When playing a digital source through a digital
terminal
• The DIGITAL SOURCE FORMAT lamps on the front panel
indicate what type of the digital signal comes into the receiver.
DIGITAL SOURCE FORMA_
DOLB¥ UNEt, R
DIGITAL pCM
DOLBY DIGITAL:
Eights up when Dolby Digital signals (see
page 21) come in.
LINEAR PCM:
Eights up when Linear PCM signals come
in.
• The signal indicators also light up on the display to indicate the
incoming channel signals. (Only the indicators for the incoming
signals light up.)
L: Left front channel
R: Right front channel
C: Center channel
kS: Left rear channel
RS: Right rear channel
S: Rear channel (monaural)
LFE: Subwoofer channel
Selecting different sources for picture and
sound
You can watch picture from a video component while listening to
sound from another component.
On the front panel:
1. Press SOUND SELECT (INPUT
ATT.) briefly while viewing the
picture from a video component
such as the VCR or DVD player,
etc.
"SOUND SELECT" appears on the display
2. Turn SOURCE SELECTOR to
select the sound (except the TV
sound), while the indication of the
above step is still on the display.
SOUND SELECT
From the remote control:
Press one of the audio source selecting buttons (CD, TAPE/MD,
PHONO, FM/AM), while viewing the picture from a video
component such as the VCR or DVD player, etc.
Notes:
• Once you have selected a video source, pictures of the selected
source are sent to the TV until you select another video source.
• Whenyouselect"TVSOUND'asthesource, thisfunctiondoesnot
work.
On the front panel'.
To increase the volume, turn MASTER
VOLUME clockwise,
To decrease the volume, turn it
counterclockwise.
• When you turn MASTER VOLUME rapidly,
the volume level also changes rapidly.
• When you turn MASTER VOLUME slowly,
the volume level also changes slowly.
From the remote control:
To increase the volume, press VOLUME +.
To decrease the volume, press VOLUME
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Note:
The volume level can be adjusted within the range of "O"(minimum) to
"90" (maximum).
On the front panel ONLY'.
When you have connected two pairs of the front speakers, you can
select which to use.
Press SPEAKERS 1 or SPEAKERS 2 to select
SPE^KERS
the speaker to use.
_L_
• Each time you press the button, the lamp on _
the respective button turns on and oft: When
the lamp on either button lights up, the
respective speakers are activated.
Note:
If you use any of the DSP modes other than the 3D-PHONIC modes
with both front speakers activated, the speakers connected to the
FRONT SPEAKERS _2 terminals are deactivated.
10
