KitchenAid KECC562GBL2 Parts List page 3

36" electric built−in cooktop
Hide thumbs


Advertisement

Illus.
Part
No.
No.
DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
3172515 Mtg. Hardware Kit
3192737 Seal, Burner Box
3191239 Tape, Foam
4455364 Bracket,
Support (4)
3192408 Bracket,
Support (2)
8177484
MISCELLANEOUS PARTS
For Models: KECC562GBL2, KECC562GWH2, KECC562GBT2
(Black)
Illus.
Part
No.
No.
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
242820 Wire, Black
242822 Wire, Blue
242830 Wire, Brown
242823 Wire, Green
242824 Wire, Orange
242829 Wire, Red
242825 Wire, Red
242831 Wire, Red
242826 Wire, White
242827 Wire, Yellow
242832 Wire, Yellow
(White)
(Biscuit)
Illus.
DESCRIPTION
No.
CLEANER, COOKTOP
WIRING HARNESS PARTS
12 Ga. 150 C
14 Ga. 150 C
14 Ga. 150 C
14 Ga. 200 C
14 Ga. 150 C
14 Ga. 150 C
12 Ga. 150 C
14 Ga. 150 C
14 Ga. 200 C
14 Ga. 150 C
14 Ga. 150 C
14 Ga. 200 C
3
Part
No.
DESCRIPTION
3191048 Cleaner, Glass
4455274 Harness, Main
313438 Clip, Harness
3400015 Screw, Ground
3192221 Conduit
