Table 2
Symptom
Heating will not come
on.
Cooling will not come
on.
Cool ON or Heat ON
is displayed, but no
warm or cool air is
coming from the
registers.
Control does not
respond to keypad
presses.
Fan does not operate
properly in heat or
cool mode.
Fan runs all the time.
Page - 19
Pub. No. 22-5204-01
Possible Cause
1. System Mode not set to Heat.
2. Minimum off time delay being enforced. "waiting displayed".
3. Loose connection to control or system.
4. Heating system requires service or
control requires replacement.
1. System Mode not set to Cool.
2. Minimum off time delay being enforced "waiting displayed".
3. Loose connection to control or system.
4. Cooling system requires service or
control requires replacement.
1. The heating equipment turns on the
fan when the furnace has warmed up to a
setpoint.
2. Heating or cooling equipment is not
operating.
1. "Keypad locked" icon is displayed on LCD.
2. Keypad failure.
1. Incorrect wiring.
2. Heating or cooling equipment inoperative.
1. Fan mode set to ON.
2. Shorted control wiring.
Troubleshooting
(Continued)
Action
1. Set Mode to heat and raise the setpoint above room temperature.
2. If heating does not come on within 5 minutes, Check Heating.
3. Check - Repair connections.
4. Repair system / Replace control.
1. Set Mode to cool and lower the setpoint below room temperature.
2. If cooling does not come on within 15 minutes, contact servicer.
3. Repair connections.
4. Repair system / Replace control.
1. Wait one minute after seeing the ON icon and then check the registers.
2. Check Heating and Cooling system.
1. Unlock keypad - press Up+Down arrow together until "Keypad Locked"
disappears.
2. Replace Control.
1. Correct wiring.
2. Repair system.
1. Set fan mode to AUTO.
2. Check / Repair wiring.
