Maximum power output

Direct (4 ohm) .................. 24 watts max. (continuous), 12 watts (rms) per channel
Direct (8 ohm) .................. 16 watts max. (continuous), 8 watts (rms) per channel
Protection ...................................... Input limiting, thermal, short circuit
Control/remote — switcher
Serial control port ........................ RS-232, 3.5 mm captive screw connector, 5 pole (uses 3 poles)
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations 1 = TX, 2 = RX, 4 = GND
Program control ........................... Extron's configuration program for Windows

General

Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 60 watts, internal, autoswitchable
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Rack mount ................................... Yes, with included brackets (#70-077-03)
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 17.5" W x 8.5" D (1U high, full rack wide)
Product weight
MLS 406 ............................. 5.0 lbs (2.3 kg)
Amplified models ............ 6.0 lbs (2.7 kg)
Shipping weight
MLS 406 ............................. 10 lbs (5 kg)
Amplified models ............ 11 lbs (5 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
MLS 304MA, MLS 304SA, MLS 406, MLS 406MA, MLS 406SA MediaLink Switchers • Specifications
Extron's Simple Instruction Set (SIS
Operating: +32 to +113 °F (0 to +45 °C) / 10% to 90%, noncondensing
4.4 cm H x 44.4 cm W x 21.6 cm D
(Depth excludes connectors and knob. Width excludes rack ears.)
®
™
)
(7.51-121206-D9)
