• If cleaner is in disrepair, do not attempt to operate. • Have repairs made by the qualified personnel at Hoover Factory Service Centers or Authorized Hoover Warranty Service Dealers. SAVE THESE INSTRUCTIONS ¢. The Hoover Company i971...
HOW TO ASSEMBLE YOUR NEW HOOVER CLEANER ASSEMBLE HANDLE PIECES Remove cardboard from end of handle pieces. Slide the two handle pieces together. Check see that cord clips are on the same side of the handle. Insert bolt through small...
TO ATTACH OUTER JACKET TO CLEANER Place the two projections at the bottom of the outer bag assembly inside the wire loops at the back of the cleaner. Pull the bag clip to the left and fit bag against opening. When you release bag clip,...
To turn cleaner push switch down. turn cleaner off, pull the switch HANDLE ADJUSTMENTS The handle on your cleaner has three positions -- storage, operating, low (for reaching under low furniture). handle be low- ered by stepping on pedal at the left rear of cleaner. handle should always...
Brush, and Bare Floor Brush. Upholstery Brush. USING YOUR ATTACHMENTS NOTE: When using tools, select SHAG RUG POSITION on cleaner. Your Hoover Cleaner is equipped with a two-speed motor. One speed utilized when the cleaner is being used on carpets...
Page 7
TO CONNECT CONVERTER TO CLEANER Tilt the cleaner so the underside Push converter all the way in to the red line. It is not visible. Insert the converter in the track on the underside of the cleaner. necessary to remove the belt.
MANY USES FOR CLEANING ATTACHMENTS Vinyl Hose Hose has vinyl jacket for long, trouble-free life. Floor Brush* All hard floors carpeted stairs. Upholstery Nozzle Upholstery Brush Upholstered furniture, draperies, tapestries, mattresses, clothing, automobile interiors, carpeted stairs. Dusting Brush* Carved furniture, table tops, books,...
Page 9
Hoover throw-away filter bags made by The Hoover Company. Genuine Hoover bags can be identified by the Hoover Medallion. These bags are made from special material which is scientifically formulated to filter dust while allowing air to flow through freely.
Discard used bag. WHERE BAGS Bags may be purchased from your local Authorized Hoover Dealer, ;ea on tne Dell:. ';_'_ ......... BELT Check from time to time to be sure the :it is stretched or cut.
Page 11
4. Lift out rug agitator, remove old belt and place new belt in groove of rug agitator. 5. Replace agitator. one end of the agitator roll there is a raised metal plate. Make sure that this end is placed in groove on side of cleaner.
THE BRUSHES When brushes are worn and bristles not touch the edge of a card held across the nozzle, they should be re- placed. Always replace both brushes at the same time to maintain clean- ing efficiency. REPLACE BRUSHES 1. (Disconnect the Cleaner from Electrical...
REPLACING HEADLIGHT* Disconnect the Cleaner from Electrical Outlet. 1. Set nozzel adjustment to the Normal High position. 2. Turn cleaner over and remove the two screws indicated in the illustration. Place cleaner in the upright position. Slip furni- ture guard and hood up off of cleaner casting.
1. Set carpet adjustment lever HARB TO lever setting, for type carpet being PUSH cleaned. If the problem persists, check the telephone book for a HOOVER COMPANY listing, or consult the white insert accompanying this manual for the nearest location...
3. Turn off cleaner when not in use, such as when moving furniture. 4. Keep your cleaner operating at peak performance level - have spection and service performed by a Hoover Factory Service Center or Authorized Hoover Service Dealer.
Page 16
VCMA VACUUM CLEANER MANUFACTURERS ASSOCIATION (HOOVER -AN ASSOCIATION. MEMBER) Service To The Consumer Since 19 13 This information has been compiled by the Vacuum Cleaner Manufacturers Associ- from Governmentaland Private Sources concernedwith product safety. ation These basic guidelinesare for your protectionand convenience.
