Place TV on a solid surface.
For ventilation, leave a space of at least 10 cm free all around
the set. To prevent any fault and unsafe situations, please do
not place any objects on top of the set.
Features
• It is a remote controlled color television.
• 100 programmes from VHF, UHF bands or cable channels
can be preset.
• It can tune cable channels.
• Controlling the TV is very easy by its menu driven system.
• It has two Euroconnector sockets for external devices (such
as video recorder, video games, audio set, etc.)
• FrontAV
Input available.
• Stereo sound systems (German+Nicam) are available.
• Full function Teletext (Fastext, Toptext).
• It is possible to connect headphone.
• Direct channel access.
• APS (Automatic Programming System).
• All programmes can be named.
• Forward or backward automatic tuning.
• Sleep timer.
• Automatic sound mute when no transmission.
• 5 minutes
after the broadcasting
(closedown),
the TV
switches itself automatically to stand-by mode.
Power connection
Important: The TV set is designed to operate on 220-240 V
AC, 50 Hz.
• After unpacking, allow the TV set to reach the ambient room
temperature before you connect the set to the mains.
Aerial Connections
• Connect the aerial plug to the aerial input socket located at
the back of the IV.
How to connect the external equipments
See "Connect the External Equipments" on page 11.
• See the instruction manuals provided with the external de-
vices too.
Inserting batteries in the remote control handset
• Remove the battery cover located on the back of the hand-
set by gently pulling upwards from the indicated part.
• Insert two AAA (R03) or equivalent type batteries inside.
• Replace the battery cover.
NOTE: Remove batteries from remote control handsetwhen it is
not to be used for a long period. Otherwise it can be damaged
due to any leakage of batteries.
You can operate your TV either using the remote control
handset or directly using the TV onset buttons.
To switch the TV on
Your TV will switch on in two steps:
1- Press the power button located on the front of the IV. Then
the TV switches itself to standby mode and the RED LED
located below the TV turns on.
2- To switch on the TV from stand-by mode either:
Press a digit button on the remote control so that a program-
me number is selected,
or,
Press Standby / Power Button or Programme Up and Down
buttons on the front of the TV or on the remote control re-
spectively, so the TV will switch on and the RED Led will turn
GREEN.
To switch the TV off
• Press the stand-by button on the remote control, so the TV
will switch to stand-by mode and the GREEN LED will be-
come RED,
or,
• Press the power button located on the front of the -IV.
The message "Please
check antenna
cable Auto. Pro-
gramming System" will be displayed when you turn on your
TV for the first time.
1- Select LANGUAGE with the "P A" or "P v"
button, then
press the "4" or "I," button to select a menu language.
2- Select COUNTRY with the "PA"
or "Pv"
button, then
press the "4" or "I," button to select the country you are
now located.
3- Select START with the "P A" or "P v"
button, then press
the "I," button to startAPS.
APS (Automatic Programming System) automatically pro-
grammes the received channels in your TV's programme
numbers. During APS, "A. P. S. IS RUNNING
PLEASE
WAIT" will be displayed. After APS is finalized, the "PRO-
GRAM." menu appears.
To cancel APS, press "STANDARD" button.
You can delete a channel, insert a channel into a programme
number, or re-start APS with the "PROGRAM." menu.
For details, see "PROGRAM.
(Programming)
Menu" on
page 8.
4- Press the "STANDARD"
button to complete the initial set-
tings.
After the initial settings are complete, you can change a pro-
gramme number or to name a programme number or to pro-
gramme
new channel
manually.
For details,
see
"TUNING Menu" on page 7.
If the message "Please check antenna cable Auto. Pro-
gramming System" does not appear, follow the description
"TV CONFIG. (configration)
Menu" on page 8 to select a
menu language and the country where you are now located,
then follow the description
"PROGRAM.
(Programming)
Menu" on page 8 to use AUTOSTORE
ENGLISH
- 4-
