USING THE REMOTE
MENU Brings up the Main menu and selects highlighted items. When
in VCR mode, it functions as a PROGRAM button.
CLEAR Removes any menu or display from the screen and returns you
to TV viewing. Will also exit the Guide system.
{0-9} Number Buttons Enters channel numbers and time settings
directly though the remote control. To enter a two-digit channel, press
the two digits. To enter a three-digit channel, press and hold the first
digit until _'-- appears, then add the second two. Example: to tune to
channel 123, press and hold 1 until 1-- appears then press 2 and 3.
WHO.INPUT In TV mode, press to toggle through the available input
sources VID1/SVID1, VID2/COMP2, previous channel and FRNT {front
panel jacks). In SAT mode, press to select available channel lists.
ANTENNA Functions as TVNCR button in VCR mode and TV/receiver
button in SATeCABLE mode.
REVERSE,PLAY,FORWARD, REC'VCR+, STOP, PAUSE If
programmed, provides transport control for some remote-controllable
VCRs, DVD players, laserdisc players, tape decks, and CD players.
Pressing RECoVCR+ when using the GUIDE Plus+ Gold system sets the
VCR to record a program.
PiP {Picture-In-Picture) Brings up the small Picture-in-Picture window,
Press again to remove the PIP window. When PIP Caption Display -
Alternate with PIP - has been selected, will toggle between PIP on, PIP
on with closed captions, and PiP off.
SWAP Swaps the main picture with the PiP window.
CH CTRL Selects the picture window, (that is, the main or PIP
window) to be changed by the CH ^ (channel up) or CH v (channel
down) buttons.
RESET Resets picture quality controls to the Bright Lighting Picture
Control Preset. Point and select to choose a different Picture Control
Preset.
ACCESSING THE VIDEO INPUT
Use the WHO°INPUT button to scroll through the available input
channels and view components you have connected to the TV.
1. Press TV to place the remote in TV mode. Make sure that the
component you want to view is turned ON.
2. Press WHO.INPUT to tune to an available input channel.
3. Continue to press the WHO" INPUT button to scroll through the
channels.
Modes of Operation
Because this universal remote can
control several different components
(DVD player, VCR, Cable Box, etc.) it
uses operational modes triggered by the
component buttons. For example if you
want the remote to control the TV, you
would press the TV button to put the
remote into TV mode before you could
control the TV.
23
