2. You candispense water b ytheounce, cup, o rliter. Press I CE
andLIGHT t oselect yourdesired setting. Default, minimum,
and maximum volumes are listed below.
Press the LOCK and FAST ICE/COOL buttons to adjust the
volume as desired.
NOTE: Most coffee cups (commonly 4 to 6 oz [118 to 177 mL]
per cup) are not the same size as a measuring cup (8 oz
[237 mL]). You may need to adjust the volume to avoid
overfilling coffee cups.
To dispense water, press a sturdy glass against the water
dispenser pad OR place the glass below the water dispenser
and press the WATER button.
NOTE: While dispensing water, the digital display will count
down how much water remains to be dispensed, according to
the volume you selected. The flow of water will automatically
stop once the desired volume has been dispensed.
To stop dispensing before the selected volume has been
dispensed, remove the glass from the dispenser pad OR press
the WATER button a second time.
NOTE: If you stop dispensing before the desired volume has
been dispensed, the digital display will continue to show how
much water remains to be dispensed. The display will turn off
after 15 seconds of inactivity.
To select a new volume or select the same volume again, you
must first finish dispensing the selected volume, or turn off the
Measured Fill feature and then turn it back on.
Rotating Faucet and Pull-out Tray (on some models)
Your dispenser may include a rotating water faucet and a small
pull-out tray at the bottom of the dispenser.
A. Faucet rotated
B. Pull-out tray
The faucet rotates to the center to allow for easy dispensing
into large containers. To rotate it, push in and release the left-
hand side of the faucet as shown.
The faucet rotates to the center automatically. However, you
must rotate it back into place manually. When in place, it will
NOTE: When using the dispenser with the faucet rotated, do
not use the water dispenser pad. Only use the WATER button
to dispense. Dispensing by pressing the container against the
water dispenser pad may result in unintentional spilling.
The tray can be pulled out approximately
2" (5.08 cm) to
better support large containers. It is designed to catch small
spills and allow for easy cleaning. There is no drain in the tray.
NOTE: The tray can be removed from the dispenser and
carried to the sink to be emptied or cleaned. Pull the tray out
until it hits the stop, then gently lift up on the back of the tray
and slide it out the rest of the way.
The Ice Dispenser
Ice dispenses from the ice maker storage bin in the freezer when
the dispenser pad is pressed. The dispensing system will not
operate when the freezer door is open. To turn off the ice maker,
see "Ice Maker and Storage Bin."
Your ice maker can produce both crushed and cubed ice. Before
dispensing ice, select which type of ice you prefer by pressing the
The display screen indicates which type of ice is selected.
• al_ *
For crushed ice, cubes are crushed before being dispensed. This
may cause a slight delay when dispensing crushed ice. Noise
from the ice crusher is normal, and pieces of ice may vary in size.
When changing from crushed to cubed, a few ounces of crushed
ice will be dispensed along with the first cubes.
1. Press the button to select the desired type of ice.
Use a sturdy glass when dispensing
Failure to do so can result in cuts.
Press a sturdy glass against the ice dispenser pad OR place
the glass below the ice dispenser and press the ice dispenser
Hold the glass close to the dispenser opening so ice does not
fall outside of the glass.
IMPORTANT: You do not need to apply a lot of pressure to the
pad or button in order to activate the ice dispenser. Pressing
hard will not make the ice dispense faster or in greater
Remove the glass OR release the button to stop dispensing.
NOTE: Ice may continue to dispense for up to 10 seconds
after removing the glass from the pad or releasing the button.
The dispenser may continue to make noise for a few seconds
