- Page 1 TURF TRACER ® For Serial Nos. 790,000 & Higher Part No. 4500-359 Rev. A...
-
Page 3: Table Of Contents
READ OPERATOR’S MANUAL BEFORE OPERATING OR SERVICING EXMARK EQUIPMENT. TABLE OF CONTENTS Description Page 36" Mower Deck ...3-4 48" Mower Deck ...5-6 52" Mower Deck ...7-8 Decals ...17-18 Electrical Group...15 Engine Deck Group ...9-12 Hydraulics Group...19 Upper Handles & Controls, ECS...13-14... -
Page 4: 36" Mower Deck
1-413113 Bushing, Idler...1 Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140). Kit 103-4051 includes antiscalp roller, spacer, & mounting hardware. Link assembly nominal length is 6.89” (or approximately 6 7/8”) between center of ball joint and center of furthest hole. -
Page 5: Mower Deck
36” MOWER DECK... -
Page 6: 48" Mower Deck
109-8854 Pin, Chute ...1 Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140). Kit 103-4051 includes antiscalp roller, spacer, & mounting hardware. Link assembly nominal length is 6.89” (or approximately 6 7/8”) between center of ball joint and center of furthest hole. -
Page 7: Mower Deck
48” MOWER DECK... -
Page 8: 52" Mower Deck
32128-20 Nut, Whizlock 5/16-18 ...6 Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140). Kit 103-4051 includes antiscalp roller, spacer, & mounting hardware. Link assembly nominal length is 6.89” (or approximately 6 7/8”) between center of ball joint and center of furthest hole. -
Page 9: Mower Deck
52” MOWER DECK... -
Page 10: Engine Deck Group
Screw, HH 7/16-20 x 2-1/2 ...1 3256-24 Washer, 3/8 SAE ...2 Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140). Manual start only. Electric start only. ∇ Use Pro-Lock (nut type, Part no. 1-840022, 5 ml tube): on setscrew threads. - Page 11 ENGINE DECK GROUP...
- Page 12 1-403180 Screw, HH 5/16-18 x 1 3/8 ...2 Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140). ∇ Use Pro-Lock nut type, Part No. 1-840022 (.5 ml tube) on shoulder bolts & setscrew threads.
- Page 13 ENGINE DECK GROUP (cont.)
-
Page 14: Upper Handles & Controls, Ecs
323-6 Screw, HH 3/8-16 x 1 ...4 Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140). ∇ Use Pro-Lock nut type, Part no. 1-840022 (.5cc tube) on setscrew threads, on thumblatch screws and on fuel fitting. - Page 15 ECS UPPER HANDLES and CONTROLS...
-
Page 16: Electrical Group
Item Part No. Description 1-543070 Switch, Ignition ... 1 1-603511 Key, Ignition... 1 103-2106 Key, Exmark Logo ... 1 Tie, Plastic Large... 2 1-303335 321-3 Screw, HH 1/4-20 x 5/8... 2 3296-42 Nut, Nyloc 1/4 20 ... 3 1-323442-01 Bracket, Fuse ... 1 1-816001 Fuse, 20A... -
Page 17: Wiring Diagrams
WIRING DIAGRAMS... -
Page 18: Decals
Decal, Ecs Console...1 116-0404 Decal, Hydraulic Tank ...1 103-2939 Decal, Tthp Model ...1 103-1798 Decal, Throttle...1 103-2882 Decal, Exmark Logo...1 1-303517 Decal, Belt Drive ...1 103-1977 Decal, Ecs Console...1 103-2076 Decal, Caution Hot Surface...2 Manual start only. Electric start only. - Page 19 DECALS...
-
Page 20: Hydraulics Group
Screw, HH 3/8-16 x 1-1/4 ...4 1-613034 Hose, Hydro...2 1-323241 Hose, Hydro...2 103-3914 Asm, Charge Hose...1 Exmark black touch up spray paint – Gloss black. Use only for operation below 32°F (0°C). HYDRAULIC GROUP Qty. Item Part No. 103-4019 109-4180... - Page 21 HYDRAULIC GROUP...
-
Page 22: Service Record
SERVICE RECORD Date Description of Work Done Service Done By... - Page 23 -22-...
- Page 24 © 2008 Exmark Mfg. Co., Inc. Industrial Park Box 808 Beatrice, NE 68310 All Rights Reserved Part No. 4500-359 Rev. A (402) 223-6300 Fax (402) 223-5489 Printed In USA.
