/VCR (Also EDIT-ADV Switch Button) Microphone BRIGHT Control (underneath)
- Page 11 11. Review camcorder's operating controls. (continued) Viewfinder Eyepiece Focus Control Shoulder Strap Attachment Ring BATTERY EJECT Button Attach Rechargeable Battery Here Button Handstrap with Lens Cap Holder W and T Power Zoom Buttons Cassette Door (Also TRACKING (Press here to Buttons) close.) DC IN 9.6V Jack...
- Page 12 Use the Adapter/Charger to Power Your Camcorder The adapter/charger attaches to the camcorder and lets you power your camcorder directly from standard household power. The adapter/charger operates on 120 volts, 50/60 Hz, and can be used to power the camcorder or recharge the battery. Caution: Do not attempt to use a "'power converter"...
- Page 13 Use the Battery and Charger to Power the Camera Charging the Battery The battery must be charged before it can be used the first time. initial charging will take approximately two hours. The camcorder's operating time depends on how often you turn the power on and off and how much you use zoom and pause.
- Page 14 Using the Battery to Power Your Camcorder (continued) CAMERA/ OFF/VCR Switch BATTERY EJECT Rechargeable Hold Battcry Flush and SlidcDown Charging the Battery if the DC cable is attached to the 3. Press and hold the small button on the camcorder, remove it before attaching CAMERA/OFF/VCR switch while you slide it to CAMERA.
- Page 15 Use the Battery to Power Your Camcorder (continued) Battery Level Indicator The battery level indicator appears in the viewfinder and shows you the amount of power in the rechargeable battery. Battery Level Indicator Display in Viewfinder Note: If the does not Notes: When recording using the recharge- battery level display...
- Page 16 Use the Battery to Power Your Camcorder (continued) Battery Care • Your battery will provide better service damaged if operated at temperatures and longer performance if you charge above 122°F (50°C). Operation if before and after use, and store it at time will decrease at extremely normal room temperature.
- Page 17 Using the RCA Optional Car Cord Adapter The optional DCC096 car cord shown on Caution: The DCC096 car cord i page 41 allows you to power your designed to be used only with camcorder from the cigarette lighter vehicles having 12-volt negative socket of a car, truck, or RV.
- Page 18 Make sure you select good quality tapes for your camcorder. Use of poor quality tapes or tapes that have been damaged or mishandled can contaminate the video heads, resulting in a snowy picture or no picture at all during playback. Because there is no control over the type of tape purchased...
- Page 19 Inserting and Removing Cassettes Caution: Insert the cassette only one way with the STOP/ tape wheel facing EJECT up and the tape Button windows facing out. The cassette Windows should slide easily into the holder. Gently push the cassette down until it locks into place.
- Page 20 Setting the Time and Date You must set the correct date and time before it can be displayed and recorded on your tapes. The built-in clock cell must be charged as described on the nextpage. RE W! CAMERA/ REVIEW EFWD Button DATE/TIME OFF/VCR Button...
- Page 21 1. Attach a power supply and set the months_ it wi!l over-discharge and shorten its CAMERA/OFF/VCR switch to OFF. useful lifel Do not attempt tOreplace this battery. Take the 2. Leave the power supply attached camcorder to an authorized RCA Service Center. least 24 hours.
- Page 22 Use the Viewfinder The camcorder's viewfinder is a miniature monitor that displays the picture seen by the camcorder when recording. Adj ust Viewfinder for Convenient Viewing For convenient viewing, rotate the viewfinder horizontally, pull it out from the camcorder, and adjust the eyepiece. Eyepiece Focus Control Viewfinder...
-
Page 23: Tiltadjustment
Use the Viewfinder (continued) Tilt Adjustment Cautions: Do not pull on the eyepiece. DO not force th e eyepiece to rotate completely aroun d , This might damage the viewfinder and/or the camcorder. BRIGHT Control --. o BRIGHT Control The brightness of the viewfinder can be adjusted... -
Page 24: Viewfinder Displays
Viewfinder Displays AE:60 0000M INDEX ZOOM TAPE 11/18/1999 10:30AM AE:60 (Auto Exposure) Shutter Speed Status Displays Press the DISPLAYbutton to display the The following displays appear to tell you the status of the camcorder. shutter speed selected by the camcorder. •... - Page 25 Viewfinder Displays (continued) Tape Counter (0000M) with Memory Tape-Remaining Indicator (_m) Stop Press the DISPLAY button to display the Press the DISPLAY button to display the tape-remaining indicator. This display tape counter. The tape counter helps shows the approximate amount of tape locate segments of tape.
-
Page 26: Displaybutton
DISPLA Y Button RE W/RE VIE W Button Micro VCR Switch Zoom Buttons (T and W) DISPLAY Button Quick Review Feature Press and release REW/REVIEW when the The DISPLAY button lets you remove battery level, tape counter with memory camcorder is in record-pause to review stop, tape speed, remaining-tape,... -
Page 27: Camera Edit Feature
Camera Edit Feature Auto Focus The camera edit feature allows you to The camcorder focuses on the subject in the center of the viewfinder. Auto focus position the tape when the camcorder is in record-pause. Press and hold the small operates on the telephoto (T) side from... -
Page 28: Tape-Remaining Display
Tape-Remaining Display Electronic Indexing The tape-remaining display shows the Each time you begin recording (after the camcorder has been turned off for at least amount of recording or playback time left on the tape in the camcorder. four hours), the camcorder automatically records an index mark at the beginning of the new recording. -
Page 29: Zooming
Zooming You can zoom in and out for close ups or wide-angle shots by pressing one of the zoom buttons on the camcorder. Zoom Buttons (T and W) Use the Zoom Buttons (T and W) 1. To zoom in or out from wide angle to 72 times, press zoom button Tor W. -
Page 30: Tape Counter
Tape Counter The tape counter acts as a handy reference to help you locate tape segments. The memory-stop feature helps locate a certain point on the tape. When the tape counter appears, memory stop is automatically turned on. RE W! DISPLAY CAMERA/ REVIEW... -
Page 31: Recording Tips
Recording Tips Be aware of video and audio back- • Try to make sure indoor scenes are • well-lit. This improves picture quality grounds. Background details barely and color reproduction. noticed while you are taping might show up as visual "clutter" on your •... -
Page 32: Titler
Titler The camcorder's built-in titler stores a title in memory. You can display and record the created title at any time. The built-in character register contains over 45 different characters for creating your titles. The title can contain up to 32 characters on two lines. -
Page 33: Creating
Titler (continued) To Create a Title 1. Attach a power source to the See the chart below for the camcorder. Press and hold the small characters available. button on the CAMERA/OFF/VCR 5. After you have selected the first switch while you set it to CAMERA. character, press EDIT-ADV to move 2. -
Page 34: Recording I N Thecamcorder
Titler (continued) Record a Title on a Tape in the Camcorder TITLER to remove the titler graphics Attach a power source to the camcorder. Press and hold the small from the viewfinder. The camcorder button on the CAMERA/OFF/VCR now records normally, if you do not want to continue recording, press switch while you slide it to CAMERA. -
Page 35: Playback
Viewfinder Playback Viewfinder playback is the simplest way to watch tapes using the camcorder. CAMERA/ PLAY OFF/VCR Button Swi _h STOP/EJECT Viewfinder Eyepiece Button BRIGHT Control (underneath) fiece Focus Control To Play Back a Tape 1. Attach a power supply. •... -
Page 36: Features
Playback Features REW ! STOP/ CAMERA/ REVIEW EFWD EJECT OFF/VCR Button Button Switch _. oooo Button Tape Positioning Stop-Action Pause Press and hold the small button on the • During playback, press REC/PA USE to CAMERA/OFF/VCR switch while you "stop the action" and view one frame of slide it to VCR. -
Page 37: Tracking
Playback Features (continued) TRACKING Buttons (Also Wand Buttons) Tracking During playback, streaks might appear in Remove the tape to reset the tracking the playback picture. Press either its preset center. TRACKING button to move the streaks Note: The tracking buttons only affect tape up or down and out of the picture. -
Page 38: Playback O Natv Using A/V Inputs
Playback on TV (or VCR) with Audio/Video Inputs To connect your camcorder to a TV monitor (or VCR) with audio and video inputs, you need an optional audio/video cable, such as VH83 shown on page 43. if your TV is already connected to a VCR, attach the camcorder to the VCR and watch what the camcorder is recording or playing on the TV. -
Page 39: Howto Copytapes Onthevcr
Playback Operation and How to Copy Tapes on the VCR 3. PressPLAY. Camcorder connected directly to TV: Turn on the TV and tune it to • During playback, use the playback the video input channel. features on pages 34-35. B. Camcorder connected to VCR that 4. -
Page 40: Playing Backona Tv Without A!V Inputs
Playback on a TV Without Audio/Video Inputs To connect your camcorder to a TV without audio/video inputs, you need an optional CRF95 RF output adapter and an optional coaxial RF cable, such as VH82 or VH90 shown on page 43. if your TV has audio and video inputs (or is connected to a VCR), refer to pages 36-37. -
Page 41: Playback Operation
Playback Operation 1. Set the CH3/CH4 switch on the 4. Press PLAYon the camcorder. RF output adapter to channel • During playback, use the playback CH3 or CH4. features described on pages 34-35. 2. Turn on the TV, and tune it to the 5. -
Page 42: Attaching The Shoulder Strap
The camcorder's shoulder strap is designed to let you carry the camcorder from your shoulder and - when you are ready to shoot - bring the camcorder to shooting position in one quick movement. To Attach the Shoulder Strap 1. Unfasten one end of the shoulder strap Thread the end of the strap back from the buckle. -
Page 43: Accessories
Weinvite youtotake alookatsome g reat i deas f orsparking creativity and adding t o thefunofusing your V HScamcorder. The following p ages have aselection of accessories tohelp make your m emorable moments lookand sound e ven better. These a ccessories aredesigned tomake theprocess ofrecording and watching your videos m ore enjoyable. - Page 44 EP096FS andEP096FL R echargeable Using the Optional AC093 Tripod Batteries Mounting the camcorder on a tripod, such as AC093, keeps the camcorder steady and produce excellent video results. This tripod's fluid-effect head provides smooth camera pan and tilt. The quick- release mount makes it easy to attach or remove the camcorder.
- Page 45 CRF95 RF Output Adapter VH54 Cable Transformer This 75-to-300 ohm transformer is used to connect a standard 75-ohm antenna cable This RF output adapter is used with a (such as VH82 or VH90) to the 300 ohm coaxial RF cable, such as VH82 or VH90, screw terminals on a TV.
-
Page 46: Lens Hood Removing
Remove the Lens Hood The lens hood can be removed so you can attach optional accessories, such as wide- angle lens, lens extenders, or lens filter kits. To Attach an Accessory Lens 1. Attach the lens cap over the lens hood. 3. -
Page 47: Accessory Order Form
Order Form for Camcorder Model CC4252 Total Description Part Price Qty. Deluxe Tripod AC093 $ 59.95 Soft Camcorder Case AC202 $ 49.95 Y-Adapter AH25 2.95 CPS014 $219.95 AC Adapter/Charger (100-240V) CRF95 RF Output Adapter $ 69.95 DCC096 $ 49.95 Car Cord Adapter EP096FL Rechargeable Battery (Extended) $ 79.95... - Page 48 Charge your order on your VISA,MasterCard, or Discover Card by filling in below YOUR CREDIT CARD IMPORTANT: I lll IVVJ-1VVJ-1VVJ-1 Expiration Copy complete account number from your VISA card date: V"V-] V "V-] IMPORTANT: Copy complete account number from your MasterCard I I I I II I I I II I I I II I I I I Copy Number above your name on MasterCard...
- Page 49 To order accessories, contact your local Dealer. ifa dealer is not nearby, you can also follow the directions below to order by telephone or direct-by-mail. United States and Canada Orders To place your order by phone, have your Visa, MasterCard, or Discover card ready and call the toll-free...
-
Page 50: Trouble Shooting
if you're having t rouble w ithyour c amcorder, youprobably can correct theproblem yourself. Before youtake your c amcorder toanAuthorized RCACamcorder Service Center orcallaservice p erson, use thechart below. F ind theproblem and trythe adjustment(s) thatislisted totheright. if service should b enecessary, read yourwarranty tofindoutwhat i scovered a nd how togetservice. - Page 51 Sound i stoolowor • Subject was toofarfrom camcorder. distorted Tape stops d uring Tape-counter displayed. Whenever the tape counter rewind orfast appears, the camcorder stops rewinding (or fast forward orrewind forwarding) when the counter reads O000M. Press or fast f orward n ot RE W/REVIEW or EFWD again to continue rewinding operating or fast forwarding or press DISPLAFto remove the...
- Page 52 Trouble Title is recorded on • Title is recorded whenever it appears in the viewfinder. Press the TITLER button to remove the tape title from the viewfinder. See page Date and/or time are • Date or time might need to be set See page 18. incorrect •...
- Page 53 Clean the Camcorder To clean the camcorder's exterior, remove Caution: use of strong Cleaning any power source connected to the products, such as those containing camcorder and gently wipe it with a clean alcohol or benzine, might damage soft cloth. the camcorder.
- Page 54 • Do not leave your camcorder in direct Authorized RCA Camcorder sunlight for extended periods of time. Service Center. The resulting heat buildup might...
-
Page 55: Specifications
General Camera Section Power requirement: 9.6VDC Scanning: 525 lines/60 fields/30 frames Power consumption: 7.5 watts Image Sensor: 1/4" CCD Imager Lens: F1.4 Weight: 4.4 lbs. (2kg) 16:1 (4-64 mm) power zoom lens Diameter: 46 mm Dimensions - Including Viewfinder: 4-1/4" (W) x 8-3/8"... - Page 56 Thomson provides a toll-free telephone You can reach Thomson at the number to help you with any problems you following number: may encounter with your camcorder. Many 800-283-6503 can be diagnosed over the phone, and if (Toll free inside U.S.A.) necessary, repair or replacement will be arranged.
-
Page 57: Waranty
What your warranty covers: to our phone representative. This is for security purposes. If we receive your unit, excluding all accessories, within 14 days • Any defect in materials or workmanship. from the date you were provided the RA For how long after your purchase: number, only items not covered by •... - Page 58 • Check with your dealer or call 1-800-336- 1900 for the Authorized RCA Camcorder Service Center nearest you. • Take your unit to the Authorized RCA Camcorder Service Center of your choice. • Show the Authorized RCA Camcorder Service Center representative evidence of purchase date, such as a bill of sale.
-
Page 59: Camcorder Care
Car cord adapter Care and maintenance clean the camcorder viewfinder 51 Accessories clean the lens 51 included clean the viewfinder 51 optional proper care and storage 52 order form things to avoid 52 Adapter/charger Care and storage accessory camcorder charging battery cassette 17 using... -
Page 60: Index
Lens 8 EDIT-ADV button 8, 30 Electronic indexing 26 Lenscap Lenshood Erase protection Eyepiece focus control 9, 20, 33 removing 44 Macro focus 25 F FWD (fast forward) button 8, 18, 25, 28, 30, 34 Memory-stop feature 28 Fade indicators 22 Microphone 8, 24 First time operation 3... - Page 61 Speed Powering your camcorder recording and playback using adapter/charger Status indicators 22 using battery STOP button 7, 28 using optional car cord adapter Stop-action pause 34 Problem solving STOP/EJECT button 5, 8, 13, 17, 18, 28, 30, 33, 34, 37, 39 Quick review feature 24 Tape inserting 5...
- Page 62 VIDEO and AUDIO jacks 8, 38 Videocassettes Viewfinder 9 adjust for viewing 20 displays 22 eyepiece focus control 20 playback 33 Visual searching Warnings 23 Warranty 55 Zoom buttons 9, 24, 27 Zoom level indicators 23, 27...
- Page 63 Note: This equipment has been type tested and found to comply with the limits for a Class B Digital Device in accordance with the specifications in Part 15 of FCC Rules. These rules are designed to provide reasonable protection against radio and television interference in a residential installa- tion.
- Page 64 _ THOMSON CONSU MER ELECTRON ICS 10330 N Meridian Street Indianapolis, 46290 (C)1999Thomson Consumer Electronics, Inc. Trademark(s) (R)Registered Marca(s) Registrada(s) Printed in Japan TOCOM 15407930 QR31044...
