Related Manuals for Philips OR2200
Summary of Contents for Philips OR2200
- Page 1 Always there to help you Register your product and get support at www.philips.com/welcome OR2200 Question? Question? Contact Contact Philips Philips User manual...
-
Page 3: Table Of Contents
Contents 1 Safety 8 Listen to an external device 2 Your clock radio 9 Use system menus Introduction Check the current software version What's in the box Upgrade the software Overview of the product Reset the product Know about the LCD display 10 Adjust volume 3 For the first time use Assemble the AC power adaptor... -
Page 4: Safety
• Never install this product in a confined immediately. Contact Philips Consumer space. Always leave a space of at least four Care to have the product checked before inches around the product for ventilation. -
Page 5: Your Clock Radio
2 Your clock radio Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Introduction With this product, you can: • listen to FM radio stations (RDS supported), •... -
Page 6: Overview Of The Product
Overview of the product a TIMER • Press to view the alarm settings. • Press and hold to start setting • Press repeatedly to deactivate or activate the alarm timer. countdown timer. h PRESET • Press to access the list of stored radio •... -
Page 7: Know About The Lcd Display
Know about the LCD display a The first alarm is activated. b The second alarm is activated. c The clock d Text information e The sleep timer is activated. f The countdown timer is activated. g The current source... -
Page 8: For The First Time Use
3 For the first Fix another plug converter to the power adaptor. time use Connect power Assemble the AC power adaptor Connect the AC power adaptor between the DC-IN socket on the back panel, • • the AC power outlet. » The product switches to standby Align the plug converter to the holes on mode. -
Page 9: Adjust Brightness
Adjust brightness Press BRIGHTNESS repeatedly to adjust the brightness of the LCD display. -
Page 10: Set Time And Date
4 Set time and date Note • To manually set the clock, switch the product to standby mode first. In standby mode, press and hold until [Set time] is displayed. » The hour digits blink. Press to set the hour, and then press to confirm. -
Page 11: Use The Alarm Timer
5 Use the alarm Press to select the volume level, and then press to confirm. timer » [Alarm Saved] flashes. Deactivate a preset alarm Note Press AL1 (or AL2) to view alarm settings. • Make sure that you have set the clock correctly. Press AL1 (or AL2) again. »... -
Page 12: Listen To Fm Radio Stations
6 Listen to FM Search for a radio station radio stations manually Press repeatedly until the frequency of target radio station is displayed. Note Store radio stations • For optimal reception, fully extend the antenna and automatically adjust its position. •... -
Page 13: Display Rds Information
TRAVEL Travel Display RDS information LEISURE Leisure JAZZ Jazz Music Radio Data System (RDS) is a service that COUNTRY Country Music allows FM stations to transmit additional NATION M National Music information. When you tune to an FM radio OLDIES Oldies Music station that transmits RDS signals, the station name is displayed. -
Page 14: Listen To Dab Radio Stations
7 Listen to DAB Press repeatedly to select a station, and then press PRESET to start listening. radio stations • You can re-scan to update the list of stored stations (see 'Re-scan for stations' on page 13). • You can tune to a station manually (see 'Tune to a Note station manually' on page 13). -
Page 15: Display Dab Information
Tune to a station manually Note With this feature, you can tune to a specific • If you store a radio station with the sequence number of another one, the earlier one is overwritten. channel/frequency manually. In addition to antenna orientation for better radio reception, the optimal reception can also be obtained with this feature. - Page 16 Remove invalid stations Some stations in the list have no service when you travel to another area. In front of the station name of an invalid station, a question mark (?) is displayed. Press to access the sub-menus. Press repeatedly to select an option.
-
Page 17: Listen To An External Device
8 Listen to an external device You can also listen to an external audio device, for example, MP3 player, through this product. Press SOURCE repeatedly to switch the source to [AUX IN]. » AUX is highlighted. Connect an audio input cable with a 3.5 mm connector on both ends to the AUDIO-IN socket on the back •... -
Page 18: Use System Menus
Press to display the version of current software. Upgrade the software Go to www.philips.com/support. Search for support information about your product with "OR2200/10" or "OR2200M/10" as the keyword. » When an upgrade packet is available, the link of "Firmware Upgrade Readme File"... -
Page 19: 10 Adjust Volume
10 Adjust volume • To increase the volume, turn the power and volume knob clockwise. • To decrease the volume, turn the power and volume knob anti-clockwise. -
Page 20: Use The Sleep Timer
11 Use the sleep timer You can set a time period after which the product switches to standby mode automatically. Press SLEEP repeatedly to select a time period (in minutes). » When the sleep timer is activated, appears. » After the set period, the product switches to standby mode. -
Page 21: Use The Countdown Timer
12 Use the countdown timer You can set a time period after which the product buzzes. Press and hold TIMER until blinks. » The hour digits blink. Press repeatedly to set the hour, and then press to confirm. » The minute digits blink. Press repeatedly to set the minute, and then press... -
Page 22: 13 Troubleshooting
If you encounter problems when using this product, check the following points before requesting service. If the problem remains unsolved, go to the Philips Web page (www. philips.com/support). When you contact Philips, make sure that the product is nearby and the model number and serial number are available. -
Page 23: Product Information
Signal to Noise Ratio > 65 dBA AC power adaptor Model No.: OH- Audio Input 0.5 V RMS 20 kOhm 1015E0591500U1 Brand name: Philips Input: 100-240 V~, 50/60Hz, 350 mA; Output: 5.9 V 1.5 A Operation power consumption Standby power <... -
Page 24: 15 Notice
Any changes or modifications made to this prevent potential negative consequences for the device that are not expressly approved by environment and human health. Philips Consumer Lifestyle may void the user’s Environmental information authority to operate the equipment. All unnecessary packaging has been omitted. - Page 25 Specifications are subject to change without notice © 2013 Koninklijke Philips Electronics N.V. All rights reserved. OR2200_10_UM_V1.0...
