Safe Operation
Practices • Set-Up • Operation
• Maintenance
• Troubleshooting
• Warranty
OPER roR's
L
179cc & 208cc OHV Horizontal
Shaft Engine
752Z165-SUB,
752Z265-SU,
752Z365-SUB,
752Z265-JU,
752Z365-JU,
752Z270-SU,
752Z370-SUB,
752Z170-LO, 752Z170-COA
MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
PrintedIn USA
FormNo.769-06052
(April 1,2010)
